Table 4-5 Transition Module Features - SMART Embedded Computing MVME2500 Installation & Use Manual

The MVME721X RTM is for I/O routing through the rear of a compact VMEbus chassis. It
connects directly to the VME backplane in chassis with an 80 mm deep rear transition area.
The MVME721X RTM is designed for use with the MVME7100, MVME2500, and
MVME4100. It has the following features:
Table 4-5
Function
I/O
For more information, refer to the MVME721X RTM Installation and Use. See
Related Documentation
MVME2500 Installation and Use (6806800L01S)
Transition Module Features
Features
One five-row P2 backplane connector for serial and Ethernet I/O passed from the
SBC
Four RJ-45 connectors for rear panel I/O: four asynchronous serial channels
Two RJ-45 connectors with integrated LEDs for rear panel I/O: two 10/100/1000
Ethernet channels
One PIM site with rear panel I/O
for details on how to obtain and download the document.
Functional Description
Appendix B,
87
