B - Data Matrix - Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands

b - Data Matrix

Purpose:
Syntax:
52
Example:
N
b10,20,C,1EC,x4,Y12,B,p40,210,0,F,"(01)938123456789
01|(10)ABCD123456(410)3898765432108"
P
(01)93812345678901
(10)ABCD123456(410)3898765432108
EAN/UCC Command Example
The following Data Matrix specific options should append the
general part of the two-dimensional code command indicated by
the italicized characters, see
General Part" on page 48
bp ,p ,p ,[P ,"DATA"]
1 2 3 4
b Data Matrix Command Parameter Descriptions
Parameter Description
P Narrow bar from 1-15
4
"DATA" Represents a fixed data field, maximum 125
characters long
Example:
N
b40,80,D,5,"123456789012345678901234567890123456789
0123456789012345678901234567890
12345678901234567890"
P1
Data Matrix Command Example
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
"b - Two-Dimensional Bar Codes,
for more information.
