EDU1AE Ver 1.6 for PLUTO
Torque range: 2 – 15 Nm
IDENTIFICATION DATA OF THE MANUFACTURER
KOLVER S.r.l.
VIA MARCO CORNER, 19/21
36016 THIENE (VI) ITALIA
IDENTIFICATION DATA OF THE PRODUCT
CONTROL UNIT MODEL: EDU 1AE
CODE: 030000
YEAR OF CONSTRUCTION: 2008
TECNICAL DATA OF THE PRODUCT
TRANSFORMER: 230V AC 50 Hz – 40 V DC 200 VA FUSE: 3,15 A
DIMENTIONS: 185x124x95 mm WEIGHT: 2.550 Kg
DECLARATION OF CONFORMITY
KOLVER S.r.l. declares that the new tool here described: Control unit model EDU 1AE is in conformity
with the following standards and other normative documents: 98/37/CE, 89/336/CE and 2006/95/CE,
EN50144-1 and EN60204-1.
It is also in conformity with RoHS and WEEE
normatives.
Thiene, 01/01/08
KOLVER S.r.l.
Advertisement
Related Manuals for Kolver EDU1AE
Summary of Contents for Kolver EDU1AE
- Page 1 DIMENTIONS: 185x124x95 mm WEIGHT: 2.550 Kg DECLARATION OF CONFORMITY KOLVER S.r.l. declares that the new tool here described: Control unit model EDU 1AE is in conformity with the following standards and other normative documents: 98/37/CE, 89/336/CE and 2006/95/CE, EN50144-1 and EN60204-1.
- Page 2 PLUTO10 and PLUTO15 electric screwdrivers either inline, pistol or for automation. EDU1AE and Pluto delivers all the advantages of precision torque control electric tools at a fraction of the price of transdurized tools. The state-of-the-art electronic control circuit cuts the power supply to the motor calculating the correct torque in response to 3 parameters;...
- Page 3 For example, for a Pluto10, a 50% setting on hard joint will result in a torque in the area of 6Nm. Please confirm desired torque value with a Kolver digital torque tester. The torque level is indicated on the main screen by “LEVEL” .
-
Page 4: T I M E : O F F
4) BRAKE TIME: This option can be selected only in combination with the option JOINT: HARD. You can select a time between MIN (function excluded) and 10.0 seconds indicating how long the selected speed (higher speed) will be on before switching to “pre-torque speed” (lower speed). The “pre-torque speed”... - Page 5 I/O CONNECTION On the back panel you’ll find only one connector I/O 10 pins which must be connected to the 90° connector coming from the unit. INPUT: FUNCTION COM 0VDC Common pin. By closing the contact between pin 1 and any of the other pins ( 2, 3, 4, 5) to start the function you need.
-
Page 6: Troubleshooting
IF THE PROBLEM PERSISTS, PLEASE CONTACT YOUR NEAREST KOLVER DEALER. EDU1AE power supply and control unit is a maintenance free unit. Should you need any assistance please call the nearest Kolver dealer in your Country or contact directly Kolver at kolver@kolver.it or call... - Page 7 RIF DESCRIPTION CODE RIF DESCRIPTION CODE Connector 5 PIN M12 M 201666 Plug w/fuseholder 230V 800618 Screw 2,6 x 9,5 (12pcs) 800605 Earth cable 800090 Nut M2,5 h 11 872436 Plug internal cable 800080/N Button for user interface 872437 Back panel 832414 Rubber support (4pcs) 800016...
