Table 24: Scope of delivery - accessory set 1
Pos. no. Quantity
a 1x
b 1x
c 4x
d 4x
e 2x
f 2x
Mount the vibration dampers (fig. 37. -c) at the cross member of the base frame first.
For the generator set assembly, you need a support plate which is at least 5 mm strong.
The support plate must be level and be able to bear the weight (approx. 18 kg) of the
hydraulic power unit. Put the hydraulic power unit onto the support plate first. Then, you
can fasten the hydraulic power unit at the cross member of the base frame according
to fig. 37. After the assembly, remove the support plate again.
The P/T distributor is attached according to the instructions in chap. 7.4.2. The description
for the connection of the hydraulic hose lines is contained in chap. 7.6.
Assembly of the WS200 work station
Denomination
Hydraulic power unit with control box
P/T distributor
Vibration damper
Washers
Hexagon socket head cap screws M10
Hydraulic hose line
