Remarks:

b - EAN/UCC Composite-Code

Purpose:
Syntax:
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
The standard program packages contain all the two-dimensional
bar codes mentioned above.
If the amount of data does not fit in the area specified, the
indicator turns orange, indicating an error.
The following EAN/UCC Composite-Code bar code specific
options should append the general part of the two-dimensional
bar code command (indicated by the italicized characters, see
Two-Dimensional Bar Codes, General Part" on page 48
more information. Presently, only EAN/UCC-128 with CC-C is
supported.
bp ,p , p , p ,o,x,y,s,1,[B,][P][F,]M,"Data
1 2 3 4
b - EAN/UCC Command Parameter Description
Parameter Description
p
Selection of bar code type
4
(linear part and two-dimensional part)
1EC and EAN/UCC-128 with CC-C
o 0 = No rotation
1 = 90° rotation clockwise
2 = 180° rotation clockwise
3 = 270° rotation clockwise
Limit is 0-3.
Default is 0.
x Module width of pixel size in dots, magnification of
both linear and 2D composite component.
Limit is 1-10
Default is 2.
y Bar height on linear part in dots.
Limit is 2-999.
Default is 100.
Chapter 7 — Commands
"b -
for
| Data "
1 2
49
