4. External DC power supply socket
Plug in an AC/DC 9-12V adaptor whenever you want to save battery power, or to
charge the battery when necessary. Connecting external power to the MultiLogPRO
automatically charges the internal battery. The adaptor should meet the required
specifications (see section 0).

Battery

MultiLogPRO is equipped with a 7.2V NiCad rechargeable battery. Before you first
start working with MultiLogPRO, charge the unit for 10 to 12 hours while it is turned
off. Battery life is approximately 24 hours between charges.
If the data logger's main battery runs out, the internal 3V Lithium battery backs up
the memory, so no data will be lost.
Note: Before storing the data logger make sure you have unplugged all the sensors
and pressed the OFF key.

AC/DC Adaptor


Output: Capacitor filtered 9 to 12 VDC, 400 mA

Female plug, center Negative

Automatic Shut-off

MultiLogPRO shuts off automatically after 15 minutes have passed since the time of
the last data recording, the time the last button was pressed, or the time the last
communication was made with the computer.

Standalone Operation

One way to program the MultiLogPRO is to use its keypad and screen (the other way
is to use the MultiLab software - see Error! Reference source not found.). The
keypad allows us to set all the parameters for data collection, while the LCD screen
displays the setting values.

Front Panel Layout
