Page 1 Alcatel-Lucent 1850 Transport Service Switch (TSS-5) | Release 5.1 Installation and System Turn-Up Guide 365-372-403R5.1 CC109687848 ISSUE 1 NOVEMBER 2008...
Page 2 In such an event, applicable tariffs require that the customer pay all network charges for traffic. Alcatel-Lucent cannot be responsible for such charges and will not make any allowance or give any credit for charges that result from unauthorized access.
Page 3: Table Of Contents
Optical specifications ..........................1-10 Part I: Physical and power installation Physical installation Planning ..............................2-3 Inspection ..............................2-4 Alcatel-Lucent 1850 TSS-5 rack-mount shelf installation ................ 2-5 Description .............................. 2-12 Power cable installation ........................... 2-13 Powering ..............................2-16 .................................................... i i i 365-372-403R5.1...
Page 4 Contents .................................................... Cable and fiber installation DS1/E1 cable installation .......................... 3-3 DS3/E3 cable Installation ........................3-10 Ethernet cable installation ........................3-13 Office alarm cable installation ........................ 3-19 Miscellaneous (environmental) discrete telemetry cable installation ............. 3-22 Timing cable installation ......................... 3-25 OC-3/STM-1 and OC-12/STM-4 main optical fiber cable installation ..........
Page 5 OC-3/STM-1/OC-12/STM-4 optical transmission test ................7-7 Automatic protection switching test ......................7-8 Manual switching tests ..........................7-10 Final operations ............................7-12 Cover installation for Alcatel-Lucent 1850 TSS-5 .................. 7-14 Part IV: Miscellaneous detailed installation procedure and reference material Technical support Technical assistance ..........................
Page 6 Contents .................................................... Glossary Acronyms and Abbreviations ......................... GL-1 Terms and Definitions .......................... GL-15 Index .................................................... 365-372-403R5.1 Issue 1 November 2008...
Page 7 Mounting bracket position for 23-inch frame ................2-9 Mounting bracket position for ETSI frame ................2-10 Power terminal block ......................... 2-11 Power connections on rack-mount Alcatel-Lucent 1850 TSS-5 VLIU plug-in circuit pack ..2-16 Cable and fiber installation VLIU1 DS1/E1 access panel cable connectors ................3-7 RJ-45 pin out for VLIU2/VLIU10 dual cable harness ..............
Page 8 List of figures .................................................... Circuit pack installation Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view ............4-2 Stand-alone node set-up WaveStar® CIT banner ......................5-11 WaveStar® CIT login prompt ....................5-11 WaveStar® CIT legal notice ...................... 5-12 WaveStar® CIT network view ....................5-12 Shelf Login ..........................
Page 9 Power cable assembly ........................ 2-13 Power cable color coding for -48V connection ................2-14 Power cable color coding for +24V connection ................. 2-14 Alcatel-Lucent 1850 TSS-5 shelf power supply requirements ..........2-16 Cable and fiber installation Cable requirements and options ....................3-2 DS1/E1 cable assemblies ......................
Page 10 List of tables .................................................... 3-16 Standard CIT cable connection ....................3-32 3-17 RJ-45 to DB-9 connector connections ..................3-33 3-18 RS-232 default settings ......................3-34 3-19 Ethernet / LAN crossover cable ....................3-35 3-20 LAN cross-over cable connections .................... 3-35 3-21 LAN straight-through cable connections ...................
Page 11: About This Document
This installation manual provides information and procedures necessary to install, self- test, and turn up the Alcatel-Lucent 1850 TSS-5 system. This manual is not a service or operations manual. Refer to Alcatel-Lucent 1850 Transport Service Switch (TSS-5) User Provisioning Guide, 365-372-401R5.1 for any activities involving circuit turn-up or regular maintenance, and Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Maintenance and Trouble-Clearing Guide, 365-372-402R5.1 for...
Page 12: Conventions Used
PC response to a command. Courier For the remainder of this document, “Alcatel-Lucent 1850 TSS-5” is used in place of Alcatel-Lucent 1850 Transport Service Switch 5 in most cases. Related documentation The following documents provide additional information about the Alcatel-Lucent 1850...
Page 13: Training
Suitcasing of these courses is also available. Contact Alcatel-Lucent University at 1 (888) 582-3688 to enroll in training classes. To arrange suitcase sessions, call the Product Training Manager at 1 (800) 432-6317 (within USA) or +1 (614) 764-5542 (worldwide).
Page 14: Document Support
This is a non-technical number. The referral number is 1 (888) 727-3615 (continental United States) or +1 (630) 713-5000 (for all countries). Technical support For technical support, contact your local Alcatel-Lucent customer support team. See the Alcatel-Lucent Support web site (http://alcatel-lucent.com/support) for contact information.
Page 15 Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel- Lucent products at the end of their useful life or products displaced by Alcatel-Lucent equipment offers. For information regarding take-back of equipment by Alcatel-Lucent, or for more...
Page 16 About this document ......................................................................................................x v i 365-372-403R5.1 Issue 1 November 2008...
