B&R Automation PC 2200 User Manual page 71

2.3.4.1.3.4 X2X Link master interface - Pinout
The X2X Link master interface on the system unit is referred to as "IF option".
The electrically isolated X2X Link master interface is designed as a 10-pin female con-
nector.
Pin
1
2
3
4
5
6
7
8
9
10
1) The interfaces, etc. available on the device or module have been numbered for the purpose of clear differentiation. This numbering may deviate from the
numbering used by the respective operating system, however.
2) This interface can only be used in Automation Runtime and is displayed as IF2 in Automation Studio / Automation Runtime. It is not a "PC interface" and
therefore not displayed in BIOS.
2.3.4.1.3.5 Shielding
For the interfaces on the 10-pin female connector, the shield of the interfaces can be connected to pin "Shield"
of the female connector.
In addition, there is a functional ground connection on the the interface cover of the system unit and a screw point
for cable shields that can also be used for the shielded cables.
2.3.4.1.3.6 LED status indicators L1, L2, L3
The LEDs of the interface option are located near the ETH1 interface.
LED Color Status
L1 Yellow On
Off
L2 Green On
Blinking
L3 Green-Red On
Off
Status/Error LED
The status/error LED is designed as a green and red dual LED. The LED statuses have a different meaning
depending on the operating mode.
Ethernet mode
In this mode, the interface is operated as an Ethernet interface.
Color green - Status
On
Automation PC 2200 User's manual V 1.05 Translation of the original documentation
X2X Link master
Pinout
X2X H
Shield
X2X L
X2X GND
-
-
-
-
-
-
Table 63: 5ACCIF01.FPCC-000 - X2X Link Master interface
LED status indicators
Explanation
The CAN bus 1 terminating resistor is switched
on.
The CAN bus 1 terminating resistor is switched
off.
POWERLINK link LED
A connection to a POWERLINK network exists.
POWERLINK link LED
Data is being transferred.
POWERLINK status/error LED
See "Status/Error LED".
POWERLINK status/error LED
See "Status/Error LED".
Table 64: 5ACCIF01.FPCC-000 - LED status indicators
Description
The interface is operated as an Ethernet interface.
Table 65: Status/Error LED - Ethernet mode
1)2)
10-pin, male
1 3
2 4
Technical data
5 7 9
6 8 10
