4.9 Unsupervised Disconnect

When using analog trunks, various methods are used for trunk supervision, ie. to detect when the far end of the trunk
has disconnected and so disconnect the local end of the call. Depending on the locale, the system uses Disconnect Clear
signalling and or Busy Tone Detection. This setting should only be enabled if it is know that the analog trunks do not
provide disconnect clear signalling or reliable busy tone. When enabled:
·
Disconnect clear signalling detection is turned off. Busy tone detection remains on.
·
Unsupervised transfers and trunk-to-trunk transfers of analog trunk calls are not allowed.
·
A wider range of busy tones which may signal the caller has disconnected are used to disconnect calls connected to
voicemail.
·
This procedure is not listed when using the Next Procedure or Previous Procedure buttons to select a
procedure.
1408/1416/9504/9508 Phone
1. At either of the first two extensions on the system, press Admin.
·
To do the above during a call, you may need to press the
option. If you access phone administration during a call, only the
buttons still affect the connected call.
2. Use the up or down
Select.
3. Use the up or down
Select.
·
Alternatively, dial # and the
3. Use the up or down
Select.
4. Enter 1 or 2. The default is 2 (not active), ie. use supervised disconnection.
·
1 = Active/Assigned.
·
2 = Not Active/Not Assigned (the default setting).
·
Alternatively use the
default setting.
·
1 = Active/Assigned.
·
2 = Not Active/Not Assigned (the default setting).
5. The change requires the system to be rebooted. At the Immed Reboot? prompt, press OK to reboot or Cancel
to cancel.
M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #129. Unsup Discnct: and the current setting are displayed:
4. Enter the required value. The default is 2 (not active), ie. use supervised disconnection.
·
1 = Active/Assigned.
·
2 = Not Active/Not Assigned (the default setting).
·
Alternatively use the Next Data or Previous Data buttons to change the setting or press Remove to return
to the default setting.
5. The change requires the system to be rebooted. At the Immed Reboot? prompt, press Enter to reboot or
Remove to cancel.
ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #129. Unsup Disconnect: and the current setting are displayed:
Phone Based Administration
IP Office Basic Edition
arrow buttons to scroll the display to System Administration. When highlighted, press
arrow buttons to scroll the display to System Parameters. When highlighted, press
system administration
arrow buttons to scroll the display to Unsup Disconnect. When highlighted, press
left or right arrow icons to toggle through the settings or Default to return to the
system password set, it is requested. Enter the password.
