SPARE PARTS
Position
1
Screw M3x5 TX10
2
Upper panel 2AE
3
Main PCB
4
Switching 48V 600W
5
Spacer 15mm - 4,8 mm
6
Washer M3 h0,5 mm
7
Ground cable
8
Ferrite
9
M3 Brass nut
10
Front membrane EDU 2AE
11
Front panel EDU2AE
12
Connector M12 5 pin + nut + ferrite
13
Display EDU2AE
14
Zn-white nut M3
15
Washer M3
16
Plastic support
17
Bottom panel
18
Flat 10 vie
19
Fuse 3.15A
20
Connector I/O 10 pin spacing 3,81
21
Filtered plug
22
Board support
Label
Vers. 211020
Description
EDU2AE/SW
Quantity
Code
17
872444
1
819003
1
852521/SW
1
872490
4
890004/T
4
800042
1
800090/E
1
872468
2
800056/O
1
858004
1
818002
1
201666/R1
1
852522
7
800056
5
800041
4
800016/B
1
818001/SW
1
872438
2
800619
1
800102
1
800718
2
872442
1
818006/SW
19
