Alcatel-Lucent 1850

Transport Service Switch (TSS-60) | Release 2.0

Installation and System Turn-Up Guide

365-372-603R2.0

CC109696583

ISSUE 1

JANUARY 2009

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the 1850 TSS-60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alcatel-Lucent 1850 TSS-60

Page 1 Alcatel-Lucent 1850 Transport Service Switch (TSS-60) | Release 2.0 Installation and System Turn-Up Guide 365-372-603R2.0 CC109696583 ISSUE 1 JANUARY 2009...
Page 2 In rare instances, unauthorized individuals make connections to the telecommunications network through the use of access features. In such an event, applicable tariffs require that the customer pay all network charges for traffic. Alcatel-Lucent and its predecessors cannot be responsible for such charges and will not make any allowance or give any credit for charges that result from unauthorized access.
Page 3: Table Of Contents
Recycling/take-back/disposal of product ....................xvii Safety Laser safety ............................... 1-2 Electrostatic discharge ESD considerations ....................1-5 Laser product classification ........................1-10 Alcatel-Lucent 1850 TSS-60 optical specifications ................1-12 Part I: Physical and power installation Physical installation Planning ..............................2-2 Inspection ..............................2-6 Alcatel-Lucent 1850 TSS-60 center divider ....................
Page 4 Stand-alone node setup Software installation ..........................5-3 Circuit pack installation ..........................5-4 ® Use of WaveStar CIT software ........................ 5-8 Circuit pack program version verification ....................5-12 Alcatel-Lucent 1850 TSS-60 shelf initialization ..................5-14 .................................................... 365-372-603R2.0 Issue 1 January 2009...
Page 5 Contents .................................................... Stand-alone installation testing LBO software settings ..........................6-5 Clearing alarms ............................6-8 Local equipment and cross-connect tests ....................6-10 DS1/E1 testing ............................6-11 DS3/EC1 testing ............................6-17 LNW74 and LNW66 testing ........................6-24 OC-3 low-speed testing ........................... 6-28 OC-12 low-speed testing .........................
Page 6 Contents .................................................... Part IV: Miscellaneous detailed installation procedure and reference material Technical support Technical assistance ..........................A-2 Accessing and navigating the On-Line Customer Support (OLCS) web site ...........A-7 Other technical support services ......................A-12 Fiber cleaning Equipment requirements and recommendations ..................B-3 Safety instructions .............................B-4 Cleaning/inspecting optical connectors ....................B-5 Cleaning pluggable optics module ......................B-11 PTM installation...
Page 7 DS1 and DS3 hybrid cable routing ................... 3-36 3-10 10/100BASE-T/TX cable connections ..................3-43 3-11 10/100BASE-T cable routing ..................... 3-43 3-12 IAO LAN/TCP-IP cable connection to rear of Alcatel-Lucent 1850 TSS-60 ......3-47 3-13 Modem cable connection ......................3-50 3-14 Sync cable connections ......................3-53 3-15 Office alarm cable connections ....................
Page 8 Miscellaneous discrete cable routing ..................3-62 3-19 Optical fiber routing ........................3-67 Circuit pack installation Power connections on Alcatel-Lucent 1850 TSS-60 backplane ..........4-4 Alcatel-Lucent 1850 TSS-60 shelf ....................4-9 Stand-alone installation testing Alcatel-Lucent 1850 TSS-60 shelf backplane ................6-58 Miscellaneous (environmental) discrete functions ..............
Page 9 List of tables Safety Laser classes ..........................1-11 Alcatel-Lucent 1850 TSS-60 optical circuit pack laser safety specifications ......1-12 Alcatel-Lucent 1850 TSS-60 optical PTM laser safety specifications ........1-13 Dispersion-limited receiver sensitivity for OC-192 DWDM PTMs .......... 1-20 Physical installation Cable requirements and options ....................
Page 10 Standard CIT cable connection ....................3-74 3-25 RJ-45 to DB-9 connector connections ..................3-74 Circuit pack installation Alcatel-Lucent 1850 TSS-60 shelf power supply requirements ..........4-3 Release 2.0 circuit pack slot compatibility .................. 4-7 Stand-alone installation testing Office alarm connections ......................6-44 Miscellaneous (environmental) discrete telemetry connections ..........
Page 11: About This Document
Intended audience This installation manual is intended to provide individuals and customers the information and procedures necessary to install, self-test and turn up the Alcatel-Lucent 1850 TSS-60 system. This manual is not a service or operations manual. Refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-60), Release 2.0 User Provisioning Guide, 365-372-601R2.0, for any...
Page 12: How To Use This Document
Part I covers Chapters 2, 3, and 4. These sections covers the physical mounting of the Alcatel-Lucent 1850 TSS-60 shelf using the Horizontal Bay Mount. This section includes the running and connecting of power cables, interconnecting cables, alarm cables, and as required, external timing, communication cables, and covers initial circuit pack installation (not seated).
Page 13 (GUI) or Craft Interface Terminal (CIT) software installation and turn-up testing on a new Alcatel-Lucent 1850 TSS-60 shelf. It is intended to verify correct electrical DS1/DS3/FE cable wiring to the DSX panel or punch down block as well SONET fiber routing to the LGX panel from the faceplates of installed packs.
Page 14: Safety Information
Adhere to the following safety precautions: Electrostatic discharge (ESD) • You must be properly grounded when making contact with the Alcatel-Lucent 1850 TSS-60 frame and handling circuit packs, disk drives, and tapes. Wrist strap ground cords should be routinely tested for the minimum 1-megohm resistance.
Page 15: Conventions Used
.................................................... Plug-in storage • Circuit packs should be stored in static-safe packaging or in a grounded cabinet. For additional safety precautions, please see the Alcatel-Lucent 1850 Transport Service Switch (TSS-60), Release 2.0 User Provisioning Guide, 365-325-601R2.0. CAUTION Laser Safety When connecting fiber loops between the IN and OUT ports on optical circuit packs, always connect to the IN port first and then the OUT port.
Page 16: Document Support
The referral number is 1 (888) 727-3615 (continental United States) or +1 (630) 713-5000 (for all countries). Technical support For technical support, contact your local Alcatel-Lucent customer support team. See the Alcatel-Lucent Support web site (http://www.alcatel-lucent.com/support) for contact information. For more information, refer to Appendix A, “Technical...
Page 17: Packaging Collection And Recovery Requirements
Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel-Lucent products at the end of their useful life. Alcatel-Lucent will also offer to provide for the collection and treatment of existing products displaced by Alcatel-Lucent equipment.
Page 18 About this document ......................................................................................................x v i i i 365-372-603R2.0 Issue 1 January 2009...
Page 19 Safety Overview Purpose This chapter provides important safety instructions for the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60). Contents This appendix provides information on the following topics: Laser safety Electrostatic discharge ESD considerations Laser product classification 1-10 Alcatel-Lucent 1850 TSS-60 optical specifications 1-12 ....................................................
Page 20: Safety
Laser safety System design The Alcatel-Lucent system complies with FDA/CDRH 21 CFR 1040.10 and 1040.11 as a Class I and with IEC 60825-1 as a Class 1 Optical Fiber Telecommunication laser product. The system has been designed to ensure that the operating personnel is not endangered by laser radiation during normal system operation.
Page 21: Safety
Safety Laser safety .................................................... Laser warning labels The laser warning labels indicate either only the laser class or both the laser class and the maximum output power of laser radiation. The following figure shows different types of laser warning labels and their characteristics. CLASS 1 LASER HAZARD PRODUCT...
Page 22: Safety Laser Safety
Safety Laser safety .................................................... Laser safety instructions Observe the following instructions to avoid exposing yourself and others to risk. Read the relevant descriptions in the manuals before taking equipment into operation • or carrying out any installation and maintenance work on the optical port units, and follow the instructions.
Page 23: Electrostatic Discharge Esd Considerations
Safety Electrostatic discharge ESD considerations .................................................... Electrostatic discharge ESD considerations ESD precautions CAUTION ESD hazard Industry experience has shown that all integrated circuit packs can be damaged by static electricity that builds up on work surfaces and personnel. The static charges are produced by various charging effects of movement and contact with other objects.
Page 24 Safety Electrostatic discharge ESD considerations .................................................... for connection of wrist straps are located at the lower right-hand corner of each assembly and are labeled. When grounding jacks are not provided, an alligator clip adapter enables connection to bay frame ground. Figure 1-1 Static control wrist strap GROUND CONNECTION...
Page 25 4. Connect this product only to the type of power sources recommended by Alcatel-Lucent. For information on the powering instructions, consult the Installation Manual. 5. This equipment is suitable for mounting on a concrete or other noncombustible surface only.
Page 26 Incorrect reassembly can cause electrical shock when the unit is subsequently used. 19. Some of the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) hardware modules contain FDA/CDRH Class I/IEC Class 1 single-mode laser products that are enclosed lightwave transmission systems.
Page 27 Safety Electrostatic discharge ESD considerations .................................................... This Equipment is to be Installed Only in Restricted Access Areas on Business and • Customer Premises Applications in Accordance with Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA No. 70. Other Installations Exempt from the Enforcement of the National Electrical Code May Be Engineered According to the Accepted Practices of the Local Telecommunications Utility.
Page 28: Laser Product Classification
Safety Laser product classification .................................................... Laser product classification Standards compliance The product complies with both IEC standards and the Food and Drug Administration’s Center for Devices and Radiological Health (FDA/ CDRH) regulations. FDA/CDRH regulations Laser products are classified in accordance with the FDA/CDRH - 21 CFR 1010 and 1040. The classification scheme is based on the ability of the laser emission to cause injury to eye or skin during normal operating conditions.
Page 29: Laser Classes
Safety Laser product classification .................................................... Laser classes The maximum output power of laser radiation depends on the type of laser diode used. The international standards IEC-60825 or DIN/EN 60825 define the maximum output power of laser radiation for each laser class in accordance with the wavelength. Table 1-1 Laser classes Maximum output power Laser class...
Page 30: Alcatel-Lucent 1850 Tss-60 Optical Specifications
.................................................... Alcatel-Lucent 1850 TSS-60 optical specifications Overview Table 1-2 provides the optical specifications for Alcatel-Lucent 1850 TSS-60 internal laser circuit packs. Table 1-2 Alcatel-Lucent 1850 TSS-60 optical circuit pack laser safety specifications Maximum Laser circuit Wavelength Out Pwr Max/Min Rcv...
Page 31: Alcatel-Lucent 1850 Tss-60 Optical Ptm Laser Safety Specifications
.................................................... Table 1-3 shows the pluggable transmission module (PTM) laser safety specifications and the supported circuit packs. The following Class 1 SFP/XFP transceivers are Alcatel-Lucent approved. Table 1-3 Alcatel-Lucent 1850 TSS-60 optical PTM laser safety specifications Supported Maximum Module Circuit...
Page 32 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class GE-1X2XF LNW63 -2.5 0.0/-17.0 MM (50 I(LN50)/1 C-SX-I1 LNW64 and 62.5)
Page 33 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class S622C49E LNW37 1491 +5.0 -8.0/-28.0 SM (9) I(LN50)/1 LNW45 LNW49...
Page 34 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class OC48SR1- LNW41 1310 -3.0 -3.0/-18.0 SM (9) I(LN50)/1 LNW55 LNW62...
Page 35 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class S2D31C6 LNW41 1552.524 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62...
Page 36 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class S2D49C6 LNW41 1538.186 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62...
Page 37 Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Supported Maximum Module Circuit Wavelength Out Pwr Max/Min Rcv Fiber Conn Class/ Code Pack(s) (nm) (dBm) Pwr (dBm) Type (µm) Type IEC Class X10G26C5 LNW141 1556.555 +3.0 -8.0/Table 1-4 SM (9) I(LN50)/1 X10G27C5 LNW141 1555.747...
Page 38: Dispersion-Limited Receiver Sensitivity For Oc-192 Dwdm Ptms
Safety Alcatel-Lucent 1850 TSS-60 optical specifications .................................................... Table 1-4 Dispersion-limited receiver sensitivity for OC-192 DWDM PTMs Receiver Receiver Receiver Sensitivity Sensitivity Sensitivity 0 ps/nm 1300 ps/nm 1600 ps/nm Data Rate dispersion dispersion dispersion 9.9 Gb/s -24.0 dBm -22.0 dBm 10.7-11.1 Gb/s with -27.0 dBm...
Page 39 Overview Introduction Part I covers the physical mounting of the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) shelf using the Horizontal Bay Mount. This section includes the running and connecting of power cables, interconnecting cables, alarm cables, and as required, external timing and communication cables.
Page 40: Part I: Physical And Power Installation
Alcatel-Lucent 1850 TSS-60 in a 19" bayframe. 1 or 2 Heat Baffle If the Alcatel-Lucent 1850 TSS-60 shelf is to be 848862181 installed above or below existing equipment that does not have a heat baffle, then a heat baffle (C 848862181) must be installed between the shelf and the existing equipment.
Page 41 Ohmmeter An ohmmeter is required to verify that the Alcatel-Lucent 1850 TSS-60 is properly grounded. ITE-6379C DS1 Error Rate Test Set A DS1 error rate test set is required for testing of DS1 cabling.
Page 42 † Registered trademark of Paladin Corporation. ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1850 TSS-60. Quantity Description Comments Personal Computer PC minimum requirements below.
Page 43 * Available hard disk space required to install and store the CIT and Generic Software is approximately 250 MB (it is 550 MB, if all graphical packages are installed). The additional disk space specified is to provide hard disk space to store Alcatel-Lucent 1850 TSS-60 backup files.
Page 44 Procedure Required Part I: “Physical and power installation” Chapter 2, “Physical “Inspection” (p. 2-6) installation” “Alcatel-Lucent 1850 TSS-60 center divider” See Note 1 (p. 2-7) “Alcatel-Lucent 1850 TSS-60 shelf installation” (p. 2-10) “Power cable installation” (p. 2-17) Chapter 3, “Cable and fiber “Inspection”...
Page 45 Physical and power installation .................................................... Completed Section and chapter Procedure Required Chapter 4, “Circuit pack “Powering” (p. 4-3) installation” “Initial circuit pack installation” (p. 4-10) “LNW2 (SYSCTL) installation” (p. 4-10) “OC-3/OC-12/OC-48/OC-192 main OLIU installation” (p. 4-11) “LNW39/LNW391 (DS1/DS3/16/3), LNW111 See Note 1 (3DS3) and LNW112 (16DS1) installation (optional)”...
Page 46 Physical and power installation .................................................... Completed Section and chapter Procedure Required “LNW74 (10/100-PL) and LNW66 (10/100T) See Note 1 installation (optional)” (p. 4-24) “LNW63 (GBE PL) 4 port or LNW64 (GBE See Note 1 PL) 8-port installation (optional)” (p. 4-25) “LNW70 and LNW170 (GigE/FE)”...
Page 47: Physical Installation
This section provides equipment installation instructions for the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) shelf using the horizontal bay mount configuration. The Alcatel-Lucent 1850 TSS-60 shelves with the removable center divider can support either half width or full width cards in the main function slots.
Page 48: Physical Installation
Alcatel-Lucent 1850 TSS-60 in a 19" bayframe. 1 or 2 Heat Baffle If the Alcatel-Lucent 1850 TSS-60 shelf is to be 848862181 installed above or below existing equipment that does not have a heat baffle, then a heat baffle (848862181) must be installed between the shelf and the existing equipment.
