SPI Flash Header

The conga-MEVAL provides header X20 for connecting SPI flash by default. An optional 8-pin SOIC socket can be provided by request (BOM
option). Use DIP M13 to select the flash device to boot from.
Table 39
X20 - SPI Flash Header
Pin Signal
1
SPI_CS#
3
SPI_MISO
5
SPI_WP
7
GND
Table 40
SW M13 - BIOS Boot Device Selection
SW1
SW2
OFF
OFF
OFF
ON
ON
OFF
ON
ON
Note
Use SPI flash that supports the module's SPI power.
Connector Type
M13: DIP Switch
X20: 1.27 mm, 2 x 4-pin female header (board to board connection)
Copyright © 2022 congatec GmbH
Description
Pin Signal
SPI Chip select
2
SPI data in from carrier board
4
flash to module
SPI write protect
6
Ground
8
Configuration
Boot from on-module firmware (default)
Boot from carrier board SPI Flash (X20)
Not supported
Not supported
Description
SPI_PWR
SPI power source from COM Express module
SPI_HOLD#
Stops serial communication temporary without
device reset
SPI_CLK
SPI clock from module
SPI_MOSI
SPI data out from module to carrier board flash
CET0m10
X20
1
8
4
5
M13
45/58
