Chapter 1 — Introducing ESim

Printhead Density

10
The printers are available with two different printhead densities,
either 203.2 dpi or 300 dpi, and each printhead requires its own
firmware version.
Printhead Density Specifications
Field
X-axis
Y-axis
Number of active dots
Maximum print width
Dot line to tear bar
Dot line to cutter blade 256 dots
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
Medium High
203.2 dpi 300 dpi
(8 dots/mm) (11.81 dots/mm)
203.2 dpi 304.8 dpi
(8 dots/mm) (12 dots/mm)
832 1208
104 mm 102.2 mm
136 dots 204 dots
384 dots