Page 49 An ohmmeter is required to verify that the Alcatel-Lucent 1850 TSS-60 is properly grounded. Mounting options The Horizontal Bay Mount mounting brackets on the Alcatel-Lucent 1850 TSS-60 are designed to allow for mounting in the following: Standard 23-inch wide network bay frames •...
Page 50: Physical Installation Planning
Physical installation Planning .................................................... Shelf mount rear cover Figure 2-1 Shelf mount rear cover kit 849001367 .................................................... 2 - 4 365-372-603R2.0 Issue 1 January 2009...
Page 51: Bay Mount Rear Cover Kit 849001060
Note: The rear bay cover requires the front mounting configuration of the Alcatel-Lucent 1850 TSS-60 shelf. This is mounting the shelf on the front of the bay with 5 inches of the shelf protruding from the front of the bay.
Page 52: Inspection
............................................Each Alcatel-Lucent 1850 TSS-60 shelf comes with an installation kit. The bag containing the kit is attached inside the Alcatel-Lucent 1850 TSS-60 shelf. The kit contains the following items: Quantity Description...
Page 53: Alcatel-Lucent 1850 Tss-60 Center Divider
The procedure below describes how to remove the center dividers for new installations. Procedure Proceed as follows: The figure below shows the new Alcatel-Lucent 1850 TSS-60 shelf with the center dividers inserted. Note: The center dividers come equipped with a spring clip CC849027222 not shown in Figure 2-3, “Center divider”...
Page 54: Center Divider
Procedure Proceed as follows: The figure below shows the new Alcatel-Lucent 1850 TSS-60 shelf with the center dividers inserted. As seen in the Figure, there is a working circuit pack above the top divider. Figure 2-4 Center divider with circuit packs installed.
Page 55 Physical installation Alcatel-Lucent 1850 TSS-60 center divider ..............................................................................................Gently slide out the center divider............................................Repeat for the bottom center divider if necessary. T E P S ..................................................................................2 - 9 365-372-603R2.0 Issue 1 January 2009...
Page 56: Alcatel-Lucent 1850 Tss-60 Shelf Installation
Note: This section requires previous bay frame installation and grounding. Note: If the Alcatel-Lucent 1850 TSS-60 shelf is to be used in an outside cabinet with no exchange of outside air, the air filter must be removed. Procedure Proceed as follows: ............................................
Page 57 23-inch wide network bay frame with a 5 in. setback. The Alcatel-Lucent 1850 TSS-60 shelf mounting brackets may have to be repositioned and remounted, depending on the frame type and mounting position (front or rear).
Page 58: Alcatel-Lucent 1850 Tss-60 Mounting Bracket Positions - 23-Inch/19-Inch Frame
Front 8.0 in. Rear Mount Left Side ............................................Determine the position that the Alcatel-Lucent 1850 TSS-60 shelf will be mounted. Note: Start at the bottom of the bay and add shelves from bottom to top..................................................... 2 - 1 2 365-372-603R2.0...
Page 59: Fiber Duct Mounting
Figure 2-6 Fiber duct mounting ............................................Position the Alcatel-Lucent 1850 TSS-60 shelf in the frame and secure the shelf to the frame using the thread-forming screws included with the shelf (3 screws per side). Tighten the screws to 21 in.-lb. (minimum)/30 in.-lb. (maximum).
Page 60: Safety Ground Screw
............................................If fiber spools are to be used, attach the spools to the Alcatel-Lucent 1850 TSS-60 using the Fiber Spool Bracket Kit drawing 848949152. Attach the bracket to the shelf first and then the top fiber spool to the bracket. The lower fiber spool will need to overlap the top spool to snap into place.
Page 61: Fiber Spools
............................................If there is space left in the bayframe above the last Alcatel-Lucent 1850 TSS-60 shelf installed, a heat baffle must be installed above the shelf to prevent accidental damage to the power cables at the top of the shelf.
Page 62: Heat Baffle
Physical installation Alcatel-Lucent 1850 TSS-60 shelf installation ..............................................................................................Figure 2-9, “Heat baffle” (p. 2-16) for proper installation of the heat baffle. Figure 2-9 Heat baffle T E P S ..................................................................................2 - 1 6 365-372-603R2.0 Issue 1 January 2009...
Page 63: Power Cable Installation
Alcatel-Lucent 1850 TSS-60 shelf. Two feeders (A and B) are required from the battery distribution fuse board (BDFB) or battery distribution circuit breaker bay (BDCBB) to the Alcatel-Lucent 1850 TSS-60 bay. Table 2-2, “Power cable assemblies” (p. 2-19) Table 2-3, “Power connections”...
Page 64 CAUTION Verify that the BDCBB breakers are off or that the BDFB fuses are not installed............................................Splice feeders from the BDCBB or BDFB to the Alcatel-Lucent 1850 TSS-60 power cable. Refer to Table 2-3, “Power connections” (p. 2-19). and should be labeled as follows;...
Page 65: Power Cable Assemblies
Physical installation Power cable installation .................................................... Table 2-2 Power cable assemblies Alcatel-Lucent 1850 Cable Cable length Jacket TSS-60 backplane Description assembly # (feet) color connections Power Cable 848929493 One Red Connectors on rear of the Kits with Right and One...
Page 66: Final Operations
Physical installation Final operations .................................................... Final operations Description Final check on equipment installation. Procedure Proceed as follows: ............................................Verify that all the power cables are properly dressed/connected............................................Verify that all power cables are properly labeled............................................Replace rear cover on shelf if ordered............................................
Page 67: Cable And Fiber Installation
This section provides cabling instructions for the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) shelf using the horizontal bay mount configuration. The Alcatel-Lucent 1850 TSS-60 shelves with the removable center divider can support either half width or full width cards in the Main function slots.
Page 68 Cable and fiber installation .................................................... Miscellaneous (environmental) discrete telemetry cable installation 3-61 OC-3/OC-12/OC-48/OC-192 main optical fiber cable installation 3-66 OC-3/OC-12/OC-48 low-speed optical fiber cable installation 3-69 100/1000BASE-X optical fiber cable installation 3-71 CIT (RS-232) cable installation 3-73 Final operations 3-75 ....................................................
Page 69: Planning
Cable and fiber installation Planning .................................................... Planning Description This section provides information about the following: Tools, test equipment and accessories • Mounting options • Cabling checklist • Tools, test equipment and accessories Listed below are the tools, test equipment and accessories necessary to perform the procedures in this section.
Page 70: Cable Requirements And Options
Optional Modem Optional 1. One CIT Cable Assembly is required for PC interface with the Alcatel-Lucent 1850 TSS-60 (not included with equipment). 2. Two DS1/E1 Cable Assembly are required for each D or G function unit group that will support additional DS1/E1 traffic using the LNW8. Each DS1 Cable Assembly consists of two separate cable assemblies, both containing 28 pairs of 24 gauge cable.
Page 71 One Office Alarm Mult Cable Assembly is required for each additional Alcatel-Lucent 1850 TSS-60 shelf in the bay frame. For example, if four Alcatel-Lucent 1850 TSS-60 shelves are located in a single 7-foot bay frame, one Office Alarm Cable Assembly and three Office Alarm Mult Cable Assemblies are required.
Page 72: Connector References
.................................................... Connector references Description Figure 3-1 provides the pinouts of some of the connectors used to interface with the Alcatel-Lucent 1850 TSS-60. Figure 3-1 Connector types and pinouts DB-9 male-type connector DB-9 female-type connector DB-15 male-type connector DB-15 female-type connector...
Page 73: Inspection
Cable and fiber installation Inspection .................................................... Inspection Description Perform the following procedure before installing the Alcatel-Lucent 1850 TSS-60 cables. Procedure Proceed as follows: ............................................Inspect the shelf for visible damage including bent or touching backplane pins. Note: If any backplane pins are damaged, refer to Appendix E, “Backplane pin...
Page 74: Ds1/Ei Cable Installation
Alcatel-Lucent 1850 TSS-60 backplane connections. Thus the IN on the Alcatel-Lucent 1850 TSS-60 backplane connects to the IN of the DSX and the OUT of the Alcatel-Lucent 1850 TSS-60 backplane connects to the OUT of the DSX respectively.
Page 75: Ds1/E1 Cable Connectors
Cable and fiber installation DS1/EI cable installation .................................................... Note: The first 28 DS1/E1s of a Function Group must be connected to the right side connectors (J1D, J3D, J7G, and J9G). An additional capacity of 28 DS1s, 29-56, are used when the LNW8 circuit pack is used. The second 28 DS1s of a Function Group are connected to the backplane (J2D, J4D, J8G, and J10G).
Page 76: Ds1/E1 Cable Routing To The Right
Cable and fiber installation DS1/EI cable installation .................................................... Figure 3-3 DS1/E1 cable routing to the right Figure 3-4 DS1/E1 cable routing to the left ............................................Route the cables along the cable rack and into the terminating bay............................................Remove slack and cut the DS1/E1 cables to the desired length at the DSX............................................
Page 77 Cable and fiber installation DS1/EI cable installation ..............................................................................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ................................ Table 3-2 DS1/E1 cable assemblies Alcatel-Lucent 1850 Cable length Cable TSS-60 backplane (feet) assembly # Description connections 848954988 848955001...
Page 78 DS1/E1 or DS3/EC-1 cabling. 5. Cables are terminated in J1D through J4D and J7G through J10G connectors at the Alcatel-Lucent 1850 TSS-60 end and unterminated at the other end for wire-wrap installation. 6. The cable connectors are 62 pins D-Sub male-type connectors and fit into J1D through J4D and J7G through J10G.
Page 79: Ds1/E1 Transmission Connections
Cable and fiber installation DS1/EI cable installation .................................................... Table 3-3 DS1/E1 transmission connections Alcatel-Lucent 1850 TSS-60 DSX-1 connections backplane connections Function Function 62-Pin group D group G conn. conn. conn. ChanD pin# term color 1 (1) B8/B7 W/BL¹ 19/40 2 (2) B6/B5 W/O¹...
Page 80 Cable and fiber installation DS1/EI cable installation .................................................... Alcatel-Lucent 1850 TSS-60 DSX-1 connections backplane connections Function Function 62-Pin group D group G conn. conn. conn. ChanD pin# term color 1 (25) B8/B7 3/24 2 (26) B6/B5 W/BL¹ 2/23 3 (27) B4/B3 W/O¹...
Page 81 Cable and fiber installation DS1/EI cable installation .................................................... Alcatel-Lucent 1850 TSS-60 DSX-1 connections backplane connections Function Function 62-Pin group D group G conn. conn. conn. ChanD pin# term color 1 (53) B8/B7 3/24 2 (54) B6/B5 W/BL¹ 2/23 3 (55) B4/B3 W/O¹...
Page 82: Ds3/Ec-1 Cable Installation
When cabling the Alcatel-Lucent 1850 TSS-60 to a DSX, the DSX becomes an extension of the Alcatel-Lucent 1850 TSS-60 backplane connections. Therefore, the IN on the Alcatel-Lucent 1850 TSS-60 backplane connects to the IN of the DSX and the OUT of the Alcatel-Lucent 1850 TSS-60 backplane connects to the OUT of...
Page 83: Ds3/Ec-1 Cable Connections
Cable and fiber installation DS3/EC-1 cable installation ..............................................................................................Connect the function group cables at the Alcatel-Lucent 1850 TSS-60 end, carefully matching the correct connector with the appropriate backplane connectors as shown in Figure 3-5, “DS3/EC-1 cable connections” (p. 3-18).
Page 84: Ds3/Ec-1 Cable Routing To The Right
Cable and fiber installation DS3/EC-1 cable installation .................................................... Figure 3-5 DS3/EC-1 cable connections Ports ............................................Route the cables along the backplane and out of the bay to the DSX per Figure 3-6, “DS3/EC-1 cable routing to the right” (p. 3-18). Figure 3-6 DS3/EC-1 cable routing to the right Notes: The 12-conductor DS3/EC-1 cable is showing that this cable could be either the 12- or 24-conductor DS3/EC-1 cable.
Page 85: Ds3/Ec-1 Cable Routing To The Left
Cable and fiber installation DS3/EC-1 cable installation .................................................... Figure 3-7 DS3/EC-1 cable routing to the left Notes: The 12-conductor DS3/EC-1 cable is shown............................................Route the cables along the cable rack and into the terminating bay (DSX or other terminating transmission equipment)............................................
Page 86: Ds3/Ec-1 Cable Assemblies
Cable and fiber installation DS3/EC-1 cable installation .................................................... Table 3-4 DS3/EC-1 cable assemblies Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Function group D 848955084 and G 848955092 12 Cable DS3/ EC-1 In (CA1) and 848955100...
Page 87 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections The following kits include 12 individually bagged BNCs with instructions plus one spare: KINGS 75ohm 735A 848965778 cable type (12)BNC...
Page 88 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Right side cables for 848940011 These cables route to the function group D right (as viewed from the 848940029 and G...
Page 89 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Right side cables for 848940169 function group D 848940177 and G 24 Cable DS3/EC-1 848940185 In (CA1) and 24 848940193...
Page 90 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Right side cables for 849041207 These cables route to the function group D right (as viewed from the 849041215 and G...
Page 91 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections TROMPETER 848963088 75-ohm 735A cable type (24)BNC Plug TROMPETER 848963096 75-ohm 734D cable type (24)BNC Plug ITT CANON 75ohm 409013554...
Page 92 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Left side cables for 848923124 These cables route to the function group D left (as viewed from the 848923132 and G...
Page 93 Cable and fiber installation DS3/EC-1 cable installation .................................................... Cable Alcatel-Lucent 1850 Cable length TSS-60 backplane Description assembly # (feet) connections Left side cables for 848932075 735A/734 Splice function group D 848839528 735A/734 Splice and G 24 Cable DS3/EC-1 848839536 735A/734 Splice Ne to Ne...
Page 94 4. For Input connections use cable CA1 (DS3/EC-1 IN) and for Output connections use cable CA2 (DS3/EC-1 OUT). 5. 735A cable is used to connect Alcatel-Lucent 1850 TSS-60 to DSX-3 or another NE (10 to 450 ft. length). 6. The cable connectors are 62 pins D-Sub male-type connectors and fit into J1D through J4D and J7G through J10G.
Page 95: Twenty-Four Cable Ds3/Ec-1 Transmission Connections
Cable and fiber installation DS3/EC-1 cable installation .................................................... Table 3-5 Twenty-four cable DS3/EC-1 transmission connections Coaxial Lead Connector cable designation Name pin# Connectors (Ports 1 - 24) J1D (IN), J3D (OUT) and J7G (IN), J9G (OUT) This cable routes to the right. DS3 1R/1T Signal FRG1...
Page 96 Cable and fiber installation DS3/EC-1 cable installation .................................................... Coaxial Lead Connector cable designation Name pin# DS3 13R/12T Signal FRG13 Ground DS3 14R/12T Signal FRG14 Ground DS3 15R/12T Signal FRG15 Ground DS3 16R/12T Signal FRG16 Ground DS3 17R/12T Signal FRG17 Ground DS3 18R/12T Signal FRG18...
