Table 3-12 Pmc J13 Connector - SMART Embedded Computing MVME2500 Installation & Use Manual

Table 3-11
Pin
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

Table 3-12 PMC J13 Connector

Pin
1
2
3
4
5
6
7
MVME2500 Installation and Use (6806800L01S)
PMC J12 Connector (continued)
Signal Description
BUSMODE4 (PULLED DWN)
NC
GND
AD 30
AD 29
GND
AD 26
AD 24
+3.3V
IDSEL
AD 23
+3.3V
AD 28
AD 18
GND
AD 16
CBE2
Signal Description
NC
GND
GND
CBE7
CBE6
CBE5
CBE4
Controls, LEDs, and Connectors
Pin Signal Description
48 AD 10
49 AD 8
50 +3.3V
51 AD 7
52 REQB
53 +3.3V
54 GNTB
55 NC
56 GND
57 NC
58 EREADY
59 GND
60 RSTOUT
61 ACK64
62 +3.3V
63 GND
64 NC
Pin Signal Description
33 GND
34 AD48
35 AD 47
36 AD 52
37 AD 45
38 GND
39 +3.3V
