76/92 Maintenance and repair

10.6 Spare parts

The following table gives an overview of the spare parts that can be ordered. The table is divided
into three columns. The first column contains the Rexroth material number of the complete
component, e.g. R961002474 - Hydraulic hose line length 630 mm with two coupling sockets.
This material number is specified on the name plate (see chap. 5.9). The second column contains
the Rexroth material number of the spare part, in the example of R961002474 this would e.g. be
the spare part material number R900087365 (without coupling sockets). The third column
contains the material short text belonging to the spare part material number, e.g. for
R900087365 - SCHLAUCH AB23-14/2SC-08/N10-N10X.630.
Table 32: Spare part for hydraulic hose line at the hydraulic power unit of the WS200 work station
(identical spare part for pressure and tank line, see fig. 6:)
Material number
component
Table 33: Spare parts for hydraulic hose lines of the training components
Material number
component
R961002471
R961002472
R961002474
R961002481
R961006552
R961002475
R961002476
R961002473
R961002482
R961002478
R961002480
R961002477
R961002479
Table 34: Spare parts for hydraulic couplings (chap. 9.6)
Material number
component
-
Installed in
hydraulic
hose lines
The R96100481 coupling socket has the same function as the R961000480 coupling socket; only
the connection thread is G 1/4. This coupling socket is used for the assembly in plates. And apart
from that in training components such as check valves, pressure relief valves and
hydraulic distributors.
Bosch Rexroth AG, WS200, DCA_DE_000151/10-2013
Material number Material short text
spare part spare part
R900087365 SCHLAUCH AB23-14/2SC-08/N10-N10X.630
Material number Material short text
spare part spare part
R900087365 SCHLAUCH AB23-14/2SC-08/N10-N10X.630
R900205237 SCHLAUCH AB23-14/2SC-08/N10-N10X1000
R900988933 SCHLAUCH AB23-14/2SC-08/N10-N10X1500
R901059828 SCHLAUCH AB23-14/2SC-08/N10-N10X2000
R901264355 SCHLAUCH AB23-14/2SC-08/L10-N10X2000
R901264254 SCHLAUCH AB23-14/2SC-08/N10-N10X2500
Material number Material short text
spare part spare part
R961000482 KUPPLUNGSSTECKER FF-005-2-XX014-AAAF &
R961000480 KUPPLUNGSMUFFE 1-15-005-0-XX010-AAA&
R961000481 KUPPLUNGSMUFFE 1-15-005-0-L1016 &
