5.6.3.5
Flat Panel and Backlight Power Supply Connection
+3.3 V
Connector X36
LVDS_BKLT_EN
Copyright © 2022 congatec GmbH
+12 V
+5 V
X34
1
2
1
2
X36
3
LVDS_BKLT_CTRL
LVDS I2C
1.5 A
1.5 A
X33
3
1
2
3
LVDS_VDD_EN
1.5 A
1.5 A
DAC
O
CET0m10
X35
[4] +12 V
[3] +5 V
[1] VDD_LCD
[5] LVDS_VDD_EN
[2] VDD_BKLT
[6] LVDS_BKLT_EN
[8] LVDS_BKLT_CTRL
[7] LVDS_BKLT_VREF
[9] GND
[10] GND
35/58
