Bosch Rexroth WS200 Operating Instructions Manual page 55

Table 28: Scope of delivery - accessory set 3
Pos. no. Quantity
a 2x
b 2x
c 8x
d 8x
e 4x
f 1x
g 2x
h 4x
For better clearness, fig. 39 shows the assembly of only one hydraulic power unit.
Assembly of the second hydraulic power unit is identical to that of the first one.
Mount all vibration dampers (fig. 39. -c) at the cross member (fig. 39. -f) first. Then the two
hydraulic power units are fastened at the prepared cross member according to fig. 39.
The cross member with the two hydraulic power units is assembled at the base frame
according to the instructions in chap. 7.4.4. Installation of the two P/T distributors
according to the instructions in chap. 7.4.2. The description for the connection of
the hydraulic hose lines is contained in chap. 7.6.
Assembly of the WS200 work station
Denomination
Hydraulic power unit with control box
P/T distributor
Vibration damper
Washers
Hexagon socket head cap screws M10
Cross member
Mounting bracket
Hydraulic hose line
DCA_DE_000151/10-2013, WS200, Bosch Rexroth AG
55/92
