Avaya Solution & Interoperability Test Lab
Application Notes for Valcom One-Way IP Speakers with
Avaya IP Office – Issue 1.0
These Application Notes describe the configuration steps required for the Valcom One-Way IP
Speaker devices to successfully interoperate with Avaya IP Office. The Valcom One-Way IP
Speakers are SIP-based devices that integrate with Avaya IP Office as a SIP endpoint.
Information in these Application Notes has been obtained through DevConnect compliance
testing and additional technical discussions. Testing was conducted via the DevConnect
Program at the Avaya Solution and Interoperability Test Lab.
MJH; Reviewed:
SPOC 2/8/2011
Abstract
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
1 of 17
Valcom-1Way-IPO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP Office and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avaya IP Office

Summary of Contents for Avaya IP Office

  • Page 1 These Application Notes describe the configuration steps required for the Valcom One-Way IP Speaker devices to successfully interoperate with Avaya IP Office. The Valcom One-Way IP Speakers are SIP-based devices that integrate with Avaya IP Office as a SIP endpoint. Information in these Application Notes has been obtained through DevConnect compliance testing and additional technical discussions.
  • Page 2 Speakers to successfully interoperate with Avaya IP Office. The Valcom One-Way Speakers enable voice access to a single zone of one-way paging over an IP-based LAN/WAN. The Speakers are SIP-based devices that integrate with Avaya IP Office as a SIP endpoint. The following Valcom One-Way IP Speaker was compliance tested: ...

  • Page 3: Reference Configuration

    The Valcom One-Way IP Speaker was configured as a SIP endpoint that registered with Avaya IP Office. When a call is placed to the Valcom One-Way IP Speaker, the device automatically answers the call and provides one-way communication to the device.

  • Page 4: Equipment And Software Validated

    The following equipment and software were used for the sample configuration provided: Equipment Software Avaya IP Office 500 6.0 (8) Avaya IP Office 500 Phone Expansion 6.0 (8) Module Analog POTS 30 V2 Avaya IP Office Manager (Windows PC) 8.0 (8) Avaya 5610SW IP Telephone (H.323)
  • Page 5 This section describes the steps required to configure SIP extensions and users on IP Office. IP Office is configured via the IP Office Manager program. Log into the IP Office Manager PC and select Start  Programs  IP Office  Manager to launch the Manager application.
  • Page 6 On the VoIP tab, select G.711 ULAW 64K for Compression Mode and RFC2833 for DTMF Support. Click the OK button on the bottom of the screen (not shown). MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 6 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...

  • Page 7: Administer Users

    Administer Users Create a user for the Valcom One-Way IP Speaker. Right-click User from the left panel and select New. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 7 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 8 Enter a desired name.  Full Name Enter a descriptive name.  Extension Enter the extension configured in Section 4.1. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 8 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 9 Click the OK button on the bottom of the screen. After making the changes, click File  Save Configuration to push the changes to the IP Office system and have them take effect. Changes will not take effect until this step is completed.
  • Page 10 IP Solutions Setup Tool screen is displayed. Retain the default values and click OK to scan for Valcom devices. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 10 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 11 At the conclusion of the scan, the VIP-102B IP Solutions Setup Tool screen is updated with the discovered Valcom One-Way IP Speakers as shown below. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 11 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 12 Properties tab, and enter a descriptive Device Name. Select the appropriate time zone in the Offset From UTC field, and enter any desired Comments. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 12 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 13 Select the Network tab. Enter the proper values for Static IP Address, Subnet Mask, and Gateway IP Address fields for the network configuration. The default values in the remaining fields may be retained. MJH; Reviewed: Solution & Interoperability Test Lab Application Notes 13 of 17 SPOC 2/8/2011 ©2011 Avaya Inc. All Rights Reserved. Valcom-1Way-IPO...
  • Page 14  Authentication Name: Enter the “Name” from Section 4.2.  Secret: Enter the “Login Code” from Section 4.2.  SIP Server: Enter the IP address of Avaya IP Office.  Register: Check this field.  CID Name: Enter a descriptive name.
  • Page 15 The serviceability test cases were performed manually by disconnecting and reconnecting the LAN cables to the Valcom One-Way IP Speakers. Additionally, the Avaya IP Office server was rebooted to verify the Valcom One-Way IP Speaker was able to properly register and function normally after the server recovered.

  • Page 16: Verification Steps

    7. Verification Steps This section provides the tests that can be performed to verify proper configuration of Avaya IP Office and the Valcom One-Way IP Speaker. 7.1. Verify Valcom One-Way IP Speakers Place a call to the Valcom One-Way IP Speaker and verify that the call is connected with a one- way talk path.
  • Page 17 2011 Avaya Inc. All Rights Reserved. © Avaya and the Avaya Logo are trademarks of Avaya Inc. All trademarks identified by ® and ™ are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. The information provided in these Application Notes is subject to change without notice.
