PWR_OK Signal

The PWR_OK signal is a high-active input from the main power supply to the module and it indicates whether the power is good. Use jumper
X57 to configure the PWR_OK signal.
Table 12 X57 - Module PWR_OK Signal
Pin Description
1-2 Add 3.3V pull-up with 1 kΩ to PWR_OK signal (default)
3-4 Connect PWR_OK signal from ATX power supply
5-6 Connect PWR_OK signal from onboard DC/DC regulator (only via DC banana jack)
Connector Type
X57: 2.54 mm, 2-pin jumper
5.2.6

Power-Up Control

The module's SUS_S3# signal controls the ATX power supply control signal (PS_ON#). When the system goes to Suspend to RAM (S3) or
Soft Off (S5), the module's chipset asserts the 'SUS_S3#' signal. Through the use of an inverter, the low active 'PS_ON#' signal goes high and
switches off the ATX power supply.
When the system is in a power-down system state, any system wake-up event invokes the module's chipset to deassert the 'SUS_S3#' signal.
With the deassertion, the system transitions to 'Full-On' state (S0).
5.2.7

Module Type Detection

The signals TYPE0#, TYPE1#, TYPE2# and TYPE10# indicate the pinout type of the module connected to the carrier board. These pins are either
open (N.C), strapped to ground (GND) or connected to 12 V by the module as shown below.
Table 13 Module Type Detection Pinout Description
TYPE0#
Module Type 1 X (don't care)
Module Type 10 X (don't care)
Module Type 2 N.C
