Congatec COM Express conga-MEVAL Manual page 18

Pin Row A Pin Row B
A28 (S)ATA_ACT# B28 HDA_SDIN2
A29 HDA_SYNC B29 HDA_SDIN1
A30 HDA_RST# B30 HDA_SDIN0
A31 GND(FIXED) B31 GND(FIXED)
A32 HDA_BITCLK B32 SPKR
A33 HDA_SDOUT B33 I2C_CK
A34 BIOS_DIS0# B34 I2C_DAT
A35 THRMTRIP# B35 THRM#
A36 USB6- B36 USB7-
A37 USB6+ B37 USB7+
A38 USB_6_7_OC# B38 USB_4_5_OC#
A39 USB4- B39 USB5-
A40 USB4+ B40 USB5+
A41 GND(FIXED) B41 GND(FIXED)
A42 USB2- B42 USB3-
A43 USB2+ B43 USB3+
A44 USB_2_3_OC# B44 USB_0_1_OC#
A45 USB0- B45 USB1-
A46 USB0+ B46 USB1+
A47 VCC_RTC B47 ESPI_EN#
A48 RSVD B48 USB0_HOST_PRSNT
A49 GBE0_SDP B49 SYS_RESET#
A50 LPC_SERIRQ B50 CB_RESET#
A51 GND(FIXED) B51 GND(FIXED)
A52 RSVD B52 RSVD
A53 RSVD B53 RSVD
A54 GPI0 B54 GPO1
A55 RSVD B55 RSVD
Note
1. Not supported
2. Assembly option
Copyright © 2022 congatec GmbH
Pin Row A
A83 eDP_AUX+/LVDS_I2C_CK
2 A84 eDP_AUX-/LVDS_I2C_DAT
2 A85 GPI3
A86 RSVD
A87 eDP_HPD
A88 PCIE_CLK_REF+
A89 PCIE_CLK_REF-
A90 GND(FIXED)
A91 SPI_POWER
A92 SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 TPM_PP
A97 TYPE10#
A98 SER0_TX
A99 SER0_RX
A100 GND(FIXED)
A101 SER1_TX/CAN_TX
A102 SER1_RX/CAN_RX
A103 LID#
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND(FIXED)
CET0m10
Pin Row B
B83 eDP/LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 DD0_HPD
B90 GND(FIXED)
B91 DDI0_PAIR5+ 1
B92 DDI0_PAIR5-
1
B93 DDI0_PAIR6+
1
B94 DDI0_PAIR6- 1
B95 DDI0_DDC_AUX_SEL
B96 USB7_HOST_PRSNT
B97 SPI_CS#
B98 DDI0_CTRLCLK_AUX+
B99 DDI0_CTRLDATA_AUX-
B100 GND(FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND(FIXED)
