Avaya IP Office Basic Edition Manual page 143

ETR 18D/ETR 34D Phone
1. Do one of the following:
To program the same extension
a. At the phone, press Feature 00.
b. Program Extension: is shown on the
display.
2. Press Feature and the speed dial number to be programmed between 80 and 99.
3. The current setting of the speed dial entry is displayed.
4. Enter the external number. The number can be up to 28 characters in length. The following keys can be used to
enter special dialing commands:
Function Press to insert
Pause HOLD
Transfer SPEAKER
Stop CONFERENCE
·
On 9500 Series phones, these options are accessed by pressing More and select Pause, Stop or Recall as
required.
5. To remove the existing number press MIC/HFAI.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
To program another extension
a. At either of the first two extensions on the system, press Feature
00 followed by two presses the first intercom or call appearance
button and one press of the second intercom or call appearance
button. Centralized Programming: is shown on the display.
b. At the Extension: prompt enter the number of the extension.
Character
P
R
S
Comments on this document? infodev@avaya.com
Speed Dials: Personal Speed Dials
Description
Inserts a 1.5 second pause.
Send a hook-switch flash signal.
Stop dialing.
- Issue 6a (Thursday, February 22, 2018)
Page 143
