Connectors and Features

5.1

COM Express A - B Connector

Table 3 Module Type 10 Connector Pinout—Rows A and B
Pin Row A
A1 GND(FIXED)
A2 GBE0_MDI3-
A3 GBE0_MDI3+
A4 GBE0_LINK100#
A5 GBE0_LINK1000#
A6 GBE0_MDI2-
A7 GBE0_MDI2+
A8 GBE0_LINK#
A9 GBE0_MDI1-
A10 GBE0_MDI1+
A11 GND(FIXED)
A12 GBE0_MDI0-
A13 GBE0_MDI0+
A14 GBE0_CTREF
A15 SUS_S3#
A16 SATA0_TX+
A17 SATA0_TX-
A18 SUS_S4#
A19 SATA0_RX+
A20 SATA0_RX-
A21 GND(FIXED)
A22 USB_SSRX0-
A23 USB_SSRX0+
A24 SUS_S5#
A25 USB_SSRX1-
A26 USB_SSRX1+
A27 BATLOW#
Copyright © 2022 congatec GmbH
Pin Row B Pin
B1 GND(FIXED) A56
B2 GBE0_ACT# A57
B3 LPC_FRAME# A58
B4 LPC_AD0 A59
B5 LPC_AD1 A60
B6 LPC_AD2 A61
B7 LPC_AD3 A62
B8 LPC_DRQ0# A63
B9 LPC_DRQ1# A64
B10 LPC_CLK A65
B11 GND(FIXED) A66
B12 PWRBTN# A67
B13 SMB_CK A68
B14 SMB_DAT A69
B15 SMB_ALERT# A70
B16 SATA1_TX+ A71
B17 SATA1_TX- A72
B18 SUS_STAT# A73
B19 SATA1_RX+ A74
B20 SATA1_RX- A75
B21 GND(FIXED) A76
B22 USB_SSTX0- A77
B23 USB_SSTX0+ A78
B24 PWR_OK A79
B25 USB_SSTX1- A80
B26 USB_SSTX1+ A81
B27 WDT A82
Row A Pin
RSVD B56
GND B57
PCIE_TX3+ B58
PCIE_TX3- B59
GND(FIXED) B60
PCIE_TX2+ B61
PCIE_TX2- B62
GPI1 B63
PCIE_TX1+ B64
PCIE_TX1- B65
GND B66
GPI2 B67
PCIE_TX0+ B68
PCIE_TX0- B69
GND(FIXED) B70
eDP_TX2+/LVDS_A0+ B71
eDP_TX2-/LVDS_A0- B72
eDP_TX1+/LVDS_A1+ B73
eDP_TX1-/LVDS_A1- B74
eDP_TX0+/LVDS_A2+ B75
eDP_TX0-/LVDS_A2- B76
eDP/LVDS_VDD_EN B77
LVDS_A3+ B78
LVDS_A3- B79
GND(FIXED) B80
eDP_TX3+/LVDS_A_CK+ B81
eDP_TX3-/LVDS_A_CK- B82
