10. Accessories

Standard Accessories
FXCQ20 125M
~
Name Metal clamp
Quantity 1 pc.
Shape
Washer for
Name
hanging bracket
Quantity 8 pcs.
Shape
• Screws for fixing panels are attached to decoration panel.
Optional Accessories (For Unit)
Type
Item
Decoration panel
∗1 High efficiency filter
65%
∗1 High efficiency filter
90%
Filter
related
Filter Bottom
chamber suction
Long life replacement
filter
Note:
∗ 1. Filter chamber is required if installing high efficiency filter.
Optional Accessories (For Controls) : Refer to P.645
FXCQ-M
Paper pattern for
Drain hose
installation
1 pc. 1 pc.
Clamp Screws (M5)
8 pcs. 4 pcs.
For paper pattern
for installation
FXCQ20M
FXCQ25M FXCQ40M
FXCQ32M
BYBC32G-W1 BYBC50G-W1
KAFJ532G36 KAFJ532G56
KAFJ533G36 KAFJ533G56
KDDFJ53G36 KDDFJ53G56
KAFJ531G36 KAFJ531G56
Washer fixing
Insulation for fitting
plate
1 each 4 pcs.
for gas pipe
for liquid pipe
(Other)
• Operation manual
• Installation manual
FXCQ50M FXCQ63M
BYBC63G-W1
KAFJ532G80
KAFJ533G80
KDDFJ53G80
KAFJ531G80