Page 17 Safety Overview Purpose This chapter provides important laser safety instructions and precautions for the Alcatel- Lucent 1850 Transport Service Switch 5 (Alcatel-Lucent 1850 TSS-5) high-capacity shelf. Contents This chapter provides information on the following topics: Laser safety Laser product classification...
Page 18: Safety
Laser safety System design The Alcatel-Lucent system complies with FDA/CDRH 21 CFR 1040.10 and 1040.11 as a Class I and with IEC 60825-1 as a Class 1 Optical Fiber Telecommunication laser product. The system has been designed to ensure that the operating personnel is not endangered by laser radiation during normal system operation.
Page 19: Safety
Safety Laser safety .................................................... This warning label is affixed to the inside of the subrack. Laser safety instructions Observe the following instructions to avoid exposing yourself and others to risk. Read the relevant descriptions in the manuals before taking equipment into operation •...
Page 20: Laser Product Classification
Safety Laser product classification .................................................... Laser product classification Standards compliance The product complies with both IEC standards and the Food and Drug Administration’s Center for Devices and Radiological Health (FDA/ CDRH) regulations. FDA/CDRH regulations Laser products are classified in accordance with the FDA/CDRH - 21 CFR 1010 and 1040. The classification scheme is based on the ability of the laser emission to cause injury to eye or skin during normal operating conditions.
Page 21: Laser Classes
Safety Laser product classification .................................................... Laser classes The maximum output power of laser radiation depends on the type of laser diode used. The international standards IEC-60825 or DIN/EN 60825 define the maximum output power of laser radiation for each laser class in accordance with the wavelength. Table 1-1 Laser classes Maximum Output Power of Laser class...
Page 22: Electrostatic Discharge Esd Considerations
Safety Electrostatic discharge ESD considerations .................................................... Electrostatic discharge ESD considerations ESD precautions CAUTION ESD hazard Industry experience has shown that all integrated circuit packs can be damaged by static electricity that builds up on work surfaces and personnel. The static charges are produced by various charging effects of movement and contact with other objects.
Page 23 Safety Electrostatic discharge ESD considerations .................................................... for connection of wrist straps are located at the lower right-hand corner of each assembly and are labeled. When grounding jacks are not provided, an alligator clip adapter enables connection to bay frame ground. Figure 1-1 Static control wrist strap GROUND CONNECTION...
Page 24 Safety Electrostatic discharge ESD considerations .................................................... IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL INSTRUCTIONS The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying this product. When installing, operating, or maintaining this equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:...
Page 25 Incorrect reassembly can cause electrical shock when the unit is subsequently used. 19. Some of the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) hardware modules contain FDA/CDRH Class I/IEC Class 1 single-mode laser products that are enclosed lightwave transmission systems.
Page 26: Optical Specifications
Safety Optical specifications .................................................... Optical specifications Overview Table 1-2 details the short, intermediate, and long reach SFPs that support the OC- 3/STM1 connections for the VLNC50, VLNC52, and VLNC64 circuit packs. Table 1-3 details the intermediate and long reach SFPs that support the OC-12/STM4 connections on the VLNC50 and VLNC52 only.
Page 27: Ethernet Ptm Specification
Safety Optical specifications .................................................... Table 1-4 Ethernet PTM specification Maximum Maximum Supported Output Input Circuit Wavelength Power Power Connector Target Plugin Type Pack(s) (nm) (dBm) (dBm) Type Distance 100BASE-LX VLNC35 1260 -1360 -8 to -15.0 -14 to -25.0 10 km VLNC40 VLNC42 VLNC60...
Page 28 Safety Optical specifications .................................................... Maximum Maximum Supported Output Input Circuit Wavelength Power Power Connector Target Plugin Type Pack(s) (nm) (dBm) (dBm) Type Distance SGEC47EL VLNC40 1471 -1 to +5.0 -9 to -29.0 96 km VLNC42 VLNC50 VLNC52 VLNC60 VLNC61 VLNC64 SGEC49EL VLNC40 1491...
Page 29 Safety Optical specifications .................................................... Maximum Maximum Supported Output Input Circuit Wavelength Power Power Connector Target Plugin Type Pack(s) (nm) (dBm) (dBm) Type Distance VLNC40 1551 -1 to +5.0 -9 to -29.0 96 km SGEC55EL VLNC42 VLNC50 VLNC52 VLNC60 VLNC61 VLNC64 VLNC40 1571 -1 to +5.0...
Page 30 Safety Optical specifications ......................................................................................................1 - 1 4 365-372-403R5.1 Issue 1 November 2008...
Page 31 Overview Purpose Part I of this document covers the physical installation of the Alcatel-Lucent 1850 Transport Service Switch 5 (Alcatel-Lucent 1850 TSS-5) rack mount shelf; the running and terminating of power cables, miscellaneous cables, and fibers. The installation and downloading of circuit packs.
Page 32: Part I: Physical And Power Installation
.................................................... Quantity Description Comments Heat Baffle The Alcatel-Lucent 1850 TSS-5 can be stacked on top (848862181) with 19” of each other without using a heat baffle due to its or 23” brackets integrated fan unit. Only use a heat baffle above or below the shelf if other equipment generates heat towards the Alcatel-Lucent 1850 TSS-5 shelf.
