progressively lower in order to avoid motor stalling. If the torque level is reached correctly, it will be
showed on the display and you will hear a beep sound, too.
Such torque level is indicated as " T: ..% " on the main screen.
4) TM Fast Spd (Time Fast Speed): It indicates how long the screwdriver should turn at the FAST SPEED
speed (see point 6) before switching to "pre-set speed" (lower speed). The "pre-set speed" is the speed set at
point 4. This FAST SPEED time can be set from 0.3 to 10.0 sec.
To disable the function press
pre-set speed (see point 6).
CAUTION: The aim of the FAST SPEED is only to speed up the approach time in case of long screws.
Reaching the torque at higher speed will result in inaccurate torque output. To avoid inaccurate torque
values we suggest first to set a shorter time, and then increase it.
Torque reached during the FAST SPEED won't activate the torque signal and the message "Error FAST
SPEED" will be displayed on the main screen and 2 beep sounds. The red led will turn on, too.
5) Fast Spd (Fast Speed): You can select the speed of the screwdriver during the FAST SPEED. It can be
set between max speed and the pre-set one (see point 4).
This function is available only if the Time Fast Speed is active.
- - - - - - - - M E N U - - - - - - - -
6 ) F i n a l
7 ) R u n
8 ) M i n
6) Final Spd (Final Speed): You can select any speed value of the screwdriver between the maximum and
the minimum specific speed of every single screwdriver (see table with technical data).
7) Run time: You can set the time of a tightening, from OFF to 20.0 sec. When the pre-set time has been
reached, it results in a torque signal.
The couple reached during this time results in a signal of Correct screw. If the correct screw signal is not
required, set the Minimum time up to a value of 'Minimum Time -0.1sec'.
ATTENTION: Max Time must be set at 20.0 sec.
8) Min Time - Minimum Time: You can set this time from 0.1 sec to 'Max time - 0.1s'. To disable the
function select OFF by pressing
Torque reached below the minimum time won't activate the torque signal and will result in an error
signal. "Below minimum time" will be displayed on the status bar and the red led will light up. You will
hear two beep sounds, too.
9) Max time - Maximum time: You can select the maximum time of tightening. You can set from 'Min
time + 0.1s' to 20.0 sec.
You also can set the Maximum time to OFF by pressing the
of 20.0s. In this case the screwdriver turns without any time limit.
Vers. 211020
until you get to OFF. In this case the screwdriver will automatically start at
S p d :
t i m e :
t i m e :
as many times as needed. (Min time = 0).
- - - - - - - - M E N U - - - - - - - -
9 ) M a x
t i m e :
1 0 ) A u t o
1 1 ) R e v
6 0 0 r p m
o f f
o f f
2 0 . 0 s
r e v :
t o r q :
button when you have reached the value
o f f
M A X
5
