Technical data

2 Technical data

2.1 Introduction

2.1.1 Information about this user's manual

This user's manual contains all the necessary information for a functioning Automation PC 2200 built-in device.

2.1.2 Maximum performance in minimum space

The control cabinet variant of the Automation PC 2200 offers a fully-fledged PC system with a minimum size.
The PC design is based on Intel's Apollo Lake architecture, which with dual-core and even quad-core processors
represents a milestone in the field of embedded systems – and at an optimal price/performance ratio.

2.1.3 Communicative in all directions

All important interfaces are integrated in the Automation PC 2200. These include 2x Gigabit Ethernet and 2x USB
3.0. In addition, fieldbuses such as POWERLINK and CAN can be implemented via modular interface modules.
The compact CFast card is used as the data storage medium, which is also available with 60 GB or more and
based on MLC technology.

2.1.4 Best graphics performance

The graphics engine of the Intel Atom processors is derived from the Core i processors and offers powerful graphics
processing. It supports DirectX 12 for the first time in this segment, which is now used in many SCADA systems
with sophisticated graphics. On the display side, all resolutions and diagonals up to 24.0" Full HD are supported.