Page 33: Part I Installation Checklist
Table I-1 Part I installation checklist Completed Section and Chapter Procedure Required Chapter 2, “Physical “Inspection” (p. 2-4) installation” “Alcatel-Lucent 1850 TSS-5 rack- mount shelf installation” (p. 2-5) “Power cable installation” (p. 2-13) .................................................... I- 3 365-372-403R5.1 Issue 1 November 2008...
Page 34 Physical and power installation .................................................... Completed Section and Chapter Procedure Required “Powering” (p. 2-16) Chapter 3, “Cable and “DS1/E1 cable installation” (p. 3-3) Optional fiber installation” “DS3/E3 cable Installation” (p. 3-10) Optional “Ethernet cable installation” (p. 3-13) “Office alarm cable installation” (p.
Page 35 Physical and power installation .................................................... Completed Section and Chapter Procedure Required “199MN apparatus blank installation” (p. 4-10) “Install optical PTMs” (p. 4-11) “Install ethernet PTMs” (p. 4-12) .................................................... I- 5 365-372-403R5.1 Issue 1 November 2008...
Page 36 Physical and power installation ......................................................................................................I- 6 365-372-403R5.1 Issue 1 November 2008...
Page 37: Physical Installation
Purpose This section provides installation mounting and powering instructions for the Alcatel- Lucent 1850 Transport Service Switch 5 (1850 TSS-5) high-capacity shelf. Note that this document uses the term “shelf” as the combination of chassis, backplane and I/O plug-in circuit pack (VLIU1, VLIU2, or VLIU10).
Page 38: Physical Installation
Physical installation Overview .................................................... Power cable installation 2-13 Powering 2-16 .................................................... 2 - 2 365-372-403R5.1 Issue 1 November 2008...
Page 39: Physical Installation Planning
Equipment Framework Standard PBS-000-102PT. 23-inch wide EIA-Type bay frames. • Up to 15 Alcatel-Lucent 1850 TSS-5 network elements can be mounted into one 7 foot • frame with 2 inches remaining for a power distribution unit not specified. For mounting in ETSI type frames, there is a separate orderable bracket kit available.
Page 40: Inspection
If any backplane pins are damaged, refer to Appendix E, “Backplane pin replacement” instructions on repairing the damaged pin(s)............................................Each rack-mount Alcatel-Lucent 1850 TSS-5 shelf comes with a box containing the brackets and the following items Table 2-1 Shelf equipment packaging Quantity...
Page 41: Alcatel-Lucent 1850 Tss-5 Rack-Mount Shelf Installation
Alcatel-Lucent 1850 TSS-5 rack-mount shelf is dissipated by horizontal air flow provided by integrated fans within the shelf. 2. The Alcatel-Lucent 1850 TSS-5 rack-mount is 17.4" (441 mm) wide, 4.9" (125 mm) high, and 11.8" (300 mm) deep. 3. Alcatel-Lucent 1850 TSS-5 rack-mount has an integrated fan unit, and is stackable.
Page 42 Physical installation Alcatel-Lucent 1850 TSS-5 rack-mount shelf installation .................................................... Aparatus Circuit Pack Code Comcode Release Description Interface Unit VLIU2 109659136 R5.0 Required for the higher density VLNC52 and VLNC61 circuit packs when used in conjunction with the VLNC40. Interface Unit...
Page 43: Vliu Faceplate Latches
Physical installation Alcatel-Lucent 1850 TSS-5 rack-mount shelf installation .................................................... Figure 2-1 VLIU faceplate latches Figure 2-2 Fully seated VLIU interface panel ............................................Using a phillip head screwdriver, tighten the captive screws on the left and right sides of the VLIU interface panel. See Figure 2-3, “VLIU captive screws”...
Page 44: Vliu Captive Screws
Mounting position (front or rear) • Position in bay (bottom to top) • The Alcatel-Lucent 1850 TSS-5 shelf mounting brackets can be rotated to fit both the 19- inch and 23-inch bay frames. See Figure 2-5, “Mounting bracket position for 19-inch frame” (p. 2-9)
Page 45: Mounting Bracket Position For 23-Inch Frame
Physical installation Alcatel-Lucent 1850 TSS-5 rack-mount shelf installation .................................................... attaching the shelf to a 23-inch bay frame, and Figure 2-7, “Mounting bracket position for ETSI frame” (p. 2-10) if attaching to an ETSI bay frame. Figure 2-5 Mounting bracket position for 19-inch frame Figure 2-6 Mounting bracket position for 23-inch frame ....................................................
Page 46: Mounting Bracket Position For Etsi Frame
Only use heat baffles (848862181) above and below when stacking Alcatel-Lucent 1850 TSS-5 shelves with other vendors equipment in the same bay............................................Position the rack-mount Alcatel-Lucent 1850 TSS-5 shelf in the frame and secure the shelf to the frame using the thread-forming screws, included with the shelf............................................
