Introduction
Boot Firmware: U-Boot-based firmware image in 16 MB SPI Flash. This flash is

split into two 8 MB chips.
Operating Systems

–
–
MVME721X Transition Module I/O

–
–
–
–
Software: U-Boot firmware

One PMC/XMC site

SATA port for optional on-board hard drive

Extended temperature and rugged variants

The front panel I/O configuration consists of two RJ45 10/100/1000BASE-T

Ethernet ports, a USB 2.0 port, a Micro DB9 RS-232 serial console port, and a
reset/abort switch. It also has an LED to signal board failure and another LED that
can be configured in the LED register.
The rear I/O includes support for VMEbus (Legacy VME, VME 64, VME64x, and

2eSST), rear PMC/XMC I/O, RTM I/O (through VME P2), two 10/100/1000BASE-
T Ethernet, four UART, and RTM I2C/Presence/Power.
2
I

–
–
–
–
VMEbus Interface Controller: Tsi148 PCI-X to VMEbus bridge with support for

VME64 and 2eSST protocols
CPLD: Watchdog, timers, and registers

28
Based from BSP provided by NXP which is based from standard Linux version
2.6.32-rc3. Development tool is ltib 9.1.1 (Linux Target Image Builder) from
Freescale
VxWorks
Two GbE interfaces
Four RS-232 serial ports
2
I C
PMC I/O
C devices
Real-Time Clock
Board Temperature Sensor
8 KB VPD EEPROM
Two 64 KB User EEPROM