Page 97 Cable and fiber installation DS3/EC-1 cable installation .................................................... Coaxial Lead Connector cable designation Name pin# DS3 26R/12T Signal FRG26 Ground DS3 27R/12T Signal FRG27 Ground DS3 28R/12T Signal FRG28 Ground DS3 29R/12T Signal FRG29 Ground DS3 30R/12T Signal FRG30 Ground DS3 31R/12T Signal FRG31...
Page 98 Cable and fiber installation DS3/EC-1 cable installation .................................................... Coaxial Lead Connector cable designation Name pin# DS3 40R/12T Signal FRG40 Ground DS3 41R/12T Signal FRG41 Ground DS3 42R/12T Signal FRG42 Ground DS3 43R/12T Signal FRG43 Ground DS3 44R/12T Signal FRG44 Ground DS3 45R/12T Signal FRG45...
Page 99: Twelve Cable Ds3/Ec-1 Transmission Connections
Cable and fiber installation DS3/EC-1 cable installation .................................................... Table 3-6 Twelve cable DS3/EC-1 transmission connections Coaxial Lead Connector cable designation Name pin# Connectors (Ports 1 - 12) J1D (IN), J3D (OUT) and J7G (IN), J9G (OUT) This Cable Routes to the Right. DS3 1R/1T Signal FRG1...
Page 100 Cable and fiber installation DS3/EC-1 cable installation .................................................... Coaxial Lead Connector cable designation Name pin# Notes: 1. Lead designation for EC-1 connection for cable# x should be read as EC-1 xR/xT instead of DS3 xR/xT, where x is a number from 1 to 12.....................................................
Page 101: Ds1 And Ds3 Hybrid Cable Installation
This section describes how to connect the DS1 and DS3 Hybrid cables to the Alcatel-Lucent 1850 TSS-60 shelf and route the cables out of the bay and to the DS1 and DS3 Hybrid Cable terminating equipment. Perform this procedure if DS1 and DS3 Hybrid cables are required.
Page 102: Ds1 And Ds3 Hybrid Cable Connections
Cable and fiber installation DS1 and DS3 hybrid cable installation .................................................... Figure 3-8 DS1 and DS3 hybrid cable connections ............................................Route the cables along the backplane and out of the bay to the DSX per Figure 3-9, “DS1 and DS3 hybrid cable routing” (p. 3-36).
Page 103 Cable and fiber installation DS1 and DS3 hybrid cable installation .................................................... Note: When installing BNC connectors, follow the manufacturer’s instruction carefully to ensure a proper connection. Failure to do so may result in faulty DS3 signals as a result of improperly installed BNC connectors............................................
Page 104: Ds1 And Ds3 Hybrid Cable Assemblies
Cable and fiber installation DS1 and DS3 hybrid cable installation .................................................... Table 3-7 DS1 and DS3 hybrid cable assemblies Alcatel-Lucent 1850 TSS-60 Cable length backplane Description Cable assembly # (feet) connections Function group A/B 848955035 J5A/B(IN) DS1 and DS3 hybrid cable In...
Page 105 Cable and fiber installation DS1 and DS3 hybrid cable installation .................................................... Alcatel-Lucent 1850 TSS-60 Cable length backplane Description Cable assembly # (feet) connections 849041678 J5A/B(IN) J6A/B(OUT) 849041686 849041694 849041702 Function group A/B 849006903 J5A/B(IN) DS1 and DS3 hybrid cable In...
Page 106 4. For Input connections use cable CA1 (DS1 and DS3 Hybrid IN) and for Output connections use cable CA2 (DS1 and DS3 Hybrid OUT). 5. For the Coaxial cable 735A cable is used to connect Alcatel-Lucent 1850 TSS-60 to DSX-3 or another NE (50 to 350 ft. length).
Page 107: Ds1 And Ds3 Hybrid Cable Ds3 Transmission Connections
Ground DS3 2R/2T Signal FRG2 Ground DS3 3R/3T Signal FRG3 Ground Table 3-9 DS1 and DS3 hybrid cable DS1 transmission connections Alcatel-Lucent 1850 TSS-60 backplane DSX-1 connections connections Function group A conn. 62 pin ChanD conn. term color pin# T/R...
Page 108: 10/100Base-T Ethernet Cable Installation
Description This section describes how to connect the 10/100BASE-T cables to the Alcatel-Lucent 1850 TSS-60 shelf and route the cables out of the bay and to the 10/100BASE-T terminating equipment. Perform this procedure if 10/100BASE-T cables are required. This section describes how to route the 10/100BASE-T cables from the interconnecting equipment (for example, a 110/RJ45 punch down block) to the Alcatel-Lucent 1850 TSS-60 backplane.
Page 109 Cable and fiber installation 10/100BASE-T Ethernet cable installation .................................................... Figure 3-10 10/100BASE-T/TX cable connections ............................................Route the cables to the left along the backplane and out of the bay to the 110/RJ45 punch down block. Route the cables in the same manner as DS3/EC1 cables. Refer to Figure 3-11, “10/100BASE-T cable routing”...
Page 110: 10/100Baset Ethernet Connections
JSM110A, for intra-office applications only............................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ................................ Table 3-10 10/100Base-T Ethernet cable assemblies Alcatel-Lucent 1850 Cable length TSS-60 backplane Description Cable assembly # (feet) connections 10/100BASE-T/TX...
Page 111 Cable and fiber installation 10/100BASE-T Ethernet cable installation .................................................... Table 3-11 10/100BaseT ethernet connections Port# (1-24) Wire dsub 62M RJ-45 J1D, J7G J3D, J9G color pin# Signal pin# 50/49 R+/R- W/BL 8/29 T+/T- W/BR 48/47 R+/R- 5/26 T+/T- R/BL 7/28 R+/R- 6/27 T+/T-...
Page 112: Iao Lan And Tcp/Ip Cable Installation
LAN (RJ45) jack on the SYSCTL circuit pack. If connecting to the rear of the Alcatel-Lucent 1850 TSS-60 shelf, connect the cable to the J17 port (IAO LAN) on the Alcatel-Lucent 1850 TSS-60 backplane and route to the left side of the shelf.
Page 113: Iao Lan/Tcp-Ip Cable Connection To Rear Of Alcatel-Lucent 1850 Tss-60
Cable and fiber installation IAO LAN and TCP/IP cable installation .................................................... Figure 3-12 IAO LAN/TCP-IP cable connection to rear of Alcatel-Lucent 1850 TSS-60 ............................................If a cross-over cable is used, route the cable to the desired PC LAN port. If a straight-through cable is used, route the cable to the desired hub port location.
Page 114 Cable and fiber installation IAO LAN and TCP/IP cable installation .................................................... Alcatel-Lucent 1850 TSS-60 connections Cable Cable Description assembly # length (feet) Front Rear LAN 10BASE-T 109321836 SYSCTL J17 (IAO LAN) Straight-through LAN jack cable to Ethernet hub 109321844 / router...
Page 115: Lan 10Base-T Cross-Over Cable Connections
Cable and fiber installation IAO LAN and TCP/IP cable installation .................................................... Table 3-13 LAN 10Base-T cross-over cable connections Alcatel-Lucent Connection 1850 TSS-60 bkpl Color Other side J17 (IAO LAN) BL - W W - BL O - W W - O...
Page 116: Modem Cable Installation
Modem cable installation .................................................... Modem cable installation Description The use of a modem will allow the Alcatel-Lucent 1850 TSS-60 to be accessed remotely via dial up. Note: Perform this procedure for the shelf which will be directly connected to a modem or a distribution frame (if specified in the order).
Page 117: Modem Cable Connections
............................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ................................ Table 3-15 Modem cable assemblies Alcatel-Lucent Cable Cable length 1850 TSS-60 Description assembly # (feet) connections Modem cable 848756508 J18 (MODEM) 848756524 848756516 848756532...
Page 118: Sync Cable Installation
The section provides the instructions for installing the two types of synchronization (Sync) cables to the Alcatel-Lucent 1850 TSS-60. A Sync cable is required if the shelf is to be externally timed. The Alcatel-Lucent 1850 TSS-60 can provide DS1 external timing to a BITS clock. When the shelf is externally timed by a DS1 Reference and/or is configured to provide a Sync Output, a Sync Input timing cable is required.
Page 119: Sync Cable Connections
Cable and fiber installation Sync cable installation .................................................... Figure 3-14 Sync cable connections ............................................Route the cable to proper location and cut to desire length............................................Terminate the wires in the red jacket for an output signal. See Table 3-18, “Synchronization cable (DS1 timing reference) connections”...
Page 120 Cable and fiber installation Sync cable installation ..............................................................................................Wire-wrap Rx1 and Tx1 (red cable) on the D-Sub connector for an output signal per Table 3-18, “Synchronization cable (DS1 timing reference) connections” (p. 3-56)............................................Wire-wrap Rx2 and Tx2 (gray cable) on the D-Sub connector for an input signal per Table 3-18, “Synchronization cable (DS1 timing reference) connections”...
Page 121 Cable and fiber installation Sync cable installation .................................................... Table 3-17 Synchronization cable assemblies (SYNC1 and SYNC2) Alcatel-Lucent 1850 TSS-60 Cable Cable length backplane Description assembly # (feet) connections Sync1 (J11) and Sync2 (J12) 848839619 J11 (Sync1)/ cables, straight connector, J12 (Sync2)
Page 122: Synchronization Cable (Ds1 Timing Reference) Connections
Cable and fiber installation Sync cable installation .................................................... Alcatel-Lucent 1850 TSS-60 Cable Cable length backplane Description assembly # (feet) connections Notes: 1. The Sync cable is 22 gauge. 2. Ground the Filter connectors either at the bay frame ground or at the office timing source. Refer to office records.
Page 123: Office Alarm Cable Installation
3-60). Alarm mult Office alarm cabling in a Alcatel-Lucent 1850 TSS-60 bay starts at the bottom shelf which is cabled directly to the office alarm system. Then as shelves are added to the bay, the office alarm connection is extended by multing the alarm cabling from shelf to shelf (bottom to top).
Page 124: Office Alarm Cable Connections
Figure 3-15, “Office alarm cable connections” (p. 3-58). Figure 3-15 Office alarm cable connections ............................................Route the office alarm cable from the bottom shelf out of the Alcatel-Lucent 1850 TSS-60 bay per Figure 3-16, “Office alarm cable routing” (p. 3-58) to the office alarm panel.
Page 125 No shelf should be skipped............................................Obtain the office alarm mult cable 848589602 for Alcatel-Lucent 1850 TSS-60. Connect one end to ALM MULT (J14) of the Alcatel-Lucent 1850 TSS-60 shelf. See Figure 3-15, “Office alarm cable connections” (p. 3-58).
Page 126: Alarm Office Connections
1. The SYSCTL circuit pack reports office alarms. 2. The connection to the central office alarms from P13 is run for each Alcatel-Lucent 1850 TSS-60 shelf assembly when used in a miscellaneously mounted individual application or from the first Alcatel-Lucent 1850 TSS-60 shelf assembly when mounted in a typical bay arrangement.
Page 127: Miscellaneous (Environmental) Discrete Telemetry Cable Installation
Description The miscellaneous (environmental) discrete telemetry access allows the maintenance center to control and monitor equipment collocated with the Alcatel-Lucent 1850 TSS-60. The environmental control feature enables the maintenance center to remotely initiate up to four contact closures at the remote terminal (RT) for equipment operation such as pumps, generators, etc.
Page 128: Miscellaneous Discrete Cable Connection
Miscellaneous (environmental) discrete telemetry cable installation .................................................... Figure 3-17 Miscellaneous discrete cable connection ............................................Route the cable out of the Alcatel-Lucent 1850 TSS-60 bay per Figure 3-18, “Miscellaneous discrete cable routing” (p. 3-62) to the telemetry panel. Figure 3-18 Miscellaneous discrete cable routing ............................................
Page 129 Cable and fiber installation Miscellaneous (environmental) discrete telemetry cable installation .................................................... should be connected to the appropriate alarm indication. For each output, one lead should be connected to output-common and the other lead should be connected to the appropriate alarm indication............................................
Page 130: Miscellaneous Discrete Cable Assemblies
Cable and fiber installation Miscellaneous (environmental) discrete telemetry cable installation .................................................... Table 3-21 Miscellaneous discrete cable assemblies Alcatel-Lucent 1850 TSS-60 Cable Cable length backplane Description assembly # (feet) connections Miscellaneous 848979399 discrete cable 848979407 848549598 848549606 848549614 848549622 848549630 Table 3-22 Miscellaneous (environmental) discrete telemetry connections Conn.
Page 131 Cable and fiber installation Miscellaneous (environmental) discrete telemetry cable installation .................................................... Conn. Pin# Color Designation Name BR-R TLMI17 Env. Input - #17 R-BR TLMI18 Env. Input - #18 TLMI19 Env. Input - #19 TLMIC48VTR Input Common BL-BK TLMO1 Env. Output - #1 BK-BL TLMO2 Env.
Page 132: Oc-3/Oc-12/Oc-48/Oc-192 Main Optical Fiber Cable Installation
OC-3/OC-12/OC-48/OC-192 Main OLIUs of the Alcatel-Lucent 1850 TSS-60. This procedure does not cover routing the optical fiber cable between sites. The optical fiber cables will be connected to the Alcatel-Lucent 1850 TSS-60 after the circuit packs are installed. The Alcatel-Lucent 1850 TSS-60 requires single-mode fiber for the main OLIUs.
Page 133: Optical Fiber Routing
.................................................... Procedure Proceed as follows: ............................................Route the optical fiber cables from the interconnecting equipment into the left side of the Alcatel-Lucent 1850 TSS-60. See Figure 3-19, “Optical fiber routing” (p. 3-67). Note: Protective covers must be left on cables.
Page 134 Cable and fiber installation OC-3/OC-12/OC-48/OC-192 main optical fiber cable installation ..............................................................................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ..................................................................................3 - 6 8 365-372-603R2.0 Issue 1 January 2009...
Page 135: Oc-3/Oc-12/Oc-48 Low-Speed Optical Fiber Cable Installation
PVC tubing, or PANDUIT cable channel, when running the cable from the Alcatel-Lucent 1850 TSS-60 to the cable rack. The fibers should be placed in the cable rack in a protective channel with nothing on top of them.
Page 136 Label the optical fiber cables, indicating bay, shelf, function group, pack, and direction (IN or OUT)............................................Route optical fiber cables from the interconnecting equipment into the left side of the Alcatel-Lucent 1850 TSS-60 and into the OC-3/OC-12/OC-48 optical ports. See Figure 3-19, “Optical fiber routing” (p. 3-67)............................................
Page 137: 100/1000Base-X Optical Fiber Cable Installation
PVC tubing, or PANDUIT cable channel, when running the cable from the Alcatel-Lucent 1850 TSS-60 to the cable rack. The fibers should be placed in the cable rack in a protective channel with nothing on top of them.
Page 138 Label the optical fiber cables, indicating bay, shelf, function group, pack, and direction (IN or OUT)............................................Route optical fiber cables from the interconnecting equipment into the left side of the Alcatel-Lucent 1850 TSS-60 and into the 100/1000BASE-X optical ports. See Table 3-19, “Optical fiber routing” (p. 3-67).
Page 139: Cit (Rs-232) Cable Installation
Connect the 9-pin D-type connector to the serial port on the PC............................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ................................ Table 3-23 CIT cable assembly Alcatel-Lucent 1850 Cable Cable TSS-60 Description assembly # length connections...
