27) Ins. barcode:
to scan a barcode and recall the desired program. To be used in combination with option
4. of the Sequence Menu.
IMPORTANT: Barcode can be ONLY numeric.
28) Serial PRT:
Serial print: from OFF to 5.
When OFF, no print.
If it is set up to 5, this value identifies the number of line feeds between a string and another.
THE FOLLOWING MENU IS AVAILABLE ON T&A VERSION ONLY
- - - - - M E N U - - P R : 1 - - - - -
2 9 ) F u n c
3 0 ) S t a r t i n g
3 1 ) A n g .
29) Func T&A–T&A function mode:
you don't need this function. When you set ON you can choose among six working conditions (see T&A
specific instructions).
30) Starting Tor – Starting torque:
set the torque threshold the angle starts to be read from. When T&A is set on angle mode (see T&A
paragraph), you can set the torque threshold the angle starts to be carried out from.
31) Ang. min – Minimum angle:
or T/lv (see T&A specific instructions). The minimum angle the operator can set is 5°.
- - - - - M E N U - - P R : 1 - - - - -
3 1 ) A n g .
3 2 ) A n g .
32) Ang. max - Maximum angle:
T/in or T/lv (see T&A specific instructions). The maximum angle the operator can set is 29999°.
When T&A is set on Ang., A/in or A/lv mode, maximum angle corresponds to the angle that has to be
carried out.
