Table 3-3
Pin Name
7B
8B
9B
10B
D1B
D2B
D3B
D4B
3.4.1.2

Front Panel Serial Port (J4)

There is one front access asynchronous serial port interface that is routed to the micro mini
DB-9 front panel connector. A male-to-male micro-mini DB9 adapter cable is available
under SMART EC part number SERIAL-MINI-D2 and ACC/CABLE/SER/DTE/6E 9-pin
micro-DSUB to 9-pin DSUB cross connected serial console cable. The pin assignments for
these connectors are as follows:
Table 3-4
Pin
1
2
3
4
5
6
7
8
9
MVME2500 Installation and Use (6806800L01S)
Front Panel Tri-Speed Ethernet Connector (J1) (continued)
Signal Description
Port B TRD1 -
Port B TRD1 +
Port B TRD0 -
Port B TRD0 +
Port B Green LED1Anode/ Yellow LED1 Cathode
Port B Yellow LED1 Anode/ Green LED1 Cathode
Port B Green LED2Anode/ Yellow LED2 Cathode
Port B Yellow LED2 Anode/ Green LED2 Cathode
Front Panel Serial Port (J4)
Signal Description
NC
RX
TX
NC
GND
NC
RTS
CTS
NC
Controls, LEDs, and Connectors
47
