Controls, LEDs, and Connectors
Table 3-12 PMC J13 Connector (continued)
Pin
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
56
Signal Description
GND
+3.3V
PAR64
+3.3V
AD 62
AD 61
GND
GND
AD 60
AD 59
AD 58
AD 57
GND
+3.3V
AD 56
AD 55
AD 54
AD 53
GND
GND
GND
AD 51
AD 50
AD 49
GND
Controls, LEDs, and Connectors
Pin Signal Description
40 AD 40
41 AD 43
42 AD 42
43 AD 41
44 GND
45 GND
46 AD 40
47 AD 39
48 AD 38
49 AD 37
50 GND
51 GND
52 AD 36
53 AD 35
54 AD 34
55 AD 33
56 GND
57 +3.3V
58 AD 32
59 NC
60 NC
61 NC
62 GND
63 GND
64 NC