Page 140: Standard Cit Cable Connection
FRXD Transmit Data Notes: 1. The connection and the colors shown above are for a standard Alcatel-Lucent made cable. If you use a RJ-45 to DB-9 connector with a standard straight-through 10BASE-T LAN cable then, refer to Table 3-25, “RJ-45 to DB-9 connector connections”...
Page 141: Final Operations
Cable and fiber installation Final operations .................................................... Final operations Description Final check on cable installation. Procedure Proceed as follows: ............................................Verify that all the cables are properly dressed/connected............................................Verify that all cables are properly labeled............................................Verify that designations where cables were wire-wrapped are properly labeled............................................
Page 142 Cable and fiber installation Final operations ......................................................................................................3 - 7 6 365-372-603R2.0 Issue 1 January 2009...
Page 143: Circuit Pack Installation
Shelf powering • Circuit pack option settings and installation • Detailed information on the function of each circuit pack is contained in Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 User Provisioning Guide — 365-372-601R2.0. Contents This chapter provides information on the following topics:...
Page 144: Circuit Pack Installation
Circuit pack installation Description .................................................... Description Overview This section should be performed on all shelf installations. Tools, test equipment, and accessories Listed below are the tools, test equipment and accessories necessary to perform the procedures in this section. Quantity Description Comments Screwdriver(s) A screwdriver(s) with the appropriate head(s) is...
Page 145: Powering
Verify that the frame or structure into which the Alcatel-Lucent 1850 TSS-60 Shelf is installed is properly grounded............................................Verify that both 10 ampere circuit breakers on the Alcatel-Lucent 1850 TSS-60 are in the OFF position. These breakers are located on the front of the Alcatel-Lucent 1850 TSS-60 shelf.
Page 146: Power Connections On Alcatel-Lucent 1850 Tss-60 Backplane
............................................If breakers are being used, verify that 25-ampere breakers are installed and switch the breakers to the ON position for the Alcatel-Lucent 1850 TSS-60 A and B feeders............................................At the Alcatel-Lucent 1850 TSS-60 power cable connector, use a voltmeter and measure the voltage on the power cable between BAT A and BAT A RTN.
Page 147 At the BDFB either remove the fuse or put the circuit breaker, associated with the “B” feed of the Alcatel-Lucent 1850 TSS-60, in the OFF position............................................Verify the PWR A LED on the Alcatel-Lucent 1850 TSS-60 shelf is lighted with only the “A” feed powered............................................
Page 148 Circuit pack installation Powering ..............................................................................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ..................................................................................4 - 6 365-372-603R2.0 Issue 1 January 2009...
Page 149: Circuit Pack Compatibility
Table 4-2, “Release 2.0 circuit pack slot compatibility” (p. 4-7) lists all the circuit packs that are compatible with Release 2.0 and their respective shelf locations (slots). Figure 4-2, “Alcatel-Lucent 1850 TSS-60 shelf” (p. 4-9) for slot locations. Table 4-2 Release 2.0 circuit pack slot compatibility...
Page 150 Circuit pack installation Circuit pack compatibility .................................................... Slot name G1, G2 A1/B1, A2/B2 M1, M2 D1, D2 LNW601 LNW39 LNW111 LNW112 LNW55 LNW55 LNW62 LNW62 † † LNW63 LNW63 † † LNW64 LNW64 † † LNW66 LNW66 † † LNW70 LNW70 †...
Page 151: Alcatel-Lucent 1850 Tss-60 Shelf
Main Slots to provide proper air flow for cooling. †† System Detectable Blank Card for slots D and G. Apparatus Blanks are required in all unequipped function unit slots to provide proper air flow for cooling. Figure 4-2 Alcatel-Lucent 1850 TSS-60 shelf .................................................... 4 - 9 365-372-603R2.0...
Page 152: Initial Circuit Pack Installation
Alcatel-Lucent 1850 TSS-60 shelf. After circuit packs have been unpacked, they may be placed in their respective slots in the Alcatel-Lucent 1850 TSS-60 shelf but not fully engaged in the backplane connector. The circuit packs will be fully installed (seated) in the next section.
Page 153 ............................................Remove the first main OLIU circuit pack from the packing material............................................Identify the M1 slot on the Alcatel-Lucent 1850 TSS-60 shelf. See Figure 4-2, “Alcatel-Lucent 1850 TSS-60 shelf” (p. 4-9).....................................................
Page 154 Initial circuit pack installation ..............................................................................................Place the main OLIU circuit pack into the M1 slot on the Alcatel-Lucent 1850 TSS-60 shelf. Do NOT engage the circuit pack in the backplane connector............................................Remove the second main OLIU from the packing material.
Page 155 LNW7 (28DS1PM) and LNW8/LNW801 (56DS1E1) installation (optional) Follow this procedure only if installing LNW7 (28DS1PM) or LNW8/LNW801 (56DS1E1) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf. Note: The LNW7 is not supported when the LNW141 or LNW84 VLF main OLIU is used.
Page 156 ................................ LNW16 (12DS3/EC1) and LNW19B (48DS3/EC1) installation (optional) Follow this procedure only if installing LNW16 (12DS3/EC1) or LNW19B (48DS3/EC1) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf............................................Refer to the engineering job specification. Identify the proper function group(s) where LNW16 or LNW19B will be installed.
Page 157 ................................ LNW18 (12TMUX) and LNW20 (48TMUXDS3EC1) installation (optional) Follow this procedure only if installing LNW18 (12TMUX) or LNW20 (48TMUXDS3EC1) into the Alcatel-Lucent 1850 TSS-60 shelf............................................Refer to the engineering job specification. Identify the proper function group(s) where LNW18 or LNW20 will be installed.
Page 158 ................................ LNW402 OC-48 1310 nm, 1550 nm, or DWDM PTM Optics Follow this procedure to install the LNW402 circuit packs in the Alcatel-Lucent 1850 TSS-60 shelf. The high-speed LNW402 is a single-port OLIU that employs PTM pluggable optics to offer 1310 nm, 1550 nm, or DWDM optics with a 12 STS-1 VT fabric.
Page 159 T E P S ................................ LNW785 OMD5/8 8-channel low-loss DWDM Optical Mux/Demux Follow this procedure to install the LNW785 circuit packs in the Alcatel-Lucent 1850 TSS-60 shelf. The LNW785 OMD5/8 circuit pack multiplexes/demultiplexes up to 8 DWDM optical channels............................................
Page 160 LNW37 (OC-3 4 port PTM OLIU) or LNW45 (OC-3 8 port PTM OLIU) Follow this procedure if installing the LNW37 (OC-3 4 port PTM OLIU) or LNW45 (OC-3 8 port PTM OLIU) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf. Note: The LNW37 or LNW45 circuit pack comes in two separate boxes.
Page 161 LNW49 (OC-12 4 port PTM OLIU) low speed installation (optional) Follow this procedure only if installing the LNW49 (OC-12 4 port PTM OLIU) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf. Note: The LNW49 (OC-12 4 port PTM OLIU) circuit pack comes in two separate boxes.
Page 162 LNW62 (4 OC-48 PTM OLIU) or LNW55 (OC-3/OC-12/OC-48 12/4 port OLIU) low-speed installation (optional) Follow this procedure only if installing the LNW62 (4 OC-48 PTM OLIU) or LNW55 (OC-3/OC-12/OC-48 12/4 PTM OLIU) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf. Note: The LNW62 and the LNW55 circuit packs require the LNW141 or LNW84 VLF main OLIU to be used.
Page 163 Circuit pack installation Initial circuit pack installation ..............................................................................................If a companion circuit pack is required, continue with the Step 5. If not, install a 177D or LNW98 Apparatus Blank into the protection circuit pack slot (D2 or G2 as required), then proceed to Step Note:...
Page 164 ................................ LNW49 (OC-12 OLIU) low-speed installation (optional) Follow this procedure only if installing LNW49 (OC-12 OLIU) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf............................................Refer to the engineering job specification. Identify the proper function group(s) and/or growth slot(s) where LNW49 circuit pack will be installed.
Page 165 ................................ LNW31 (OC-48 OLIU) low-speed installation (optional) Follow this procedure only if installing LNW31 (OC-48 OLIU) circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf............................................Refer to the engineering job specification. Identify the proper function group(s) and/or growth slot(s) where LNW31 circuit pack will be installed.
Page 166 The LNW74 or LNW66 circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See the Alcatel-Lucent 1850 Transport Service Switch (TSS-60), Release 2.0 Product Information and Planning Guide 365-372-600R2.0 for allowed combinations.
Page 167 Note: LNW63 or LNW64 circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See the Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Product Information and Planning Guide —...
Page 168 I-6). T E P S ................................ LNW70 and LNW170 (GigE/FE) Follow this procedure only if installing LNW70 circuit packs into the Alcatel-Lucent 1850 TSS-60 shelf. Note: The LNW70 and LNW170 have both electrical and optical PTMs for both gigE and FE. When inserting them into ports, provision the card appropriately.
Page 169 Note: LNW78 circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See the Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Product Information and Planning Guide — 365-372-600R2.0 for allowed combinations.
Page 170 Circuit pack installation Initial circuit pack installation ..............................................................................................Check off the appropriate box in “Installation checklist” (p. I-6). T E P S ..................................................................................4 - 2 8 365-372-603R2.0 Issue 1 January 2009...
Page 171 Note: LNW73/73C circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See the Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Product Information and Planning Guide — 365-372-600R2.0 for allowed combinations.
Page 172 ................................ LNW43, LNW96 (apparatus blank) installation (optional) Follow this procedure to installs LNW43 or LNW96 Apparatus Blank(s) into the Alcatel-Lucent 1850 TSS-60 shelf. Note: A LNW43 or LNW96 Apparatus Blank is required in any unequipped A1/B1 or A2/B2 slots to provide proper air flow for cooling.
Page 173 ................................ LNW42, LNW95 apparatus blank installation (optional) Follow this procedure to install LNW42 or LNW95 Apparatus Blank(s) into the Alcatel-Lucent 1850 TSS-60 shelf. Note: A LNW42 or LNW95 Apparatus Blank is required in any unequipped Main slots to provide proper air flow for cooling.
Page 174 Circuit pack installation Initial circuit pack installation ......................................................................................................4 - 3 2 365-372-603R2.0 Issue 1 January 2009...
Page 175: Part Ii: Stand-Alone Installation Testing
(GUI) or Craft Interface Terminal (CIT) software installation and turn-up testing on a new Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) shelf. It is intended to verify correct electrical DS1/DS3/FE cable wiring to the DSX panel or punch down block as well SONET fiber routing to the LGX panel from the faceplates of installed packs.
Page 176 LC-type Optical Fiber Two optical fiber jumpers with LC type connectors are Jumper ITE-7169 required to optically loop the Alcatel-Lucent 1850 (108918269) TSS-60 shelf for test purposes. In addition, for shelves containing optical circuit packs in any of the function unit slots, a single optical fiber jumper is required for testing of the individual ports.
Page 177 15-dB LC-type LBO LBOs are only required when optically looping the ITE-7196 (108279480) Alcatel-Lucent 1850 TSS-60 shelves containing optical circuit packs in any of the function unit slots; a single 15-dB LBO is required for testing of the individual ports Noyes OFS 300-200X This equipment may not be necessary at all locations.
Page 178 Stand-alone installation testing .................................................... ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1850 TSS-60. Quantity Description Comments Personal Computer PC minimum requirements below. (PC) RS-232 Interface 8-ft.
Page 179 ® “Use of WaveStar CIT software” (p. 5-8) “Login procedure” (p. 5-8) “Circuit pack program version verification” (p. 5-12) “Alcatel-Lucent 1850 TSS-60 shelf initialization” (p. 5-14) Chapter 6, “Stand-alone “LBO software settings” (p. 6-5) See Note 1 installation testing” “Clearing alarms” (p. 6-8) See Note 1 “Local equipment and cross-connect tests”...
Page 180 Stand-alone installation testing .................................................... Completed Section and chapter Procedure Required “OC-48 PTM equipped low-speed testing See Note 1 procedure” (p. 6-38) “LED test” (p. 6-41) “Office alarm test” (p. 6-43) See Note 1 “Automatic protection switching and alarm See Note 1 test”...
Page 181 Software installation Circuit pack installation ® Use of WaveStar CIT software Circuit pack program version verification 5-12 Alcatel-Lucent 1850 TSS-60 shelf initialization 5-14 Tools, test equipment and accessories Listed below are the required tools, test equipment and accessories. Quantity Description Comments ®...
Page 182: Stand-Alone Node Setup
Stand-alone node setup .................................................... Quantity Description Comments CIT Interface Cable 8-ft. long RJ45 to 9-pin D-sub serial cable (Comcode 848748869). Required to connect the PC to the CIT jack on the front of the SYSCTL circuit pack. CIT Cross-Over Cable This cable is used for IAO LAN (OSI/TCP-IP) Front LAN connection cross over cable should be used if the shelf...
Page 183: Software Installation
® Installation of the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) WaveStar CIT software is covered in detail in the Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0.0 Software Release Description (SRD), which is provided with the software CD. To install the CIT software, please follow the procedures in the “Installing software and documentation on a PC”...
Page 184: Circuit Pack Installation
Description This section provides instructions and the recommended order for installing (fully seating) the circuit packs in the Alcatel-Lucent 1850 TSS-60 shelf. The procedures in this section assume that the SYSCTL is installed and operational. Locations of circuit packs (function unit slots) are shown in Figure 4-2, “Alcatel-Lucent...
Page 185 Appendix C, “PTM modules” for proper insertion............................................Connect IN to OUT on the OLIU in the M1 slot of the Alcatel-Lucent 1850 TSS-60 shelf using an optical fiber jumper cable and a 15-dB LBO. Refer to Appendix B, “Fiber cleaning”...
Page 186 Stand-alone node setup Circuit pack installation .................................................... Connect IN to OUT on the OLIU in the M2 slot of the Alcatel-Lucent 1850 TSS-60 shelf using an optical fiber jumper cable and a 15-dB LBO. CAUTION Equipment damage The LNW38, LNW40, LNW51, LNW140, LNW380 and LNW601 OLIU circuit packs are equipped with optics that do not meet GR-78 R9-3 requirements on ESD susceptibility.
Page 187 Stand-alone node setup Circuit pack installation ..............................................................................................If there are any FAULT LEDs on or flashing on any of the inserted circuit packs; press the UPD/INIT pushbutton on the SYSCTL circuit pack. Result: The operation of the UPD/INIT pushbutton on the SYSCTL circuit pack will update the system and should clear any flashing FAULT LEDs on any of the low speed circuit packs.
Page 188: Use Of Wavestar ® Cit Software
Description ® Complete the following steps to login to the Alcatel-Lucent 1850 TSS-60 via WaveStar CIT. It is assumed that the CIT software has been installed on the PC and the LNW2 system controller is installed and operational to the Alcatel-Lucent 1850 TSS-60 shelf per the Software Release Description.
Page 189 ® Stand-alone node setup Use of WaveStar CIT software ..............................................................................................(Optional see note) Enter the following in the Login window: Note: User ID and case sensitive. password are User ID: LUC01 Password: LUC+01 Note: When the CIT is installed there is an optional step to enable or disable CIT logins.
Page 190 ® Stand-alone node setup Use of WaveStar CIT software ..............................................................................................The following is displayed............................................NE Name Under , enter ALU-TSS-60............................................NE Type Under click on the drop down menu arrow and choose 1850TSS-60 from the drop-down list............................................
