JTAG Chain and Board

The MVME2500 is designed to work with separate JTAG board rather than with an on-
board JTAG multiplexer. The chip can support up to a 6-scan port and the board's boundary
scan requires the following to function: ASSET hardware, JTAG board, and JTAG cable.
The MVME2500 provides a 60-pin header that can connect to the JTAG board using a
custom cable.
The JTAG board provides three different connectors for the ASSET hardware, flash
programming and the MVME2500 JTAG connector. The board is equipped with TTL buffers
to help improve the signal quality as it traverses over the wires.
4.20.3

Custom Debugging

Custom debugging makes use of the common on-chip processor. Refer to
Chip Processor (COP) on page 71
4.21

Rear Transition Module (RTM)

The MVME2500 is compatible with the MVME721X RTM.
86
POST Code Indicator on the LED
D33 D34 D35
0 0 0
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0 0 0
Description
U-boot has been copied from SPI flash to CPU cache.
Serial console has been initialized, some text is
visible on the terminal.
DDR has been initialized using SPD parameters,
Execution is still in the cache.
Execution has been relocated to RAM.
PCI has been initialized.
POST routines are finished.
Additional SW routines are finished.
U-boot prompt is visible on the terminal, can start
loading OS image from USB, Ethernet, SATA SSD,
SD.
for details.
