Table 3-7
Pin Row A
24 PMC IO 48
25 PMC IO 50
26 PMC IO 52
27 PMC IO 54
28 PMC IO 56
29 PMC IO 58
30 PMC IO 60
31 PMC IO 62
32 PMC IO 64
3.4.2

On-board Connectors

3.4.2.1

Flash Program Connector (P7)

The Flash Program Connector is depopulated in the production version of the MVME2500.
However, each pin is exposed for the 60-pin header connector for the JTAG boundary scan.
Table 3-8
Pin
1
2
3
4
5
6
7
8
10
MVME2500 Installation and Use (6806800L01S)
VMEbus P2 Connector (continued)
Row B
DATA 25
DATA 26
DATA 27
DATA 28
DATA 29
DATA 30
DATA 31
GND
+5V
Flash Programming Header (P7)
Signal Description
HOLD 1
Chip Select 1
Chip Select 0
Programmer's VCC
Master In Slave OUT (MISO)
HOLD 0
Keying
CLOCK
GND
Master OUT Slave IN (MOSI)
Controls, LEDs, and Connectors
Row C Row D
PMC IO 47 GE4_2+
PMC IO 49 GND
PMC IO 51 GE4_1 -
PMC IO 53 GE4_1 +
PMC IO 55 GND
PMC IO 57 GE4_0 -
PMC IO 59 GE4_0 +
PMC IO 61 GND
PMC IO 63 +5V
Row Z
GND
Serial 4 RX
GND
Serial 4 TX
GND
Serial 4 CTS
GND
Serial 4 RTS
GND
51
