14.10 Transfer Return Extension
This option is new for IP Office Basic Edition 6.1 and higher+. This settings can be used to change the destination for an
extension's
transfer return calls
·
The existing extension setting
return to it. The Transfer Return Extension setting allows such calls to be redirected.
·
Note that if a door phone or paging extension is selected, the call will continue ringing at the transfer destination
rather than returning.
·
When a call is routed to an extension by transfer return, it alerts with the Transfer Return ringing pattern. The
display indicates both the transferred caller's details and the original transfer destination.
·
If a phantom extension, door extension or paging extension is set as the transfer return destination, transferred
calls will not follow transfer return and instead will continue ringing at the transfer destination.
·
Calls transferred by an auto attendant are not subject to transfer return.
·
When the transfer return extension has no available intercom buttons, the call will continue to alert at the original
transfer destination until the transfer return extension becomes available at which time the transfer return will
occur. This also applies for a busy analog extension or an extension in programming mode.
·
When an external call follows transfer return and there is a line appearance for the call, it alerts on the line
appearance. If there is no line appearance the call shall alert on an intercom button.
·
When an internal call follows transfer return, it alerts on an intercom button.
·
If a call is transferred to an extension which is the transfer return destination for the transferring extension, the
call remains ringing at the transfer destination.
·
Transfer return calls ignore Do Not Disturb, call forwarding, call coverage and coverage to voicemail.
·
Transfer return calls that are answered at the return extension are not logged even if the Called ID log answered
calls is set to Active.
1408/1416/9504/9508 Phone
1. At either of the first two extensions on the system, press Admin.
·
To do the above during a call, you may need to press the
option. If you access phone administration during a call, only the
buttons still affect the connected call.
2. Use the
up or down
Select.
3. Use the
up or down
4. Use the
up or down
Select.
5. At the Extension: prompt enter the extension you want to edit.
6. The current setting is displayed.
7. Enter the target extension number for transfer returns of calls transferred by the extension. The default is the
same extension.
8. Use the
up or down
·
Exit programming by pressing
M7324/M7324N/M7310/M7310N/T7316/T7316E Phone
1. At either of the first two extensions on the system, press
·
If the system has a
2. The phone displays System Admin.
3. Dial #306. The phone displays Transfer Return Ext.
4. At the Extension: prompt, enter the number of the extension to be programmed.
5. Enter the target extension number for transfer returns of calls transferred by the extension. The default is the
same extension.
·
Alternatively use the Next Data or Previous Data buttons to change the setting or press Remove to return
to the default setting.
Phone Based Administration
IP Office Basic Edition
.
211
Transfer Return Rings
arrow buttons to scroll the display to System Administration. When highlighted, press
arrow buttons to scroll the display to Extensions. When highlighted, press Select.
arrow buttons to scroll the display to Transfer Return Ext. When highlighted, press
arrow buttons to select another extension to adjust if required.
PHONE. Alternatively use the Back button to move to another menu.
system password
set, it is requested. Enter the password.
114
Comments on this document? infodev@avaya.com
sets whether and when calls transferred by an extension
211
PHONE button to display the Admin soft key
SPEAKER,
Feature **config (ie. Feature **266344).
- Issue 6a (Thursday, February 22, 2018)
Ring Settings: Transfer Return Rings
MUTE and
HEADSET
