Memory Maps and Registers
5.3

Flash Memory Map

The table below lists the memory range designated to U-boot and ENV variables.
Table 5-2
Description
U-boot
Reserved
ENV Variables
Available Flash
5.4

Linux Devices Memory Map

The table below lists the memory ranges designated to different devices in Linux.
Table 5-3
Device Memory Range
Ram Mem
PCIE3 Mem
PCIE2 Mem
PCIE1 Mem
MRAM
PCIE3 IO
PCIE2 IO
PCIE1 IO
QUART0
QUART1
QUART2
QUART3
Timer
FPGA
ecm local access window CCSR
90
Flash Memory Map
Linux Devices Memory Map
Memory Area
0x00000000 0x0008ffff
0x00090000 0x0009ffff
0x00100000 0x0011ffff
0x00120000 0x007fffff
Memory Area
0x00000000 0x7fffffff
0x80000000 0x9fffffff
0xa0000000 0xbfffffff
0xc0000000 0xdfffffff
0xfff00000 0xfff7ffff
0xffc00000 0xffc0fff
0xffc10000 0xffc1ffff
0xffc20000 0xffc2ffff
0xffc40000 0xffc4ffff
0xffc50000 0xffc5ffff
0xffc60000 0xffc6ffff
0xffc70000 0xffc7ffff
0xffc80000 0xffc8ffff
0xffdf0000 0xffdf0fff
0xffe00000 0xffe00ffff
MVME2500 Installation and Use (6806800L01S)
Memory Maps and Registers
Size
2GB
512MB
512MB
512MB
512KB
64KB
64KB
64KB
64KB
64KB
64KB
64KB
64KB
4KB
4KB