Page 47: Power Terminal Block
.................................................... Figure 2-8 Power terminal block UL Safety Ground ............................................Verify with an ohmmeter that the Alcatel-Lucent 1850 TSS-5 shelf is grounded properly. Measure between the Alcatel-Lucent 1850 TSS-5 shelf safety ground screw and the appropriate frame ground. Requirement: The ohmmeter reads less than 1 ohm.
Page 48: Description
Physical installation Description .................................................... Description Overview This section should be performed on all shelf installations. Tools, test equipment and accessories Listed below are the tools, test equipment and accessories necessary to perform the procedures in this section. Quantity Required Description Comments Screwdriver(s) A screwdriver(s) with the appropriate...
Page 49: Power Cable Installation
(BDFB), or the battery distribution circuit breaker bay (BDCBB) to the Alcatel-Lucent 1850 TSS-5 shelf. If the Alcatel-Lucent 1850 TSS-5 is powered through only one power feed, the system will report a minor alarm. To suppress the alarm, use two jumpers, one jumper between the - VA and -VB and the second jumper between +VA and +VB.
Page 50: Power Cable Color Coding For -48V Connection
Route the power cables toward the power source (e.g., BDCBB, BDFB etc.) Note: The Alcatel-Lucent 1850 TSS-5 is powered by either +24V DC or -48 V DC. CAUTION If using BBCBB or BDFB, verify that the BDCBB breakers are off or that the BDFB fuses are not installed.
Page 51 Power cable installation ..............................................................................................Splice feeders from the BDCBB or BDFB to the Alcatel-Lucent 1850 TSS-5 power cables. Refer to Table 2-4, “Power cable color coding for -48V connection” (p. 2-14) Table 2-5, “Power cable color coding for +24V connection” (p.
Page 52: Powering
Procedure Proceed as follows: ............................................Verify that the Alcatel-Lucent 1850 TSS-5 shelf is properly grounded by measuring the resistance between the return signal on the power terminal block and frame ground............................................The resistance between frame ground and the return should be less than 1 ohm.
Page 53 The voltage MUST be between +20.0 and +28.0 VDC............................................Verify that the PWR-A and PWR-B LEDs are lighted............................................Inhibit the power flow to the “B” power feed of the Alcatel-Lucent 1850 TSS-5 shelf by either: Disconnecting the corresponding fuse at the BDFB •...
Page 54 Physical installation Powering ..............................................................................................Verify the PWR-B LED on the Alcatel-Lucent 1850 TSS-5 shelf is lit with only the “B” feed powered............................................Restart the power flow to the “A” power feed of the Alcatel-Lucent 1850 TSS-5 shelf by either: Connecting the corresponding fuse at the BDFB.
Page 55: Cable And Fiber Installation
Cable and fiber installation Overview Purpose This chapter provides installation and cabling instructions for the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) high-capacity shelf. Contents This chapter provides information on the following topics: DS1/E1 cable installation DS3/E3 cable Installation...
Page 56: Cable Requirements And Options
(1 receive and 1 transmit), as required for up to a total of 6 mini-BNC cables per Alcatel- Lucent 1850 TSS-5 shelf. Lengths from 25’ to 250’. 4. When cabling the Alcatel-Lucent 1850 TSS-5 for office alarm applications, one office alarm Alcatel-Lucent 1850 TSS-5 cable assembly is required for each shelf.
Page 57: Ds1/E1 Cable Installation
VLNC52 supports 28 DS1s and 21 E1s. The VLNC60 supports 8DS1/E1s and the VLNC61 supports 16DS1/E1s. The cables are connectorized (RJ-45 Type) at the Alcatel-Lucent 1850 TSS-5 end and may need to be wire-wrapped at the DSX end if equipped with a blunt connection end. If applicable, route the cables out of the bay and connect the cables to a DSX panel.
Page 58 Cable and fiber installation DS1/E1 cable installation .................................................... Cable Length Orderable Description (feet) Code Single DS1/E1 Cable, 26-gauge, RJ45 blunt-cut (un- 109468132 terminated) 109142323 109142331 109142349 109142356 109142364 109142372 109142380 DS1/E1 #1-16 cable harness, RJ45-RJ45 109147942 109147959 109147967 109147975 109147983 109147991 109148007 Bundle of 16 DS1/E1 cables, 26 gauge, RJ45 blunt-cut...
Page 59: Single Harness Ds1/E1 For Vliu1 Applications
Cable and fiber installation DS1/E1 cable installation .................................................... Cable Length Orderable Description (feet) Code Dual DS1 cable, halogen free, RJ45 to un-terminated 849090451 one shielded RJ45 plug, no boot 24GA solid shielded 849090469 halogen free cable other end, no connector 849090477 The new cable codes do not replace any of the existing 849090485...
Page 60: Dual Harness Ds1/E1 For Vliu2 And Vliu10 Applications
If a bundle of 16 DS1/E1 cable assemblies is ordered, use this harness for terminating two Alcatel-Lucent 1850 TSS-5 shelves. Important! The Alcatel-Lucent 1850 TSS-5 VLIU2 and VLIU10 terminate 28 DS1 or 21 E1 connections. Use the Dual harness cable assembly for terminating 28 DS1/E1 on the VLIU2 or VLIU10 paddle boards. Use Table 3-2, “RJ-45 pin out for...
