Button Numbering
The diagram below indicates the button functions during normal phone operation. The double digit numbers are the
button numbering for programmable buttons.
SK1
Release
1
4
7
*
–
Mute
·
For systems running in key system mode, the first two programmable buttons, 01 and 02, are fixed as Intercom
1 and Intercom 2 buttons. Buttons 16 downward are assigned as line buttons, starting from the first line, based
on the Number of Lines
·
For systems running in PBX system mode, the first three buttons, 01 to 03, are fixed as call appearance buttons.
Administration Mode Buttons
The diagram below indicates the button functions during phone based administration processes.
Pause
Release
1
4
7
*
–
Mute
Phone Based Administration
IP Office Basic Edition
Display
SK2 SK3
2 3
5 6
8 9
0 #
Volume +
Speaker Headset
75
setting or the number of analog trunks installed in the system.
Display
Recall Stop
2 3
5 6
8 9
0 #
Volume +
Speaker Headset