Page 191 ® Stand-alone node setup Use of WaveStar CIT software ..............................................................................................The following screen will appear: ............................................Familiarize yourself with different aspects of the Graphical presentation of a shelf including tool bars and menu bars............................................Check off the appropriate box in “Installation checklist”...
Page 192: Circuit Pack Program Version Verification
SYSCTL is installed and the circuit packs have been installed in the shelf as described in the preceding sections. Circuit pack program version verification procedure Proceed as follows: ............................................Log on to the Alcatel-Lucent 1850 TSS-60 shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p. 5-8).
Page 193 ............................................Compare the Program Version: again for the circuit pack just reseated and if it still does not match the table, refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-60), Release 2.0 Maintenance and Trouble-Clearing Guide, 365-372-602R2.0 for detailed troubleshooting procedures.
Page 194: Alcatel-Lucent 1850 Tss-60 Shelf Initialization
Shelf initialization procedure Proceed as follows: ............................................Log on to the Alcatel-Lucent 1850 TSS-60 shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p.
Page 195: Stand-Alone Installation Testing
Purpose The purpose of this section is to verify proper transmission cabling installation and Release 2.0 functionality as well as the associated functionality of the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) shelf. For end-to-end turn-up and testing procedures, refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 User Provisioning Guide —...
Page 196 Stand-alone installation testing .................................................... External timing verification 6-56 Miscellaneous (environmental) discrete telemetry test 6-59 Modem connection test 6-62 Final operations 6-65 .................................................... 6 - 2 365-372-603R2.0 Issue 1 January 2009...
Page 197 848748869). Required to connect the PC to the CIT jack on the front of the SYSCTL circuit pack. LAN 10BaseT As required to reach from front of Alcatel-Lucent 1850 Straight-through TSS-60 to the RJ45 patch panel Cable CAT 5 or better ....................................................
Page 198 Stand-alone installation testing .................................................... Quantity Description Comments ® Personal Computer (PC) Required to run the WaveStar software. CIT Interface Cable 8-ft. long RJ45 to 9-pin D-sub serial cable (Comcode 848748869). Required to connect the PC to the CIT jack on the front of the SYSCTL circuit pack.
Page 199: Stand-Alone Installation Testing
Follow this procedure to set the LBOs for the DS1/E1, DS1/DS3/16/3, DS3/EC-1, and TMUX circuit packs. Setting DS1/E1 LBOs ............................................Log on to the Alcatel-Lucent 1850 TSS-60 shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p.
Page 200 Stand-alone installation testing LBO software settings ..............................................................................................Select Line Build Out 20 (0,133) from the drop-down window............................................Select Apply to: All Ports, This Pack ............................................Apply Click to issue the command. Result: All DS1/E1 ports will have a LBO value of 20 for this pack. Setting DS3/EC1 LBOs The DS3/EC-1 cabling will be tested with all ports provisioned for DS3.
Page 201 Stand-alone installation testing LBO software settings ..............................................................................................Select Apply to: All Ports, This Pack ............................................Apply Click to issue the command. Result: All DS3 ports will have a LBO value of In for this pack............................................Check off the appropriate box in “Installation checklist”...
Page 202: Clearing Alarms
Clearing alarms Description In order to clear standing alarms the Alcatel-Lucent 1850 TSS-60 synchronization will be optioned for “Free Running.” The DCC will be disabled in order to prevent DCC alarms from being generated due to the optical loopback on the main OLIUs.
Page 203 Stand-alone installation testing Clearing alarms ..............................................................................................Click Apply to send the command............................................If there are any FAULT LEDs on or flashing, press the UPD/INIT pushbutton on the SYSCTL circuit pack. Note: LNW16/LNW19B (DS3/EC1), LNW18/LNW20 (48TMUXDS3EC1), LNW111 (3DS3) and LNW39/LNW391/LNW84 (DS1/DS3/16/3) circuit packs require a 75-ohm termination at the DSX-3 on all ports.
Page 204: Local Equipment And Cross-Connect Tests
The tests in this section verify the proper operation of the circuit packs and the circuit pack positions in the Alcatel-Lucent 1850 TSS-60 shelf. It verifies proper cabling from the Alcatel-Lucent 1850 TSS-60 to the DSX cross-connect panel or connecting equipment.
Page 205: Ds1/E1 Testing
.................................................... DS1/E1 testing DS1/E1 testing procedure Perform the following steps for all Alcatel-Lucent 1850 TSS-60 shelf function unit slots that are cabled to a DSX-1. Function unit slot A/B must be cabled to the DSX-1 and must contain a DS1/DS3/16/3 (LNW39/LNW391/LNW84), 16/DS1 (LNW112) or OC-3/16DS1 (LNW40) circuit pack in order to perform these tests on the DS1/E1 portion of the cabling.
Page 206 Stand-alone installation testing DS1/E1 testing ..............................................................................................Select Next............................................Select Rate= VT1.5: Type of Cross-connect= UPSR Add/Drop............................................Select Next............................................Select Range= Single VT............................................Select m1-1-1-1-1 to a1-1-1-1 (if using a combo card) or [d,g] if using the function slots............................................
Page 207 Stand-alone installation testing DS1/E1 testing ..............................................................................................main (OC-N). Click on the ............................................Double click on port 1 (OC-N)............................................Select Next............................................Select Next............................................Select Finish............................................Click Yes............................................Click Yes. Result: The DS-1 test set should indicate a blue (AIS) signal is being received in place of the QRSS signal.
Page 208 Stand-alone installation testing DS1/E1 testing ..............................................................................................Repeat Step 2 through Step 27 to test each of the remaining DS-1 tributaries of the function unit, substituting the following address information. Tributary @ DSX-1 Cross-connect m1-1-1-1-2,a1-1-1-2 m1-1-1-1-3,a1-1-1-3 m1-1-1-1-4,a1-1-1-4 m1-1-1-2-1,a1-1-2-1 m1-1-1-2-2,a1-1-2-2 m1-1-1-2-3,a1-1-2-3 m1-1-1-2-4,a1-1-2-4 m1-1-1-3-1,a1-1-3-1 m1-1-1-3-2,a1-1-3-2...
Page 209 LNW140/LNW84 without optics in the main slots. Facility Loopback testing allows the installer to verify the electrical cabling to the Alcatel-Lucent 1850 TSS-60 NE. Follow the procedure below to perform a facility loopback test at the Alcatel-Lucent 1850 TSS-60 shelf.
Page 210 Stand-alone installation testing DS1/E1 testing ..............................................................................................Select Choose the DS1/E1 port to test and click ............................................Operate Loopback Type: Facility Apply Select and click ............................................Once the loopback is up, a test signal shall be generated at the DS1/E1 terminating equipment which will verify that the cabling is correct.
Page 211: Ds3/Ec1 Testing
DSX-3 ports called out in the procedure. If the Alcatel-Lucent 1850 TSS-60 shelf is not fully populated, it may be necessary to move the circuit pack(s) from slot to slot in order to test all DS3/EC-1 cabling.
Page 212 M13 should be used to test LNW39/LNW391/LNW84 (DS1/DS3/16/3)............................................Connect a cable from the DS3 test set transmit connection to the IN jack of the DSX-3 associated with the first DS3 tributary of the Alcatel-Lucent 1850 TSS-60 function unit slot to be tested............................................
Page 213 Stand-alone installation testing DS3/EC1 testing ..............................................................................................Click Configuration:Cross-Connections............................................Select Create a new cross-connection............................................Select Next............................................Select Rate= STS1: Type of Cross-connect= UPSR Add/Drop............................................Select Next............................................Select main1-1-1 to [b,d,g]1-1............................................Click Finish to issue the command. Requirement: The DS3 test set should indicate it is receiving an error free PRBS signal.
Page 214 Stand-alone installation testing DS3/EC1 testing .................................................... Verify that the port is provisioned for DS3. • Check the DS3/EC1 cabling for proper connections. • ............................................Use the GUI command to delete the cross-connect............................................Click Configuration:Cross-Connections............................................Select Delete legs of an Existing cross-connection............................................
Page 215 Stand-alone installation testing DS3/EC1 testing ..............................................................................................upd-sys Use the e to send an command............................................Configuration -> Update System -> Update All Click on ............................................Repeat Step 2 through Step 26 to test cabling to each of the remaining DS3 tributaries of the function unit.
Page 216 ................................ DS3 terminating equipment loopback testing (LNW84 without optics) Perform this test when the Alcatel-Lucent 1850 TSS-60 is equipped with LNW84 without optics in the main slots. Facility loopback testing allows the installer to verify the electrical cabling to the Alcatel-Lucent 1850 TSS-60 NE.
Page 217 Stand-alone installation testing DS3/EC1 testing .................................................... Result: If any errors are detected while performing this "wiggle test," the BNC connector must be cut off and replaced. If an error free signal is not received: View -> Equipment Check the LBOs settings using (see “Setting DS1/E1 LBOs”...
Page 218: Lnw74 And Lnw66 Testing
(C848748869) LAN 10BaseT Straight-through As required to reach Cable from front of Alcatel-Lucent 1850 TSS-60 to the RJ45 patch panel Ethernet port assignment verification testing ............................................Connect the Front CIT cable between the PC and the CIT/RS 232 port of the System Controller and login to the shelf using the serial connection and the GUI options on ®...
Page 219 Stand-alone installation testing LNW74 and LNW66 testing ..............................................................................................Verify that the port you are connected to matches the one listed in the aid of the FE-LAN LOS alarm output............................................Configuration -> Update System -> Update All. Select ............................................Click to issue the command.
Page 220 Result: Successful login to the Alcatel-Lucent 1850 TSS-60............................................Log out of the Alcatel-Lucent 1850 TSS-60 shelf............................................At the RJ45 Ethernet patch panel disconnect the RJ45 Ethernet cable run to the PC Ethernet port and connect it to the next position on the RJ45 Ethernet patch panel to be tested.
Page 221 RJ45 patch panel connected to the LNW66 under test, then continue on to Step ............................................Disconnect the PC from the RJ45 patch panel and the Alcatel-Lucent 1850 TSS-60 LAN port from the RJ45 patch panel............................................If not still connected from the previous procedure. Connect the Front CIT cable between the PC and the CIT/RS 232 jack of System Controller and login to the shelf using the serial connection.
Page 222: Oc-3 Low-Speed Testing
PTMs to ports that are fibered. LBOs are installed on the OLIU faceplate IN port............................................Beginning from the Top (G) side of the Alcatel-Lucent 1850 TSS-60 shelf, locate the first function unit slot position that contains an LNW37 circuit pack............................................
Page 223 Result: The flashing FAULT LED should extinguish on the OC-3 OLIU. There should be no alarm indications on the Alcatel-Lucent 1850 TSS-60 shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-3 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 224 PTMs to ports that are fibered. LBOs are installed on the OLIU faceplate IN port............................................Beginning from the Top (G) of the Alcatel-Lucent 1850 TSS-60 shelf, locate the first function unit slot position that contains an LNW45 or LNW55 circuit pack............................................
Page 225 Result: The flashing FAULT LED should extinguish on the OC-3 OLIU. There should be no alarm indications on the Alcatel-Lucent 1850 TSS-60 shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-3 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 226 OLIU for the remaining ports on the LNW45 and the LNW55 circuit packs............................................Repeat this entire procedure for each LNW45 and LNW55 equipped in the Alcatel-Lucent 1850 TSS-60 shelf............................................Replace all protective dust covers on the LNW45 and LNW55 PTM connectors (OLIU and LGX), that were removed to perform this procedure.
Page 227: Oc-12 Low-Speed Testing
PTMs to ports that are fibered. LBOs are installed on the OLIU faceplate IN port............................................Beginning from the top (G) of the Alcatel-Lucent 1850 TSS-60 shelf, locate the first function unit slot that contains an OC-12 OLIU circuit pack............................................
Page 228 Result: The flashing FAULT LED should extinguish on the OC-12 OLIU. There should be no alarm indications on the Alcatel-Lucent 1850 TSS-60 shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-12 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 229 OLIU ports............................................Repeat this entire procedure for each LNW49 or LNW55 PTM equipped in the Alcatel-Lucent 1850 TSS-60 shelf............................................Replace all protective dust covers on the LNW49 or LNW55 PTM OC-12 OLIU connectors (OLIU and LGX), that were removed to perform this procedure.
Page 230: Oc-48 Low-Speed Testing
LBOs are installed on the OLIU faceplate IN port............................................Beginning from the top (G) of the Alcatel-Lucent 1850 TSS-60 shelf, locate the first function unit slot that contains an OC-48 OLIU circuit pack............................................
Page 231 Click on the Result: The flashing FAULT LED should extinguish on the OC-48 OLIU. There should be no alarm indications on the Alcatel-Lucent 1850 TSS-60 shelf............................................Repeat this entire procedure for each low speed OC-48 circuit pack equipped in the Alcatel-Lucent 1850 TSS-60 shelf.
Page 232 “Safety”. Note: The LNW62, LNW55 and LNW402 circuit packs require the LNW141 or LNW84 be installed in the main slots to operate in a Alcatel-Lucent 1850 TSS-60 shelf. Note: When reference is made to optical fiber loopback connections to IN and OUT on the OLIU, make the connections at the LGX equipment in order to verify correct installation and labeling of the fibers.
Page 233 Result: The flashing FAULT LED should extinguish on the OC-48 OLIU. There should be no alarm indications on the Alcatel-Lucent 1850 TSS-60 shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-48 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 234 Stand-alone installation testing OC-48 low-speed testing ..............................................................................................Replace all protective dust covers on the LNW62, LNW55, LNW402 PTM OC-48 OLIU connectors (OLIU and LGX), that were removed to perform this procedure............................................Check off the appropriate box in “Installation checklist” (p. II-5).
Page 235: Led Test
.................................................... LED test Description This test verifies proper operation of all LEDs on the Alcatel-Lucent 1850 TSS-60 circuit packs. Operation of all the LEDs is necessary to assist in trouble isolation. Note: If there are any LED failures, determine if the problem is with the circuit pack or shelf and replace the faulty unit.
Page 236 Stand-alone installation testing LED test ..............................................................................................Check off the appropriate box in “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 4 2 365-372-603R2.0 Issue 1 January 2009...
Page 237: Office Alarm Test
“Office alarm connections” (p. 6-44) lists the office alarms connections. It is a requirement that alarms on the Alcatel-Lucent 1850 TSS-60 do not affect and • are not affected by other equipment via office alarm connections. During this test, the...
Page 238: Office Alarm Connections
Proceed as follows: ............................................Connect the office alarm cable to J13 (ALM) on the backplane of the Alcatel-Lucent 1850 TSS-60 shelf. If the shelf to be tested is part of a multiple shelf bay arrangement, the office alarm cable connects to shelf 1.
Page 239 Stand-alone installation testing Office alarm test ..............................................................................................Establish a CIT session by following the procedure in Chapter 5, “Stand-alone node ® setup”, “Use of WaveStar CIT software” (p. 5-8)............................................Use the to enter the cross-connect command............................................Configuration -> Cross Connection -> Create new cross-connection Click on ............................................
