Hardware Preparation and Installation
2. Remove the PMC/XMC filler plate from the front panel cut-out.
3. Slide the front bezel of the PMC/XMC into the front panel cut-out from backside. The
front bezel of the PMC/XMC module will be placed with the board when the connectors
on the module align with the connectors on the board.
4. Align the mating connectors properly and apply minimal pressure to the PMC/XMC until
it is seated to the board.
5. Insert the four PMC/XMC mounting screws through the mounting holes on the bottom
side of the board, and then thread the four mount points on the PMC/XMC. Fasten the
screws.
6. Install the board into the appropriate card slot. Make sure that the board is well seated
into the backplane connectors. Do not damage or bend connector pins.
7. Replace the chassis or system cover.
8. Reconnect the system to the power source and then turn on the system.
When removing the PMC/XMC, hold it by its long side and exert minimal force when
pulling it from the baseboard to prevent pin damage.
2.6

Installing and Removing the Board

This section describes the recommended procedure for installing the board in a chassis.
Read all warnings and instructions before installing the board.
The MVME2500 does not support hot swap. Power off the slot or system and make sure
that the serial ports and switches are properly configured.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits
or shorten its life.
Before touching the board or electronic components, make sure that you are
working in an ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel
and/or PCB. Deformation of the front panel can cause an electrical short or other
board malfunction.
38
Hardware Preparation and Installation
NOTICE
MVME2500 Installation and Use (6806800L01S)
