Controls, LEDs, and Connectors
3.4.2.2

SATA Connector (J3)

The on-board customized SATA connector is compatible with the SATA kit, namely VME-
64GBSSDKIT and IVME7210-MNTKIT.
Table 3-9
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
52
Custom SATA Connector (J3)
Signal Description
GND
GND
NC
SATA TX +
NC
SATA TX -
GND
GND
GND
GND
NC
SATA RX -
NC
SATA RX +
GND
GND
NC
GND
NC
GND
Controls, LEDs, and Connectors
Pin Signal Description
21 GND
22 SATA POWER ENABLE
23 NC
24 SATA DETECT
25 NC
26 GND
27 NC
28 GND
29 GND
30 GND
31 +3.3V
32 +5V
33 +3.3V
34 +5V
35 +3.3V
36 +5V
37 +3.3V
38 +5V
39 +3.3V
40 +5V
