Base frame
Fig. 24: Base frame assembly
Table 9: Scope of delivery - base frame
Pos. no.
Quantity
Denomination
1
1x
Member profile 45x45x710
2
2x
Member profile 45x45x1682 with pre-assembled angle set
3
1x
Pre-assembled oil pan
4
4x
Mounting set
Assembly of the WS200 work station
DCA_DE_000151/10-2013, WS200, Bosch Rexroth AG
37/92