Page 240 Stand-alone installation testing Office alarm test ..............................................................................................View -> Cross-Connections Click on ............................................Shelf Select ............................................Select Click to issue the command. Result: The View Cross-Connection window will open displaying the cross-connect that was just entered............................................Unseat one of the LNW7, LNW8, LNW111, LNW16, LNW18, LNW20, LNW19B, LNW112, LNW801 or LNW39/LNW391 circuit packs from the function group being used.
Page 241 Stand-alone installation testing Office alarm test ..............................................................................................Press the ACO pushbutton on the SYSCTL. Result: Activated office alarm: CR visual. The CR audible alarm should clear............................................Reconnect the optical fiber jumper removed in Step 19 and reseat the pair of function units.
Page 242: Automatic Protection Switching And Alarm Test
Automatic protection switching and alarm test .................................................... Automatic protection switching and alarm test Description This section provides the procedures for verifying the Alcatel-Lucent 1850 TSS-60 shelf automatic protection switching. Note the following: These tests do NOT simulate circuit pack failures.
Page 243 Stand-alone installation testing Automatic protection switching and alarm test .................................................... LNW40, LNW140, LNW601, LNW38, LNW51, LNW380, LNW41, LNW141 or • LNW84 ............................................® Establish a CIT session by following the procedure under “Use of WaveStar software” (p. 5-8)............................................View -> Cross-Connections Click on the ............................................
Page 244 Stand-alone installation testing Automatic protection switching and alarm test ..............................................................................................Reconnect the optical fiber to the OLIU. Result: After a short time, the MN and NE alarm LEDs on the SYSCTL and the FAULT LED on the OLIU should extinguish............................................
Page 245 Stand-alone installation testing Automatic protection switching and alarm test .................................................... Result: The ACTIVE LED on the reseated circuit pack lights. The FAULT LED on the circuit pack will light for several seconds then extinguish. On the SYSCTL, the CR alarm extinguishes and the MN alarm and the NE LED will be lit.
Page 246: Manual Switching Tests
Stand-alone installation testing Manual switching tests .................................................... Manual switching tests Description ® This test will initiate switching commands from the WaveStar GUI and verify proper switching and LED indications. Main OLIU switch test Note: An STS-1 cross-connect should still exist from the previous tests............................................
Page 247 Stand-alone installation testing Manual switching tests ..............................................................................................View -> Protection -> Path Protection Verify the active path, with the command. Result: The path selected in the previous steps will have switched to the other path and a ABN condition will be displayed on the GUI............................................
Page 248 Stand-alone installation testing Manual switching tests .................................................... Result: View Equipment Window should display information on the selected circuit pack indicating which function unit and/or growth slot circuit pack is active and which is standby............................................Note which function unit or growth slot circuit pack is the active circuit pack from the previous result.
Page 249 Stand-alone installation testing Manual switching tests ..............................................................................................Repeat this procedure for each function unit and/or growth slot pair............................................Check off the appropriate box in “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 5 5 365-372-603R2.0 Issue 1 January 2009...
Page 250: External Timing Verification
External timing verification Description This test should be performed if the Alcatel-Lucent 1850 TSS-60 shelf is going to be externally timed. The shelf timing cable must be installed and connected between the Alcatel-Lucent 1850 TSS-60 shelf and the office timing source (BITS clock) and the timing source must be active.
Page 251 • Note: If a reference does not indicate is, that input is not receiving a proper timing reference. Verify: – Cabling between the timing source and the Alcatel-Lucent 1850 TSS-60 shelf – Correct line coding – Correct frame format ............................................
Page 252: Alcatel-Lucent 1850 Tss-60 Shelf Backplane
Stand-alone installation testing External timing verification .................................................... Figure 6-1 Alcatel-Lucent 1850 TSS-60 shelf backplane ............................................View -> Timing/Sync Click on the ............................................View Timing/Sync window will display. Result: Timing Input Ports tab should display: That the reference that is disconnected is Out of Service.
Page 253: Miscellaneous (Environmental) Discrete Telemetry Test
Procedure Proceed as follows: ............................................Determine which environmental inputs are to be monitored via the Alcatel-Lucent 1850 TSS-60 shelf............................................Verify that the miscellaneous discrete cable is connected to the J20 MISC connector on the shelf.
Page 254: Miscellaneous (Environmental) Discrete Functions
Stand-alone installation testing Miscellaneous (environmental) discrete telemetry test ..............................................................................................Click Result: The NE Alarm List report window is opened and should display the correct environmental alarm has been activated............................................Remove the short and verify that the minor (MN) alarm indication on the SYSCTL clears............................................
Page 255: Miscellaneous (Environmental) Discrete Telemetry Connections
Stand-alone installation testing Miscellaneous (environmental) discrete telemetry test .................................................... Table 6-2 Miscellaneous (environmental) discrete telemetry connections Conn. Pin# Color Designation Name BL-W TLMI1 Env. Input - #1 W-BL TLMI2 Env. Input - #2 TLMI3 Env. Input - #3 TLMI4 Env. Input - #4 TLMI5 Env.
Page 256: Modem Connection Test
Stand-alone installation testing Modem connection test .................................................... Modem connection test Description This test will verify proper modem connection to the Alcatel-Lucent 1850 TSS-60 shelf. This test should only be performed if a modem is required. Procedure Proceed as follows: ............................................
Page 257 A LU- TSS- 60 A LU0 1 1 850 TSS -60 act-user: :ctag:: Result: A message indicating that the command completed will be displayed along with the Alcatel-Lucent disclosure............................................Enter the command: A LU-T SS- 60 A LU0 1 canc-user: :ctag;...
Page 258 Stand-alone installation testing Modem connection test ..............................................................................................Check off the appropriate box in “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 6 4 365-372-603R2.0 Issue 1 January 2009...
Page 259: Final Operations
Final operations .................................................... Final operations Description The following procedure ensures that all test signals and cross-connects have been removed and the Alcatel-Lucent 1850 TSS-60 shelf is alarm free and ready for network connection procedures. Procedure Proceed as follows: ............................................Use the to View and Delete any cross-connects that were entered.
Page 260 Stand-alone installation testing Final operations ......................................................................................................6 - 6 6 365-372-603R2.0 Issue 1 January 2009...
Page 261: Part Iii: Network Turn-Up And Testing
“Installation checklist” to follow when installing a Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) system. Use of the installation checklist is required to ensure a quality installation. All completed tasks should be checked off and those not completed should be duly noted as to the reason why.
Page 262 LC-type Optical Fiber Two optical fiber jumpers with LC type connectors are Jumper ITE-7169 required to optically loop the Alcatel-Lucent 1850 (108918269) TSS-60 shelf for test purposes. In addition, for shelves containing optical circuit packs in any of the function unit slots, a single optical fiber jumper is required for testing of the individual ports.
Page 263 Luminex Cloth R-6033 5.5” x 5.5” ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1850 TSS-60. Quantity Description Comments Personal Computer PC minimum requirements below.
Page 264 Network turn-up and testing .................................................... Installation checklist Completed Section and chapter Procedure Required Part III: “Network turn-up and testing” Chapter 7, “Connecting “Fiber installation” (p. 7-4) adjacent network elements” “Optical transmission test (OC-192, OC-48, See Note 1 OC-12, OC-3)” (p. 7-11) “Automatic protection switching test”...
Page 265 This procedure is used to make fiber connections between nodes in a ring. It is not intended to replace acceptance test procedures. If problems are encountered, refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Maintenance and Trouble Clearing Guide — 365-372-602R2.0 for detailed troubleshooting procedures.
Page 266: Connecting Adjacent Network Elements
Connecting adjacent network elements .................................................... Tools, test equipment and accessories Listed below are the tools, test equipment and accessories necessary to perform the procedures in this section. Quantity Description Comments Screwdriver(s) A screwdriver(s) with the appropriate head(s) is (are) required for securing the mounting screws, repositioning the mounting brackets, installing the interfacing cables, and for setting the circuit breakers to...
Page 267 Connecting adjacent network elements .................................................... Safety instructions Note: All precautions should be observed when handling fiber. WARNING Laser hazard Unterminated optical connectors may emit laser radiation. Do not view beam with optical instruments. CAUTION The operational tests in this section are run only in an out-of-service mode of operation.
Page 268 Verify that the office alarm cable to J13 (ALM) on the backplane of the Alcatel-Lucent 1850 TSS-60 shelf is disconnected. If the shelf to be tested is part of a multiple shelf bay arrangement, the office alarm cable connects to shelf 1.
Page 269: Connecting Adjacent Network Elements Fiber Installation
Connecting adjacent network elements Fiber installation ..............................................................................................Use the Graphical User Interface (GUI) to enable the AGNE at ALU-TSS-60-1 only............................................Administration -> Set NE... Click on ............................................Set NE window In the click on: Remote NE Status: Enabled •...
Page 270 (OC-3, OC-12 or OC-48) using 0x1 protection, the Function Group slot (D, or G) 1 will connect to Main 2 on whatever shelf the Alcatel-Lucent 1850 TSS-60 is being connected to. The Function Group slot (D, or G) 2 will connect to Main 1.
Page 271: Attenuation Table
Connecting adjacent network elements Fiber installation ..............................................................................................Determine the LBO value required based on the received optical power measurement. Refer to the following table and attenuate appropriately. Table 7-1 Attenuation table Received power Optics Circuit pack (dBM) (dB) OC-3 (high LNW40 -8.0 to -28.0 speed)
Page 272 Connecting adjacent network elements Fiber installation .................................................... Received power Optics Circuit pack (dBM) (dB) SFP (Small LNW37/45/55 OC-3 SR-1 -8.0 to -23.0 form-factor LNW37/45/55 OC-3 IR-1 -8.0 to -28.0 pluggable) optics LNW37/45/55 OC-3 LR-1 0.0 to -5.0 -5.0 to -10 -10 to -34.0 LNW49/55 OC-12 -8.0 to -28.0...
Page 273 At the other end, verify that the associated FAULT LED is flashing, indicating a loss of signal. Reconnect the fiber and repeat the process for the other direction of transmission............................................In order to enable communications with the adjacent Alcatel-Lucent 1850 TSS-60 nodes, ............................................Configuration -> DCC Terminations Use the to turn off the DCCs.
Page 274 ............................................Click to issue the command............................................In order to verify proper communications with the adjacent Alcatel-Lucent 1850 TSS-60 nodes, execute the following command from the Administration -> OSI-Neighbor-Map Result: The TIDs and NSAPs of adjacent nodes will be displayed along with the OLIU and port they are connected to.
Page 275: Optical Transmission Test (Oc-192, Oc-48, Oc-12, Oc-3)
Connecting adjacent network elements Optical transmission test (OC-192, OC-48, OC-12, OC-3) .................................................... Optical transmission test (OC-192, OC-48, OC-12, OC-3) Procedure Proceed as follows: ............................................Performance -> Initialize PM Registers. Use the command: ............................................Both Click on the ............................................Click to execution command............................................
Page 276 Result: OCn Line PM Report window indicates no transmission errors............................................Repeat Step 1 through Step 13 for all Alcatel-Lucent 1850 TSS-60 shelves at the test location............................................Repeat Step 1 through Step 13 for each node in the ring.
Page 277: Automatic Protection Switching Test
Connecting adjacent network elements Automatic protection switching test .................................................... Automatic protection switching test Description This section provides the procedures for verifying the Alcatel-Lucent 1850 TSS-60 shelf automatic and manual protection switching. Note the following: These tests do NOT simulate circuit pack failures. •...
Page 278 Connecting adjacent network elements Automatic protection switching test ..............................................................................................Reconnect the optical fiber to the OLIU. Result: After a short time, the MJ alarm LED on the SYSCTL and the FAULT LED on the OLIU should extinguish............................................Repeat Step 2 through Step 8...
Page 279: Manual Switching Tests
Connecting adjacent network elements Manual switching tests .................................................... Manual switching tests Description This test will initiate switching commands from the CIT and verify proper switching and LED indications. Note: An STS-1 cross-connect is required in order to perform manual switching. Manual switching test procedure ............................................
Page 280 Connecting adjacent network elements Manual switching tests .................................................... Function units/growth slots switching test This test will initiate switching commands from the CIT and verify proper switching and LED indications. Note: This procedure should be performed on each function unit equipped with protected electrical TDM circuit packs.
Page 281 Connecting adjacent network elements Manual switching tests ..............................................................................................Check off the appropriate box in “Installation checklist” (p. III-4). T E P S ..................................................................................7 - 1 7 365-372-603R2.0 Issue 1 January 2009...
Page 282: Final Operations
Final operations .................................................... Final operations Description The following procedure ensures that all test signals and cross-connects have been removed and the Alcatel-Lucent 1850 TSS-60 shelf is alarm free and ready for network connection procedures. Procedure Proceed as follows: ............................................View -> Cross-Connections...
Page 283 ............................................Verify that no alarm LEDs are lit and no FAULT LED is lit on any circuit pack. If any alarm is present, refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Maintenance and Trouble Clearing Guide — 365-372-602R2.0.
Page 284 Connecting adjacent network elements Final operations ..............................................................................................Check off the appropriate box in “Installation checklist” (p. III-4). T E P S ..................................................................................7 - 2 0 365-372-603R2.0 Issue 1 January 2009...
Page 285 Overview Purpose This chapter is used to verify WDMX connectivity between Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) nodes. The chapter includes the LNW785 8 channel Optical Multiplexer Demultiplexer (OMD) circuit pack. It is not intended to replace acceptance test procedures.
Page 286: Wdmx Setup And Testing: Integration Procedures
WDMX setup and testing: integration procedures .................................................... How to use this chapter All of the sections in this chapter are stand alone procedures and are not intended to be followed in any sequence. Locate the procedure in this chapter and follow the procedure based on the requirements of the turn-up.
Page 287: Wdmx Setup And Testing: Integration Procedures
WDMX setup and testing: integration procedures .................................................... WARNING Laser hazard Unterminated optical connectors may emit laser radiation. Do not view beam with optical instruments. CAUTION The operational tests in this section are run only in an out-of-service mode of operation. Office alarms will normally be connected only during the office alarm test to prevent constant alarms throughout this section.
Page 288: Turn-Up And Test The Lnw785 8 Channel Omd
............................................Determine and document the test signal frequency............................................Install the LNW785 into the Alcatel-Lucent 1850 TSS-60 shelf by opening both faceplate latches and seating in the slot while closing the latches. Note: The LNW785 can be installed in any Function/Growth slot. When the shelf is to be configured as an add/drop, it is recommended that the Growth slots are not used because the passthrough fibers would have to route over the SYSCTL.
Page 289 ............................................Perform end-to-end testing. Follow the end to end testing procedures determined by the input test signal. If the test signal is the Alcatel-Lucent 1850 TSS-60 as part of a ring, proceed to Chapter 8, “WDMX setup and testing: integration procedures”...
Page 290: Connecting The Ring (Mains) To The Wdmx
Note: Only the first 4 wavelengths can be used in the LNW141, PTMs X10G52C5 through X10G55C5............................................® Login to the Alcatel-Lucent 1850 TSS-60 using the WaveStar CIT............................................Provision the PTM/OTU-2 Select Configuration --> Equipment from the System View ............................................
Page 291 WDMX setup and testing: integration procedures Connecting the ring (Mains) to the WDMX ..............................................................................................Enter the Frequency in the Expected Frequency and click Apply, then Close. Note: The frequency is determined by the PTM inserted in Port 9. See the LNW785 column in Table 8-1, “Channel/port assignments”...
