Intermec EasyCoder PC4 Programmer's Reference Manual page 65

Chapter 7 — Commands
50
b - EAN/UCC Command Parameter Description (continued)
Parameter Description
Y Bar height on two-dimensional composite part in
dots. Minimum height is 2*x, nominal is 4*x.
Limit is 2-999. Default is 4 (2*x).
s Separator pattern height in dots between linear
component and two dimensional composite
component. Limits is 1-60 (minimum s = 1*x,
maximum s = 6*x). Default is same as x.
l Manually controlled column count on CC-C code.
If not set, the column count is optimized to linear
bar width. Limit is 1-30. Default is NA.
B Flag for human readable text of linear component
part, to present within the same rules as to the single
bar code. Font selection depends on the bar code
type. It is similar to B-command parameter p
see"B - Standard Bar Codes" on page
Default is no B flag.
px, y, m Human readable text of two-dimensional composite
component part appended by additional variables
for any position relocation around the composite bar
code:
x = horizontal start location: max is 4 digits.
y = vertical start location: max is 4 digits.
m = maximum characters per line. The max is 3
digits, and 0 = no limit.
Fixed Font selection 3 without any multiplier used.
CR, LF in data causes the rest of the text to wrap
around to the next line.
Similar design as b-command parameter p on
PDF417.
Limits are x and y position limitations.
Default is no p.
F Restrain control filter, to reduce input data
information, by deleting special characters for the
bar code rendering, but let them be a part of human
readable text. Deleted characters are ( ) space CR
and LF. Filters only hex 0ah, 0dh, 20h, 28h, 29h.
Default is no F.
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
,
8
42.
