4.8. Video Motion Analyzer

4.8.1.

Overview

MultiLab's Video Motion Analyzer enables you to capture position and time from
video movies, convert this to data sets and analyze the data with all of MultiLab's
analysis tools the same way you would analyze data from the data logger. You can
capture one-body motion or two-body motion. You can select the origin and rotate
the coordinate system.
With the Video Motion Analyzer you can also capture video movies either directly
from video camera connected to the computer or from an external video source such
as VCR.
4.8.2.

Getting started

1.Video Motion Analyzer basics

1. Open Video Motion Analyzer module
Click Video Analysis
2. Open a movie from MultiLab's movie library or capture
new movie
3. Capture position and time
Scaling – scale the video to the real world dimensions
Coordinate system – set origin and axes direction
Step – set the number of frames you will capture position and time
Marking – mark the position of the body on the frames. MultiLab will automatically
convert it to numerical data
4. Analyze the data
The captured data is automatically displayed in the graph and table windows.
Analyze it as you would normally with MultiLab's projects.

2.Saving new movie

1. After you have finished capturing new video movie, click Analyze
movie
2. MultiLab prompts to save the movie
3. Type a name in the File name box and click Save
on the main toolbar
to begin capturing position and time
Chapter 4 Working with a desktop computer 119
