8.3 Loudspeaker Extension

Loudspeaker paging systems allow you to broadcast a message over a large area. Use this feature to specify the
extension port to which you connected the loudspeaker paging system.
The extension is used by the
1408/1416/9504/9508 Phone
1. At either of the first two extensions on the system, press Admin.
·
To do the above during a call, you may need to press the
option. If you access phone administration during a call, only the
buttons still affect the connected call.
2. Use the up or down
Select.
3. Use the up or down
Select.
·
Alternatively, dial # and the
4. Use the up or down
press Select.
5. Enter the extension number of the extension port connected to the loudspeaker paging system or Clear to return
to the default setting (no loudspeaker).
·
Exit programming by pressing
M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #617. The phone displays Loudspeaker Paging Ext.
4. Enter the extension number and then press Enter.
·
Alternatively use the Next Data or Previous Data buttons to change the setting or press Remove to return
to the default setting.
·
To exit phone based administration at any time, press the Release button. To select a different process use the
Next Procedure or Previous Procedure buttons or dial another feature code.
ETR 18D/ETR 34D Phone
1. At either or the first two extensions on the system, press Feature 0 0 followed by two presses of the first
intercom or call appearance button.
2. System Administration: is shown on the display.
3. Dial #617. The phone displays Loudspeaker Paging Ext.
4. Enter the extension number and then press Enter.
·
Alternatively use the Next Data or Previous Data buttons to change the setting or press Remove to return
to the default setting.
·
Exit programming by pressing Feature 00. You can also exit programming mode by lifting the handset, then
placing it back in the cradle.
Phone Based Administration
IP Office Basic Edition
Loudspeaker Page and
269
arrow buttons to scroll the display to System Administration. When highlighted, press
arrow buttons to scroll the display to Auxiliary Equipment. When highlighted, press
system administration
arrow buttons to scroll the display to Loudspeaker Paging Ext. When highlighted,
PHONE. Alternatively use the Back button to move to another menu.
system password set, it is requested. Enter the password.
114
Comments on this document? infodev@avaya.com
Simultaneous Page functions.
283
PHONE button to display the Admin soft key
SPEAKER,
10 code.
Feature **config (ie. Feature **266344).
MUTE and HEADSET