Page 61: Vliu1 Ds1/E1 Access Panel Cable Connectors
(p. 3-8) ............................................If necessary attach a 3” tie bar to the front of the Alcatel-Lucent 1850 TSS-5 shelf above the circuit packs slots and just above the top of the VLIU. This will allow the front cover to close.
Page 62: Vliu2 Ds1 Rj-45 Port Assignments
Cable and fiber installation DS1/E1 cable installation .................................................... Figure 3-2 RJ-45 pin out for VLIU2/VLIU10 dual cable harness pin-8 (tip in) BR pin-7 (ring in) WH-BR DS1 (17-28) pin-6 (tip out) OR E1 (17 -21) pin-5 (tip in) WH-BL pin-4 (ring in) Blue pin-3 (ring out) WH-OR NOTE: TAB is not visible DS1 (1-16)
Page 63: Vliu10 Paddle Board
Cable and fiber installation DS1/E1 cable installation .................................................... Figure 3-5 VLIU10 paddle board Figure 3-6 DS1/E1 cable routing for VLIU Paddle boards ............................................Are you terminating the DS1/E1 cables on a DSX? IF... Then... Go on to Step 6 Skip to Step 9 ............................................
Page 64: Ds3/E3 Cable Installation
Cable and fiber installation DS3/E3 cable Installation .................................................... DS3/E3 cable Installation Description This section describes how to connect the DS3/E3 transmission cables to the B function group of the shelf. If applicable, route the cables out the bay and connect to the DSX panel.
Page 65: Ds3/E3 Access Panel Connectors
DS3/E3 1,2 or 3............................................If necessary attach a 3” tie bar to the front of the Alcatel-Lucent 1850 TSS-5 shelf above the circuit pack slots and just above the top of the VLIU in use. This will allow the front cover to close.
Page 66: Ds3/E3 Cable Routing
Cable and fiber installation DS3/E3 cable Installation ..............................................................................................Route the cables toward the left along the tie bar and into the bay cable rack. See Figure 3-8, “DS3/E3 cable routing” (p. 3-12). Figure 3-8 DS3/E3 cable routing ............................................Route the cables along the cable rack and into the terminating bay............................................
Page 67: Ethernet Cable Installation
Connect one end of the cable to the respective RJ-45 connector on the access panel on the front of the rack-mount Alcatel-Lucent 1850 TSS-5 shelf............................................Route the cabling along the rack-mount Alcatel-Lucent 1850 TSS-5 shelf and out to the 10/100BaseT terminating equipment. Refer to Figure 3-14, “Optical fiber routing”...
Page 68 Table 3-8, “Ethernet 10/100BaseT straight through cable” (p. 3-17)............................................Connect one end of the cable to the respective RJ-45 connector on the access panel on the front of the rack-mount Alcatel-Lucent 1850 TSS-5 shelf..................................................... 3 - 1 4 365-372-403R5.1...
Page 69: Vliu2 10/100 Baset Port Assignments
Ethernet cable installation .................................................... Figure 3-10 VLIU2 10/100 BaseT port assignments ............................................Route the cabling along the rack-mount Alcatel-Lucent 1850 TSS-5 shelf and out to the 10/100BaseT terminating equipment. Refer to Figure 3-15, “VLIU 10/100BaseT cable routing” (p. 3-30) ............................................
Page 70: Dual Harness 10/100 Pin Assignment For Vliu2 Applications
Cable and fiber installation Ethernet cable installation .................................................... Table 3-7 Dual harness 10/100 pin assignment for VLIU2 applications Wire Designation Direction Color TFEP* White-Green TFEN* Green RFEP* White-Orange RFEN* Blue TFEP** White-Blue TFEN** Orange RFEP** White-Brown RFEN** Brown Legend: * Indicates the primary pin pairing directions for ports 41 to 52. **Indicates the secondary pin pairing directions for ports 53 to 60.
Page 71: Ethernet 10/100Baset Straight Through Cable
Cable and fiber installation Ethernet cable installation .................................................... Table 3-8 Ethernet 10/100BaseT straight through cable Cable Length Alcatel-Lucent 1850 TSS-5 Description Comcode (feet) Connections 849010483 VLNC40/VLNC42 circuit pack Straight-through cable ports 9- 28 and VLIU2 ports 49 - 849010491 Shielded RJ45 — RJ45...
Page 72 Cable and fiber installation Ethernet cable installation .................................................... Cable Length Alcatel-Lucent 1850 TSS-5 Description Comcode (feet) Connections Gigabit Ethernet / LAN 849090527 VLNC40/VLNC42 circuit pack straight through cable ports 41- 60 849090535 one shielded RJ45 plug, 849090543 no boot 24GA solid...
Page 73: Office Alarm Cable Installation
In all cases, and as a matter of good practice, suppression devices such as diodes or contact protection networks must be provided across any external relay coil being driven by the Alcatel-Lucent 1850 TSS-5 to limit transient voltages and currents. Office alarm cable assemblies are listed in Table 3-9, “MDI/MDO/alarm cable...
