Fig. 32: Assembly of the grid frame mounting set
Table 19: Scope of delivery - grid frame – part 2
Pos. no.
Quantity
1
1x
2
1x
Screw the sliding blocks onto the star handle screw with 2 rotations.
Assembly of the WS200 work station
Denomination
Grid frame clamping set
Grid
DCA_DE_000151/10-2013, WS200, Bosch Rexroth AG
45/92
