7.4.5 Grid frame
Table 16: Material numbers for the assembly of the grid frame mounting kit
Pos. no.
Material number
1
R961008677
2
R961008668
Fig. 30: Assembly of the grid frame mounting kit
Table 17: Scope of delivery - mounting kit
Pos. no.
Quantity
1
1x
Assembly of the WS200 work station
Material short text
BEFESTIGUNGSSATZ TS-WS200
GRUNDGESTELL TS-WS200
Denomination
Grid frame mounting kit
DCA_DE_000151/10-2013, WS200, Bosch Rexroth AG
43/92