Page 74: Vliu Mdi/Mdo/Alarm Terminal Block
Cable and fiber installation Office alarm cable installation .................................................... Pin# Color Name MN/ABN Visual + BR/W MN/ABN Visual - Note: The SYSCTL circuit pack reports office alarms. All are NO (normally open) contacts. When an alarm is enabled, they become closed. Procedure Proceed as follows: ............................................
Page 75 Cable and fiber installation Office alarm cable installation .................................................... Figure 3-13 VLIU MDI/MDO/alarm terminal block shelf view ............................................Route the office alarm cable to the right of the shelf up the bay troff to the office alarm panel. Secure to a tie bar for strain relief. Note: Miscellaneous discrete connections and alarm connections may be dressed together in a single bundle.
Page 76: Miscellaneous (Environmental) Discrete Telemetry Cable Installation
Description The miscellaneous (environmental) discrete telemetry access allows the maintenance center to control and monitor equipment collocated with the Alcatel-Lucent 1850 TSS-5. The environmental control feature enables the maintenance center to remotely initiate up to four contact closures at the remote terminal (RT) for equipment operation such as pumps, generators, etc.
Page 77: Miscellaneous (Environmental) Discrete (Mdi/Mdo) Connections
MDO PIN12 CABLE 2, O/W MDO #2 - Procedure This procedure is performed for Alcatel-Lucent 1850 TSS-5 shelves requiring miscellaneous (environmental) discrete telemetry............................................Connect the miscellaneous discrete telemetry cables to the MDI and MDO terminal blocks on VLIU of the Alcatel-Lucent 1850 TSS-5 shelf, refer to Figure 3-12, “VLIU...
Page 78 Cable and fiber installation Miscellaneous (environmental) discrete telemetry cable installation ..............................................................................................Wire-wrap the loose end of the miscellaneous (environmental) discrete telemetry cable to the wire-wrap terminal strip, making connections per Table 3-12, “Miscellaneous (environmental) discrete (MDI/MDO) connections” (p. 3-23)............................................
Page 79: Timing Cable Installation
849090600 849090618 849090626 Procedure This procedure is performed for Alcatel-Lucent 1850 TSS-5 shelves requiring either input timing or sync out. Refer to the following table for cable types Supported in Release 3.0 timing cable assemblies ............................................Connect the timing cable to the TMG 1 and TMG 2 if needed to the terminal block on VLIU of the Alcatel-Lucent 1850 TSS-5 shelf refer to “TMG cable assembly”...
Page 80 Cable and fiber installation Timing cable installation .................................................... TMG 1 Pin Designation Main 1 TMG 2 Pin Designation Main 2 GND - 15 GND- 16 ............................................Connect the other end of the timing cable to the appropriate office timing leads............................................
Page 81: Oc-3/Stm-1 And Oc-12/Stm-4 Main Optical Fiber Cable Installation
VLNC50 PTMs or VLNC52 PTMs located in either Main1 or Main2 or the VLNC64 located in either Main1 or Main2 of the rack-mount Alcatel-Lucent 1850 TSS-5. This procedure does not cover routing optical fiber cable between sites.
Page 82: Optical Fiber Routing
..............................................................................................TheAlcatel-Lucent 1850 TSS-5 requires 42 degree angled rotating boot LC fibers to allow the cover to close. Align the angled fiber to the left of the shelf guiding each fiber pair between main circuit pack slots. See Figure 3-14, “Optical fiber routing”...
Page 83: 10/100/1G Cable Installation
10/100/1G cable installation Description This section describes how to route both the optical fiber cables and the 10/100BaseT RJ- 45 cables from the Alcatel-Lucent 1850 TSS-5 shelf to the interconnecting equipment (for ® example, a LGX optical fiber distributing frame). Optical fibers to the 1 GbE PTM port...
Page 84: Vliu 10/100Baset Cable Routing
Cable and fiber installation 10/100/1G cable installation .................................................... Procedure Figure 3-15 VLIU 10/100BaseT cable routing ............................................Label the optical fiber cables, indicating bay, shelf, main circuit pack, and direction (IN or OUT)............................................Route optical fiber cables from the interconnecting equipment up to where the optical ports will be on the VLNC50/52 and VLNC64 circuit pack and the M2 VLNC40/42 circuit packs and VLNC35 if applicable.
Page 85 Cable and fiber installation 10/100/1G cable installation ..............................................................................................Route any gigabit Ethernet fibers in a protective tube or channel. T E P S ..................................................................................3 - 3 1 365-372-403R5.1 Issue 1 November 2008...
Page 86: Rs-232 Cable Assembly
3-32). CIT cable connections are listed in Table 3-16, “Standard CIT cable connection” (p. 3-32) Table 3-17, “RJ-45 to DB-9 connector connections” (p. 3-33). Table 3-15 Serial CIT cable assembly Cable Cable Alcatel-Lucent 1850 TSS-5 Description Assembly # Length Connections RS-232 CIT Cable 848748869 8 feet...