Page 292 WDMX setup and testing: integration procedures Connecting the ring (Mains) to the WDMX ..............................................................................................Check off the appropriate box in the “Installation checklist” (p. III-4). T E P S ..................................................................................8 - 8 365-372-603R2.0 Issue 1 January 2009...
Page 293: Removing Provisioning And Equipage From The Lnw785
Description This section provides procedures on how to properly remove provisioning from the Alcatel-Lucent 1850 TSS-60 shelf once testing is completed and the equipment/ports are no longer needed. Locate the procedure below to remove the equipment and return the Alcatel-Lucent 1850 TSS-60 back to the original status.
Page 294 III-4). T E P S ................................ Delete LNW785 circuit pack ............................................Remove the LNW785 circuit pack from the Alcatel-Lucent 1850 TSS-60 shelf............................................Update the Alcatel-Lucent 1850 TSS-60 inventory Select Configuration --> Update System --> Update Inventory ............................................Click Yes to acknowledge the request.
Page 295: Channel/Port Assignments
WDMX setup and testing: integration procedures Removing provisioning and equipage from the LNW785 .................................................... Table 8-1 Channel/port assignments Apparatus LNW785 Code Channel LNW705 Frequency X10G52C5 9520 9520 195200 GHz X10G53C5 9530 9530 195200 GHz X10G54C5 9540 9540 195200 GHz X10G55C5 9550 9550 195200 GHz...
Page 296 WDMX setup and testing: integration procedures Removing provisioning and equipage from the LNW785 .................................................... Received power Optics Circuit pack (dBM) (dB) OC-192 VLF LNW141, LR-2 Optics +4.0 to 0.0 high speed PTM 0.0 to -7.0 (pluggable transmission -7.0 to -24.0 module) optics LNW141, IR-2 Optics +2.0 to -1.0...
Page 297: Part Iv: Miscellaneous Detailed Installation Procedure And Reference Material
Overview Purpose This section provides supplementary information that is useful when installing the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) system and using this Installation and System Turn-up Guide. This section is comprised of the following appendixes: Technical support...
Page 298 Miscellaneous detailed installation procedure and reference material ......................................................................................................IV- 2 365-372-603R2.0 Issue 1 January 2009...
Page 299 Technical support Overview Purpose This appendix provides important technical assistance information for the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60). Contents This appendix contains the following sections Technical assistance Accessing and navigating the On-Line Customer Support (OLCS) web site Other technical support services A-12 ....................................................
Page 300: Technical Assistance
Repair and Replacement (R&R) - technical support services for device repair/return or • parts replacement. Alcatel-Lucent On-Line Customer Support (OLCS) - online access to information and • services that can help resolve technical support requests. Note: Technical Support Services are available 24 hours a day, 7 days a week.
Page 301 Alcatel-Lucent product technical issue. When additional assistance is required, the Alcatel-Lucent Welcome Center is the first point of contact. An Alcatel-Lucent Welcome Center operator can direct the request to engineers that are highly trained and skilled in resolving issues, involving Alcatel-Lucent products.
Page 302 OLCS web site and view ARs 24 hours a day, 7 days a week. Data Drop Box The Data Drop Box feature allows Alcatel-Lucent support technicians to provide customers with a quick method to share files. The Data Drop Box allows a technician to provide or receive a file from a customer quickly.
Page 303 Technical support Technical assistance .................................................... – Modification Implementation Procedure (MIP) – User Guide – Alarm Messaging and Trouble Clearing Guide (AMTCG) – Framework User Guide – Graphical User Interface (GUI) Guide – Maintenance Guide, Provisioning Guide – User Operations Guide (UOG) Technical Notes •...
Page 304 Note: This may not apply to all products. The RMA area provides a list of contact information on all Alcatel-Lucent products. There is a “request an RMA number” on-line for most Alcatel-Lucent products. An RMA number is required for all returned parts and this feature provides you with an easy method to obtain the RMA number.
Page 305: Accessing And Navigating The On-Line Customer Support (Olcs) Web Site
(if necessary), and navigate to each feature listed in this document. Accessing the OLCS web site To access the Alcatel-Lucent OLCS web site, enter: www.alcatel-lucent.com/support. Once you are at this web page, select Lucent Global Support. This will bring you to the web site where you can log in to gain access to the entitled products.
Page 306 Please contact the in-country technical support hotline. Via email Use the email address: olcshelp@alcatel-lucent.com or use the site's “Contact Us” form Use the OLCS help desk number for OLCS access problems, registration questions, password resets, navigation questions, etc. View an OLCS website After you have logged into the OLCS web site, a personalized view of the Customer Support Home page is displayed.
Page 307 “My Bookmarks” section (if Data Drop Box has been added there). Click the “Upload a file” button in the Data Drop Box window to send a file to the Alcatel-Lucent support technician. An email address can also be entered so that the ....................................................
Page 308 Alcatel-Lucent technician will be notified when the file has been sent. Click the “Download a file” button from the Data Drop Box if the Alcatel-Lucent technician has sent a file to be downloaded. These files will remain on the site for 7 days.
Page 309 You can access Alcatel-Lucent Alerts from the left column on the Customer Support homepage (unless this view has been changed), from the “Technical Support” section in the center of the page, or from the “My Bookmarks” section (if Alcatel-Lucent Alerts is added there).
Page 310: Other Technical Support Services
Generally, customers should have a basic understanding of digital fundamentals and lightwave transmission systems. In addition, customers should have taken a previous Alcatel-Lucent Operating & Maintenance course or have equivalent experience with operations and maintenance issues related to the product...
Page 311 Technical support Other technical support services .................................................... Workshop Location: This workshop will be delivered in the Customer Advocate System Test Labs in Westford, MA. The format is 75% hands-on lab exercises, reinforced with 25% classroom instruction. How to Sign Up: To enroll in the training course: Within the United States, •...
Page 312 Technical support Other technical support services ......................................................................................................A- 1 4 365-372-603R2.0 Issue 1 January 2009...
Page 313: B Fiber Cleaning
Overview Purpose This appendix describes the Alcatel-Lucent recommended method for the cleaning and inspection of optical connectors using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. It is critical that connector faces are clean and free from particular contamination to assure proper performance and reliability of lightwave systems.
Page 314: Fiber Cleaning
Related information A course on connector cleaning and the connector inspection process is now offered through Alcatel-Lucent University, Course Code: LMC200H “Understanding Fiber Optic Cleaning, Inspection and Testing.” To learn more about this course, consult your local Alcatel-Lucent Account Representative.
Page 315: Equipment Requirements And Recommendations
Fiber cleaning Equipment requirements and recommendations .................................................... Equipment requirements and recommendations Description For proper cleaning, the following equipment and materials are recommended: Table B-1 Required and recommended equipment and materials Installation Product Model/description Comcode ITE # order # Optical Fiber Scope Noyes OFS 300-200X 408197028 ITE-7129...
Page 316: Safety Instructions
Fiber cleaning Safety instructions .................................................... Safety instructions Safety warnings WARNING Laser hazard Never view an energized optical cable with the naked eye or with an optical magnifying instrument. Disconnected or separated optical connectors may emit invisible laser radiation and direct exposure can severely injure the eye. If inspecting the endface of a connector with a fiberscope, be absolutely certain that the system is deactivated.
Page 317: Cleaning/Inspecting Optical Connectors
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Cleaning/inspecting optical connectors Introduction The procedure that follows utilizes the “Wet/Dry” method for connector cleaning. This method first applies a “wet” solvent such as high purity alcohol to the connector endface to dissolve/remove any organic particulate or oily films, followed by a “dry” double clean wipe using the CLETOP cleaning cassette.
Page 318: Cleaning The Ferrule Endface
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Figure B-1 Cleaning the ferrule endface ............................................If a CLETOP cassette cleaner is not available, proceed with Step 7. Otherwise, hold the CLETOP cassette cleaner in the palm of your hand with the cassette shutter door facing up.
Page 319: Cletop Cleaner
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Figure B-2 CleTop cleaner ............................................Insert and press the connector ferrule endface perpendicular against the cleaning cloth in the first of two slots of the cleaner. See Figure B-3, “Acceptability criteria for fiber cleaning” (p. B-9).
Page 320 Fiber cleaning Cleaning/inspecting optical connectors ..............................................................................................Inspect the connector for cleanliness. If necessary, repeat the cleaning process. See “Connector inspection” (p. B-8). T E P S ................................ Connector inspection After cleaning the connector, inspect the ferrule endface to ensure that it is free from any particulate contamination using an optical fiber inspection scope of at least 200X magnification.
Page 321: Acceptability Criteria For Fiber Cleaning
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Figure B-3 Acceptability criteria for fiber cleaning Restricted Area Monitor 1/2 SM Core + 1/2 Fiber Viewing Diameters - 66 µm dia. Area No Loose or No Fixed Contamination No LOOSE contamination or particulate fibers in viewing area.
Page 322 Fiber cleaning Cleaning/inspecting optical connectors ..............................................................................................Using the appropriate CLETOP stick cleaner (2.5 mm for SC, ST, and FC connectors, 1.25 mm for LC connectors) dampen the stick cleaner with Ethyl alcohol using the alcohol wipe. Insert the stick cleaner into the adapter rotating the stick 360 degrees while inserting.
Page 323: Cleaning Pluggable Optics Module
.................................................... Cleaning pluggable optics module Purpose This task describes the Alcatel-Lucent recommended method for cleaning pluggable optics modules using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. Note: Pluggable optics modules are shipped with a water-tight process plug installed into the optical ports to maintain cleanliness during storage and/or transportation.
Page 324 Fiber cleaning Cleaning pluggable optics module .................................................... CAUTION This step should only be performed on the transmit (TX) port if the air blows did not work. Do not perform this step on the receive (RX) port. The receive (RX) port contains a lens for focusing a wide input. The lens is more easily scratched than cleaned.
Page 325: Cptm Installation
Overview Purpose This chapter describes the how to insert a Pluggable Transmission Module (PTM) into a Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) circuit pack. These PTMs were once referred to as Small Form Programmable (SFP)s. Contents This chapter contains the following:...
Page 326: Ptm Modules
PTM installation PTM modules .................................................... PTM modules Alcatel-Lucent approved Class 1 PTM transceivers The following table lists all the current approved PTM modules to be used with Alcatel-Lucent 1850 TSS-60. Table C-1 Alcatel-Lucent approved PTMs Optical module Compatible circuit Name...
Page 327 PTM installation PTM modules .................................................... Optical module Compatible circuit Name code/commode Description packs S2D27C6 OC-48 DWDM OC-48/STM16/OTU1 LNW41, LNW55, DWDM LNW62 109610410 192.7 THz/1555.747nm S2D31C6 OC-48 DWDM OC-48/STM16/OTU1 LNW41 DWDM 109610451 193.1 THz/1552.524nm S2D33C6 OC-48 DWDM OC-48/STM16/OTU1 LNW41 DWDM 109610477 193.3 THz/1550.918nm S2D35C6 OC-48 DWDM...
Page 328 PTM installation PTM modules .................................................... Optical module Compatible circuit Name code/commode Description packs GE-1X2XFC-LX-C1 GE-1X2XFC-LX-C1 GbE long-reach, Single LNW64, LNW70, (1000BASE-LX, 1Gbps 109527804 Mode PTM supports LNW170, LNW73, and 2Gpbs Ethernet, FICON and LNW73C, LNW78 Fibre-Channel/ Fibre-Channel traffic, FICON LC-type connectors (GbE/FC/2FC/-1310) OM1G//OMFC GE1X2XFC-SX-C1...
Page 329: Install Pluggable Modules
PTM installation Install pluggable modules .................................................... Install pluggable modules Task Complete the following steps to install pluggable optical modules in a circuit pack that has already been installed in a shelf............................................Determine the circuit pack and socket being equipped with the pluggable optical module............................................
Page 330: Module Types
PTM installation Install pluggable modules .................................................... Figure C-2 Module types Gold Fingers Port Gold Fingers Port Gold Fingers Port MA-DMX-445 Gold Fingers Port Gold Fingers Port Gold Fingers Port MA-DMX-439 .................................................... C - 6 365-372-603R2.0 Issue 1 January 2009...
Page 331 PTM installation Install pluggable modules .................................................... Gold Fingers Port Gold Fingers Port MA-DMX-442 ............................................Important! Pluggable optical modules are shipped with a dust plug installed into the optical ports to maintain cleanliness during storage and/or transportation. It is recommended that the dust plug be kept in place to maintain cleanliness until the optical fiber is connected.
Page 332 PTM installation Install pluggable modules ..............................................................................................Before inserting the module, the latch must be in the closed position. With the dust plug in place, the latch is in the closed position. Remove the dust plug momentarily to open the latch.
Page 333 If this data for any reason is not unique, both optical modules with the duplicated information will be declared failed. Refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-60) Release 2.0 Maintenance and Trouble Clearing Guide — 365-372-602R2.0.
Page 334 T E P S ................................ Cable routing for electrical PTMs This procedure describes how to route electrical PTMs comcode 109565549 cables in a Alcatel-Lucent 1850 TSS-60 shelf............................................Insert the PTM module in ports 1 through 4 of the LNW70 card............................................
Page 335: Electrical Ptm Routing
PTM installation Install pluggable modules .................................................... Figure C-5 Electrical PTM routing T E P S ..................................................................................C - 1 1 365-372-603R2.0 Issue 1 January 2009...
Page 336 PTM installation Install pluggable modules ......................................................................................................C - 1 2 365-372-603R2.0 Issue 1 January 2009...
Page 337: D Installing Fiber Connectors And Lbos
Overview Purpose This appendix provides procedures for installing and removing Line Build Out units (LBOs) and fiber connectors onto input and output ports found on the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) optical circuit packs. Contents This chapter provides information on the following topics:...
Page 338: Lbos
LBOs are fixed-value optical attenuators that mate into mounting blocks and provide a specific connector interface (LC, ST, FC or SC-type) for external fiber connections. The Alcatel-Lucent 1850 TSS-60 optical circuit packs are equipped with LC-type connector ports designed for use with LC-type LBOs and fiber connectors. Dust caps should be applied on all LBOs when not installed in connector ports.
Page 339: Lc-Type Lbo
Installing fiber connectors and LBOs LBOs .................................................... new LC™ optic attenuators are designed to provide flat spectral loss across the full spectrum, allowing the attenuators to be used in the 1300-nm, 1400-nm, and 1500-nm bands. Figure D-2 LC-type LBO SNAP-ACTION TAB ALIGNMENT KEY Assembly of LC-type LBO into LC block The LC-type LBOs are installed into the LC-type connector by aligning the alignment key...
Page 340: Removing Lc-Type Lbo From Lc-Type Connector Port
Installing fiber connectors and LBOs LBOs .................................................... Figure D-4 Removing LC-type LBO from LC-type connector port DEPRESS TAB TO RELEASE LBO Note: Recommend installing the required LBO in the Input (Rx) Port..................................................... D- 4 365-372-603R2.0 Issue 1 January 2009...
Page 341: Fiber Connections
.................................................... Fiber connections General Alcatel-Lucent 1850 TSS-60 uses AllWave ADVANTAGE™ Lightguide Jumpers, part of Alcatel-Lucent’s AllWave ADVANTAGE™ Optical Connectivity Solution (OCS). These jumpers contain a boot angled at 40 degrees, allowing the jumpers to dress appropriately into the fiber tray. The angled boot eliminates projection outside the front of the shelf assembly.
