Limitations; Dimensional Drawings - maxon motor EPOS4 Module 50/5 Hardware Reference Manual

Specifications

Limitations

2.2.2
Figure 2-4
2.3 Limitations
Table 2-6
2.4

Dimensional Drawings

Figure 2-5
2-14
Power Dissipation and Efficiency
Power dissipation and efficiency
Protection functionality
Undervoltage
Overvoltage
Overcurrent
Thermal overload
Limitations
EPOS4 Module 50/5 – Dimensional drawing [mm]
© 2018 maxon motor. Subject to change without prior notice.
Switch-off threshold
8.0 V
58 V
20 A
105 °C
Document ID: rel8003
Edition: May 2018
Recovery threshold
EPOS4 Positioning Controller
EPOS4 Module/Compact 50/5 Hardware Reference
8.5 V
56 V
—
90 °C
maxon motor control