Page 87: Default Settings
Cable and fiber installation RS-232 cable assembly .................................................... Table 3-17 RJ-45 to DB-9 connector connections To DB-9 Pin D-Type From RJ-45 Connector Connector Pin# Color Pin# Blue Black Green Yellow Notes: 1. The connection and the colors shown above are for RJ-45 to DB-9 connector. 2.
Page 88 Cable and fiber installation RS-232 cable assembly .................................................... Table 3-18 RS-232 default settings Parameter Value Baud rate 9600 Data Bits Parity None Stop Bits Flow control Disabled Terminal VT 100 emulation T E P S ..................................................................................3 - 3 4 365-372-403R5.1 Issue 1 November 2008...
Page 89: Lan Cable Installation
LAN cable installation Description This section describes how to connect the LAN/TCP-IP cable to the Alcatel-Lucent 1850 TSS-5 shelf and to the VLNC40/VLNC42/VLNC60/VLNC61/VLNC64 circuit packs if installed. Perform this procedure if this cabling is required. Use this procedure to connect...
Page 90: Lan Cross-Over Cable Connections
Cable and fiber installation LAN cable installation .................................................... Table 3-21 LAN straight-through cable connections SYSCTL Alcatel-Lucent Connection 1850 TSS-5 Design Color to HUB Design BL - W W - BL RCV+ O - W RCV+ RCV- W - O RCV-...
Page 91: Final Operations
Cable and fiber installation Final operations .................................................... Final operations Description Final check on equipment and cable installation. Procedure Proceed as follows: ............................................Verify that all the cables are properly dressed/connected............................................Verify that all cables are properly labeled............................................Verify that designations where cables were wire-wrapped are properly labeled............................................
Page 92 Cable and fiber installation Final operations ......................................................................................................3 - 3 8 365-372-403R5.1 Issue 1 November 2008...
Page 93: Circuit Pack Installation
Circuit pack installation Overview Purpose This chapter provides the procedures for initial seating of circuit packs in the shelf. Contents This chapter provides information on the following topics: Initial circuit pack installation Install PTM (pluggable transmission modules) 4-11 Tools, test equipment and accessories Listed below are the required tools, test equipment and accessories.
Page 94: Circuit Pack Installation
Circuit pack installation Overview .................................................... Figure 4-1 Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view MAIN-1 MAIN-2 FN-C SYSCTL SYSCTL SYSCTL .................................................... 4 - 2 365-372-403R5.1 Issue 1 November 2008...
Page 95: Initial Circuit Pack Installation
Holding the SYSCTL upright in your hand, turn the circuit pack 90 degrees to the right and place the SYSCTL circuit pack into the lower right-hand slot on the Alcatel-Lucent 1850 TSS-5 shelf. Do NOT engage the circuit pack in the backplane connector.
Page 96 Alcatel-Lucent 1850 TSS-5 shelf............................................Remove the VLNC50 circuit pack from the packing material............................................Identify the large, lower left hand slot on the Alcatel-Lucent 1850 TSS-5 shelf. See Figure 4-1, “Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view” (p. 4-2)............................................
Page 97 Circuit pack installation Initial circuit pack installation ..............................................................................................Identify the large, lower left hand slot on the Alcatel-Lucent 1850 TSS-5 shelf. See Figure 4-1, “Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view” (p. 4-2)............................................Holding the VLNC52 circuit pack upright in your hand, turn the circuit pack 90 degrees to the right and place the Main OLIU circuit pack into the large, lower slot on the Rack- Mount Alcatel-Lucent 1850 TSS-5 shelf.
Page 98 The VLNC61 can occupy either Main1 or Main2 but not both slots at the same time............................................Remove the VLNC61 circuit pack from the packing material............................................Identify either Main 1 or Main 2 on the Alcatel-Lucent 1850 TSS-5 shelf. See Figure 4-1, “Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view” (p. 4-2)............................................
Page 99 Circuit pack installation Initial circuit pack installation ..............................................................................................Identify either main 1 or main 2 on the Alcatel-Lucent 1850 TSS-5 shelf. See Figure 4-1, “Rack-mount Alcatel-Lucent 1850 TSS-5 shelf front view” (p. 4-2)............................................Holding the VLNC64 circuit pack upright in your hand, turn the circuit pack 90 degrees to the right and place the main OLIU circuit pack into either main 1 or main 2 on the Rack- Mount Alcatel-Lucent 1850 TSS-5 shelf.
Page 100 Holding the VLNC40 circuit pack upright in your hand, turn the circuit pack 90 degrees to the right and place the circuit pack into the main 2 slot of the Rack-Mount Alcatel-Lucent 1850 TSS-5 shelf. Do NOT engage the circuit pack in the backplane connector.
Page 101 Holding the VLNC42 circuit pack upright in your hand, turn the circuit pack 90 degrees to the right and place the circuit pack into the main 2 slot of the Rack-Mount Alcatel-Lucent 1850 TSS-5 shelf. Do NOT engage the circuit pack in the backplane connector.
Page 102 If not installing a circuit pack in either main 1 or main 2, an 199MN apparatus blank is required............................................Identify the unequipped main slot on the left side of the Rack-Mount Alcatel-Lucent 1850 TSS-5 shelf............................................Remove the 199MN apparatus blank from the packing material.
