PM0214
4.4.7

Configuration and control register (CCR)

Address offset: 0x14
Reset value: 0x0000 0200
Required privilege: Privileged
The CCR controls entry to Thread mode and enables:
•
The handlers for NMI, hard fault and faults escalated by FAULTMASK to ignore bus
faults
•
Trapping of divide by zero and unaligned accesses
•
Access to the STIR by unprivileged software, see
(NVIC_STIR) on page
31 30 29 28
15 14 13 12
Reserved
Bits 31:10 Reserved, must be kept cleared
Bit 9 STKALIGN
Configures stack alignment on exception entry. On exception entry, the processor uses bit 9 of
the stacked PSR to indicate the stack alignment. On return from the exception it uses this
stacked bit to restore the correct stack alignment.
0: 4-byte aligned
1: 8-byte aligned
Bit 8 BFHFNMIGN
Enables handlers with priority -1 or -2 to ignore data bus faults caused by load and store
instructions. This applies to the hard fault, NMI, and FAULTMASK escalated handlers. Set this
bit to 1 only when the handler and its data are in absolutely safe memory. The normal use of
this bit is to probe system devices and bridges to detect control path problems and fix them.
0: Data bus faults caused by load and store instructions cause a lock-up
1: Handlers running at priority -1 and -2 ignore data bus faults caused by load and store
instructions.
Bits 7:5 Reserved, must be kept cleared
DIV_0_TRP
Bit 4
Enables faulting or halting when the processor executes an SDIV or UDIV instruction with a
divisor of 0:
0: Do not trap divide by 0
1: Trap divide by 0.
When this bit is set to 0, a divide by zero returns a quotient of 0.
216.
27 26 25 24
Reserved
11 10 9 8
STK BFHF
ALIGN NMIGN
rw rw
PM0214 Rev 10
Software trigger interrupt register
23 22 21 20
7 6 5 4
DIV_0_
TRP
Reserved
rw
Core peripherals
19 18 17
3 2 1
NON
UN USER
BASE
ALIGN_ SET
THRD
Res.
TRP MPEND
ENA
rw rw
231/262
16
0
rw
261
