Place Variable Text
Command
A24,160,0,5,1,1,R,V00
Place a Combination of Fixed Data and a Variable
Command
A24,250,0,4,1,1,N,"MODEL:"V01
A472,312,0,4,1,1,N,"Checked by:"V02
Place a Combination of Fixed Data and a Counter
Command
A24,312,0,4,1,1,N,"SERIAL#:"C0"
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
The next line is a text line, using text size 5 in reverse and prints
the variable V00. The data printed in this field must be sent to
the printer at the time of form retrieval.
The following two command lines consist of a combination of
fixed data enclosed in quotation marks and variable data.
The next command line is a text line containing fixed data and
the counter (C0). The first time this label form is retrieved for
printing, the start value for this counter must be sent to the
printer. The printer stores the value of the counter for this form
and automatically continues to print the next value the next time
this form is retrieved. Reset or set to another value by sending a
new start value.
Note: The value of the counter is kept in the memory even if
another form is retrieved or the printer is switched off.
Chapter 5 — Editing in Direct Mode
Explanation
Write a text line, first variable.
Explanation
Write a text line, second variable.
Write a text line, third variable.
Explanation
Write a text line with fixed data and first
counter.
27