Page 342: Lc-Type Fiber Connection
Installing fiber connectors and LBOs Fiber connections .................................................... Figure D-6 LC-type fiber connection ALIGNMENT SLOT DEPRESS LEVER TO RELEASE THE SNAP-ACTION TAB Note: Recommend installing the required LBO in the Input (Rx) Port..................................................... D- 6 365-372-603R2.0 Issue 1 January 2009...
Page 343: E Backplane Pin Replacement
Overview Purpose This appendix provides information and the procedures used when a connector and/or pin on the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60) backplane has been bent or broken. Contents This appendix provides information on the following topics:...
Page 344: Pin And Connector Background
Pins are identified by a column and row position on the backplane. D-Subminiature connectors are identified by their designation and J-number. All the METRAL™ pins used on the Alcatel-Lucent 1850 TSS-60 shelves have the same tail length of 4.30 mm (0.169 in.).
Page 345: Backplane Locations Of Metral™ Pins
Backplane pin replacement Pin and connector background .................................................... Table E-1 show the location and type of METRAL™ pins on the Alcatel-Lucent 1850 TSS-60 backplane. Table E-1 Backplane locations of METRAL™ pins Mating length Tail length Column Type (mm) (mm) 001, 154, 156, 162 Signal Pin 5.75...
Page 346: Repair Kits And Tools
All the METRAL™ pins used on the Alcatel-Lucent 1850 TSS-60 shelves have the same tail length of 4.30 mm (0.169 in.). Additional replacement signal pins may be ordered in packages of 100 by the part number shown in Table E-2, “Metral™...
Page 347: Simple Repair Methods
Backplane pin replacement Simple repair methods .................................................... Simple repair methods Precautions CAUTION Equipment Damage/Personal Injury These procedures should be done with the shelf out of service and powered down to ensure no further damage to the equipment or to the person doing the repair.
Page 348 D-subminiature pins The D-Subminiature connectors on the Alcatel-Lucent 1850 TSS-60 backplane are all of the receptacle type. These connectors are designated as jacks and not as plugs. The individual connector terminals are protected somewhat by the molded plastic insert inside the connector shell.
Page 349: Replacement Methods
Note: Any press-fit connector pin may be removed and replaced one time in the Alcatel-Lucent 1850 TSS-60 backplane. A second removal and replacement in the same plated-through hole may not meet the long-term reliability objectives. If a replacement is needed for a previously replaced connector pin, contact your next level of support before proceeding.
Page 350 Backplane pin replacement Replacement methods ..............................................................................................Verify that the new pin is securely in the backplane............................................If the replacement is not successful, contact your next level of support. T E P S ................................ Guide and keying pin procedure If it becomes necessary to replace Guide or Keying Pins, contact your next level of support for tooling, replacement parts and detailed replacement procedures.
Page 351: F Fiber Labeling
Fiber labeling Overview Purpose This appendix describes the labeling of the fiber. Contents This chapter contains the following: Fiber description Fiber labels .................................................... F - 1 365-372-603R2.0 Issue 1 January 2009...
Page 352: Fiber Description
Fiber description Fibers There are three different types of single-mode fiber used with the Alcatel-Lucent 1850 Transport Service Switch 60 (TSS-60), simplex blue fiber, simplex yellow fiber, and the customer's fiber, and two types of multi-mode fiber used with the Alcatel-Lucent 1850 TSS-60, multi-mode simplex gray fiber and the customer's multi-mode fiber.
Page 353 Fiber labeling Fiber description .................................................... Precautions CAUTION Fiber Damage Fiber is constructed of glass and should be treated with care. It should not be pulled or stretched. This could cause damage to the fiber or the fiber connector. Fiber should not be bent in a radius of less than 1-1/2”. Single-mode fiber testing requirements All fibers shall be tested after they are installed as follows: All fibers shall be tested after installation, but prior to turn-up...
Page 354: Fiber Labels
Fiber labeling Fiber labels .................................................... Fiber labels Introduction If pre-printed labels are not available, use a label-maker to create labels for each end of each fiber. The label should include: Rack location • Circuit pack • Port • Direction (IN, OUT) •...
Page 355 Glossary .................................................... Abnormal (status condition) Alarm Cutoff ACO/SW Alarm Cutoff and Test Add/Drop Multiplexer AGNE Alarm Gateway Network Element Alarm Indication Signal Alternate Mark Inversion ANSI American National Standards Institute Automatic Protection Switch Access Resource Manager AS&C Alarm, Status, and Control ASCII American Standard Code for Information Interchange ASN.1...
Page 356 Glossary .................................................... Auto Automatic AUXCTL Auxiliary Control .................................................... B3ZS Bipolar 3-Zero Substitution B8ZS Bipolar 8-Zero Substitution BDFB Battery Distribution and Fuse Bay Bit Error Ratio Bit Interleaved Parity BITS Building Integrated Timing Supply Basic Rate Interface .................................................... Clear Channel CCITT International Telephone and Telegraph Consultative Committee Controlled Environment Vault CD-ROM...
Page 357 Glossary .................................................... Clock CMISE Common Management Information Service Element CMOS Complementary Metal Oxide Semiconductor CMTS Cable Modem Termination System Central Office Circuit Pack Customer Premises Equipment Critical (alarm status) Carrier Serving Area Channel Service Unit CS&O Customer Support and Operations Coding Violation CVFE Coding Violation Far End...
Page 358 Glossary .................................................... DPLL Digital Phase-Locked Loop Dual Ring Interworking Digital Signal Level 1 Digital Signal Level 3 DSLAM Digital Subscriber Line Access Multiplexer DSNE Directory Services Network Element Digital Cross-Connect Panel Distant Terminal Data Terminating Equipment .................................................... EC-1 Electrical Carrier Level 1 Equipment Catalog Item EEPROM Electrically-Erasable Programmable Read-Only Memory...
Page 359 Glossary .................................................... Equipped (memory administrative state) Errored Seconds Electrostatic Discharge Extended Super Frame Environmental Stress Testing .................................................... Federal Communications Commission FDDI Fiber Distribution Data Interface Far End FE ACTY Far End Activity FEBE Far End Block Error FE ID Far End Identification FEPROM Flash EPROM FERF...
Page 360 Glossary .................................................... Gateway Network Element Telcordia Technologies General Requirement General Telemetry Processor GTSIP Global Technical Support Information Platform Graphical User Interface .................................................... HECI Humans Equipment Catalog Item .................................................... Internal Clock Identifier International Electrotechnology Commission Infant Mortality Factor Incoming Status Input/Output Internet Protocol Intermediate Reach In Service...
Page 361 Glossary .................................................... Intershelf Interface ISDN Integrated Services Digital Network International Standards Organization Internet Service Provider IVHS Intelligent Vehicle Highway System .................................................... Local Area Network LAPD Link Access Procedure "D" Line Build Out Local Communications Network Local Exchange Carrier Light-Emitting Diode Loss of Frame Loss of Pointer Loss of Signal...
Page 362 Glossary ......................................................................................................Mediation Device Major Alarm Multimode huMan-Machine Language Minor Alarm MPEG Moving Picture Experts Group MSDT Multi-Services Distant Terminal MTBF Mean Time Between Failures MTBMA Mean Time Between Maintenance Activities Mult Multipling Multiplex MXBIU Multiplexer and Backplane Interface Unit ....................................................
Page 363 Glossary .................................................... Nanometer (10 meters) Network Monitoring and Analysis NMON Not Monitored (provisioning state) Nonreturn to Zero NARTAC Lucent North American Regional Technical Assistance Center call 1-866-LUCENT8 (866-582-3688): Prompt 1 Network-Network Interface Not Service Affecting NSAP Network Services Access Point No Trouble Found ....................................................
Page 364 Glossary .................................................... OPS/INE Operations System/Intelligent Network Element Operations System OSGNE Operations System Gateway Network Element Open Systems Interconnection OSMINE Operations Systems Modifications for the Integration of Network Elements Outside Plant .................................................... P-bit Performance Bit Personal Computer Power Conversion Unit Program Identification PINFET Positive Intrinsic Negative Field Effect Transistor Pointer Justification Count...
Page 365 Glossary .................................................... POTS Plain Old Telephone Service Performance Report Message PROTN Protection Primary Reference Source Power Supply Unit Pluggable Transmission Module Permanent Virtual Circuit Power .................................................... Random Access Memory Reliability Prediction Procedure (described in Telcordia Technologies TR-NWT-00032) Remote Terminal Return to Zero ....................................................
Page 366 Glossary .................................................... SEFS Severely Errored Frame Seconds Single-Ended Operations Severely Errored Seconds Super Frame (format for DS1 signal) Small Form Programable. System Identification Service Level Agreements SLIM Subscriber Loop Interface Module Single Mode SONET Synchronous Optical NETwork Synchronous Payload Envelope Sync Quality Unknown Software Release Description STS, STS-n...
Page 367 Glossary .................................................... SYSCTL System Controller (circuit pack) .................................................... T1X1 and T1M1 The ANSI committees responsible for telecommunications standards Telcordia Technologies Technical Advisory TABS Telemetry Asynchronous Byte Serial (Protocol) TARP Target ID Address Resolution Protocol Threshold-Crossing Alert TCP/IP Transmission Control Protocol/Internet Protocol TCVCXO Termperature-Compensated Voltage-Controlled Crystal Oscillator Time Division Multiplexing...
Page 368 Glossary ......................................................................................................Unavailable Seconds User Network Interface Universal Optical Connector UPD/INIT Update/Intialize UPSR Unidirectional Path Switched Rings .................................................... Voice Frequency VLAN Virtual Local Area Network VLSI Very Large Scale Integration Violation Monitor Violation Monitor and Removal VoIP Voice over Internet Protocol VONU Virtual Optical Network Unit Virtual Private Network...
Page 369 Glossary ......................................................................................................Wide Area Network .................................................... G L- 1 5 365-372-603R2.0 Issue 1 January 2009...
Page 370 1xN protection switching pertains to circuit pack protection that provides a redundant signal path through the Alcatel-Lucent 1850 TSS-60 (it does not cover protection switching of an optical facility; se "1+1"). In 1xN switching, a group of N service circuit packs share a single spare protection circuit pack.
Page 371 Terms and definitions .................................................... Automatic Protection Switch A feature that allows another synchronization source to be automatically selected and the synchronization source provisioning to be automatically reconfigured in the event of a synchronization source failure or network synchronization change, for example, a fiber cut. Available Time In performance monitoring, the 1-second intervals.
Page 372 Terms and definitions .................................................... Channel A logical signal within a port. For example, for an EC-1 port, there is one STS-1 channel and sometimes 28 VT1.5 channels. See Port. Channel State Provisioning A feature that allows a user to suppress reporting of alarms and events during provisioning by supporting multiple states (automatic, in-service and not monitored) for VT1.5 and STS-1 channels.
Page 373 (accepts transmitted data) or both. Dual Homing A network topology in which two Alcatel-Lucent 1850 TSS-60s serve as hosts supporting up to 8 OC-3 rings or 4 OC-12 rings. Each OC-3 and OC-12 ring is interconnected between the two separate hosts.
Page 374 Lucent’s SONET OC-48 Lightwave System. Function Unit Refers to any one of a number of different circuit packs that can reside in the A/B, D, or G function unit slots on the Alcatel-Lucent 1850 TSS-60..................................................... GNE - Gateway Network Element A network element that has an active X.25 link.
Page 375 .................................................... LBO - Line Build Out An equalizer network between the Alcatel-Lucent 1850 TSS-60 and the DSX panel. It guarantees the proper signal level and shape at the DSX panel. LED - Light Emitting Diode Used on a circuit pack faceplate to show failure (red) or service state.
Page 376 See Intermediate Reach..................................................... Main The two slots (M-1 and M-2) on the Alcatel-Lucent 1850 TSS-60 shelf in which the OC-3 or OC-12 main OLIU circuit packs are installed. Midspan Meet The capability to interface between two lightwave terminals of different vendors. This applies to high-speed optical interfaces.
Page 377 Terms and definitions ......................................................................................................NE - Near End The network element the user is at or working on. Also called local. NE - Network Element The basic building block of a telecommunications equipment within a telecommunication network that meets SONET standards. Typical internal attributes of a network element include: onr or more high- and low-speed transmission ports, built-in intelligence, synchronization and timing capability, and access interfaces for use by technicians and/or operation systems.
Page 378 Terms and definitions .................................................... OC-12 Optical Carrier Level 12 Signal (622 Mb/s). OC-12c (STS-12c) Optical Carrier Level 12 Concatenated Signal. High-speed broadband equivalent to twelve STS-1s linked together with a single path overhead. OC-48 Optical Carrier Level 48 Signal. Operations Interface Any interface that provides information on the system performance or control.
Page 379 SONET APS channel (K1 and K2 bytes in the SONET line overhead). On a Alcatel-Lucent 1850 TSS-60, a protection line is a pair of fibers that terminate an OLIU circuit pack in the Main-2, D-2, or G-2 slots. See Service Line.
Page 380 DCC. Service Line On a Alcatel-Lucent 1850 TSS-60 system, a service (or "working") line is a pair of fibers (one transmit and one receive) that terminate on an OLIU circuit pack in the Main-1, D-1, or G-1 slots.
Page 381 Terms and definitions .................................................... Subnetwork Group of SONET network elements that share a SONET data communications channel. Synchronization Messaging SONET synchronization messaging is used to communicate the quality of network timing, internal timing status, and timing states throughout a subnetwork. SYSCTL - System Controller The system controller circuit pack that provides overall administrative control of the terminal.
Page 382 Terms and definitions ......................................................................................................VM - Violation Monitor A mode of the DS3 circuit pack in which it will monitor but not remove P-bit parity violations on the DS3 signal from the received fiber. VMR - Violation Monitor and Removal A mode of the DS3 circuit pack in which it will monitor and remove P-bit parity violations on the DS3 signal received from the fiber.
Page 383 Index Automatic 7-13 OC-48 optical fiber 3-66 test equipment automatic protection switch 6-48 office alarm 3-57 3-58 3-59 ................................office alarm connections 3-60 10/100Base-T cables 3-42 battery distribution fuse board optical fiber 3-67 3-69 1000Base-T (BDFB) 2-17 2-18 3-70 3-71 optical fiber cables 3-71...
Page 384 DB-9 connector pinouts damage laser safety discrete 3-61 electronic components Laser 1-11 document jack laser conventions used Alcatel-Lucent 1850 TSS-60 how to use optical specifications 1-11 wrist strap intended audience 6-43 classes 1-11 Documentation 6-48 7-13 product classifications 1-10...
Page 385 Index ..................................................................optical fiber scope SYNC cable 3-53 cable(s) major alarm (MJ) 3-60 6-44 6-46 out-of-service mode SYNC 3-52 minor alarm (MN) 3-60 6-44 ................................6-46 6-50 6-51 Personal Computer (PC) telemetry 3-61 6-59 miscellaneous discrete 6-59 CIT requirements connections 6-61 6-60...
Page 386 Index ..................................................................video fiber scope VT1.5 cross-connects 6-10 ................W wire-wrap gun wrist strap 6-43 6-48 7-13 .................................................... I N - 4 365-372-603R2.0 Issue 1 January 2009...
