Programming Model
2
7.4 I C Bus Device Addressing
The following table contains the I
device address.
Table 7-3
2
I C Bus Address
0x50
0x4C
0x68
0x54
0x52
0x53
0x55
0x56
1. This is a dual address serial EEPROM.
2. The RTM Bus address can be manually changed through the S1 Switch on RTM. The
default switch configuration will set the address to 0x55. Make sure that the address is
unique to the RTM Bus address when setting the switch.
3. The address of the XMC EEPROM is configured through Geographic Address resistor
on- board.
7.5

Ethernet PHY Address

The assigned Ethernet PHY on the MII management bus is shown in the following table.
Table 7-4
Ethernet
Port
TSEC1
TSEC2
TSEC3
122
2
C devices used for the MVME2500 and its assigned
2
I C Bus Device Addressing
Device Function
SPD
ADT 7461 Temperature Sensor
DS 1375 real-time clock
VPD
User configuration
User configuration
RTM EEPROM
XMC EEPROM
PHY Types and MII Management Bus Address
Function / Location
Gigabit Ethernet port routed to front panel
Gigabit Ethernet port routed to front or back panel,
set by GBE_MUX_SEL in S2
Gigabit Ethernet port routed to back panel
Size
256 x 8
N/A
N/A
8192 x 8
65536 x 8
65536 x 8
8192 X 8
N/A
PHY Types
BCM54616
BCM54616
BCM54616
MVME2500 Installation and Use (6806800L01S)
Programming Model
Notes
1
1
1
1, 2
3
PHY MIIM
Address
1
7
3
