Recommended settings
Quick Setup "Batching"
HOME position → F → MEASURAND → O → QUICK SETUP → N → QUICK SETUP BATCHING (1005)
Function No. Function name
1005 QUICK SETUP BATCHING/DOSING
!
Note!
Some of the functions listed below (with a gray background) are configured automatically, i.e. by the measuring system.
6400 ASSIGN LOW FLOW CUTOFF
6402 ON-VALUE LOW FLOW CUTOFF
6403 OFF-VALUE LOW FLOW CUTOFF
6603 SYSTEM DAMPING
6404 PRESSURE SHOCK SUPPRESSION
7200 BATCH SELECTOR
7201 BATCH NAME
7202 ASSIGN BATCH VARIABLE
7203 BATCH QUANTITY
7204 FIX COMPENSATION QUANTITY
7208 BATCH STAGES
7209 INPUT FORMAT
4700 ASSIGN RELAY
4780 TERMINAL NUMBER
7220 OPEN VALVE 1
7240 MAXIMUM BATCH TIME
7241 MINIMUM BATCH QUANTITY
7242 MAXIMUM BATCH QUANTITY
2200 ASSIGN (Main line)
2220 ASSIGN (Multiplex main line)
2400 ASSIGN (Additional line)
2420 ASSIGN (Multiplex additional line)
2600 ASSIGN (Information line)
2620 ASSIGN (Multiplex information line)
Back to the HOME position:
→ Press and hold down the X key for longer than three seconds or
→ Repeatedly press and release the X key → Exit the function matrix step by step
Setting to be selected ( P )
(to the next function with F )
YES
After F is pressed by way of confirmation, the
Quick Setup menu calls up all the subsequent
functions in succession.
▼
VOLUME FLOW
The recommended setting is contained on Page 94
in Function No. 6402.
50%
9
!
Note!
The parameter has to be optimized for highly
accurate and short filling processes: to do this, put
the setting to "0".
0 s
BATCH #1
BATCH #1
VOLUME
0
0
1
Value input
BATCHING VALVE 1
Output (display only)
0% or 0 [unit]
0 s (= switched off)
0
0
BATCH NAME
Off
BATCH DOWNWARDS
Off
BATCHING KEYS
Off
▼
