EDU 2AE/FR power supply and control unit is an innovative system for controlling the torque of any clutch
model of PLUTO clutch series: PLUTO 3FR/HS, PLUTO 5FR and PLUTO 7FR. Of FAB series: FAB03,
FAB10, FAB12 and FAB18. And of RAF series: RAF32, RAF38 and RAF50.
They are available either inline, pistol, for automation and with angle head (only PLUTO).
EDU 2AE/FR delivers all the advantages of precision torque control electric tools at a fraction of the price
of transdurized tools.
The state-of-the-art electronic control circuit cuts the power supply to the motor calculating the correct
torque in response to 3 parameters; voltage, frequency and current, according to the selected options.
The AC 90÷260V - 50÷60Hz power supply is converted into 40VDC required by the PLUTO series
screwdrivers through a switching board.
Turn the unit on through the on/off switch on the back panel. The unit will carry a general system check and
"waiting connection" will appear on the last line of the display. If the connection with the motor control
board is successful the following screen will be displayed:
Vers. 210920
Model
Torque (Nm)
PLUTO 3FR/HS
0,5-2,5
PLUTO 5FR
PLUTO 7FR
FAB03
0,05 - 0,3
FAB10
0,05 - 0,8
FAB12
0,2 - 1,2
FAB18
0,3 - 1,8
RAF32
0,7 - 3,2
RAF38
0,9 - 3,8
RAF50
K o l v e r
E D U
V e r s i o n
l o a d i n g . . .
Speed (rpm)
Min
Max
1550
2400
0,7 - 5
600
1000
1,5 - 7
350
450
600
1000
600
1000
450
600
1000
450
0,9 - 5
400
S . r . l .
2 A E / F R
2 . 0 0
Giovanni Colasante
600
650
650
650
700
2