Page 103: Install Ptm (Pluggable Transmission Modules)
Circuit pack installation Install PTM (pluggable transmission modules) .................................................... Install PTM (pluggable transmission modules) This section contains the instructions for the installation of the PTM modules. Install optical PTMs This section contains the instructions to install optical PTMs in the VLNC50. VLNC52 and VLNC64 circuit packs ............................................
Page 104 This section contains the instructions to install Ethernet PTMs in the VLNC50. VLNC52, VLNC60, VLNC61, VLNC64,VLNC40, VLNC42, and VLNC35 circuit packs. All of the circuit packs for the Alcatel-Lucent 1850 TSS-5 support one or more Ethernet PTMs. The VLNC40/VLNC42 can accept up to four PTMs supporting FE/GbE Ethernet connections, depending upon the PTM installed.
Page 105 Circuit pack installation Install PTM (pluggable transmission modules) ..............................................................................................Check off appropriate box in Table I-1, “Part I installation checklist” (p. I-3). T E P S ..................................................................................4 - 1 3 365-372-403R5.1 Issue 1 November 2008...
Page 106 Circuit pack installation Install PTM (pluggable transmission modules) ......................................................................................................4 - 1 4 365-372-403R5.1 Issue 1 November 2008...
Page 107 Overview Purpose Part II covers downloading software to the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) and then installation of circuit packs. This section also covers installation and operational tests. Contents This part of the document contains the following chapters:...
Page 108: Part Ii: Stand-Alone Installation Tests
Stand-alone installation tests .................................................... Completed Section and Chapter Procedure Required “Clearing alarms” (p. 6-8) “DS1 testing procedure” (p. 6-10) “E1 testing procedure” (p. 6-13) “DS3/E3 testing procedure” (p. 6-17) “VLNC35 standalone test” (p. 6-21) “VLNC40/VLNC42 standalone test” (p. 6-22) “VLNC60/61 standalone test” (p. 6-28) “VLNC64 standalone test”...
Page 109 VLIU panel. LC to LC Optical Fiber Optical fiber jumpers with LC-type Jumpers (108918269) connectors are required to optically loop Alcatel-Lucent 1850 TSS-5 shelf for test purposes. 2 fibers are needed for the main card. LC-Type LBOs Two of each type may be necessary to loop the VLNC50/VLNC64 optical port’s IN to...
Page 110 Stand-alone installation tests .................................................... ® PC and cable requirements for WaveStar ® This section lists the required and optional equipment needed to run the WaveStar software with the Alcatel-Lucent 1850 TSS-5. Quantity Required Description Comments Personal computer (PC) “PC minimum requirements for ®...
Page 111 Stand-alone installation tests .................................................... NE connections and multiple NE types, the processor type and speed as well as the memory size will all factor in to CIT performance..................................................... I I- 5 365-372-403R5.1 Issue 1 November 2008...
Page 112 Stand-alone installation tests ......................................................................................................II - 6 365-372-403R5.1 Issue 1 November 2008...
Page 113: Stand-Alone Node Set-Up
Stand-alone node set-up Overview Purpose This section provides instructions for installing circuit packs and downloading software. Contents This chapter provides information on the following topics Circuit pack compatibility Circuit pack installation Software installation ® Use of WaveStar CIT software 5-10 Safety instructions Note: All precautions should be observed when handling fiber.
Page 114: Stand-Alone Node Set-Up
Stand-alone node set-up Circuit pack compatibility .................................................... Circuit pack compatibility Overview “Main slot VLIU compatibility” (p. 5-2) lists all the circuit packs that are compatible with the installed VLIU and their respective shelf locations (slots). Table 5-1 Main slot VLIU compatibility Supported Circuit Packs Configurations Compatible VLIU Interface Units Main 1...
Page 115: Stand-Alone Node Set-Up
Stand-alone node set-up Circuit pack compatibility .................................................... Supported Circuit Packs Configurations Compatible VLIU Interface Units Any Main Pack VLNC64 VLNC64 VLNC64 Note: 1. The “X” implies that the supported circuit pack will work with that VLIU. 2. The VLNC35 is supported on all VLIU I/O paddle boards.....................................................
Page 116: Circuit Pack Installation
............................................Insert the VLNC2 circuit pack into the “SYCTL” slot of the shelf. If software has not been loaded, refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Software Release Description “New Installation chapter and load the VLNC2 card............................................
Page 117 Stand-alone node set-up Circuit pack installation ..............................................................................................If applicable, fully insert the VLNC52 circuit pack into main 1 or main 2. Note: The VLNC52 can occupy both main slots when equipped with a VLIU10 I/O board. Refer to Table 5-1, “Main slot VLIU compatibility” (p. 5-2) for appropriate slot configurations for the VLNC52.
Page 118: B Fiber Cleaning
Attenuate according to Table 5-2, “LBOs for OC-n/STM-n lines” (p. 5-8). Connect OUT to IN of the second PTM of the VLNC5052 in Main1 of the Alcatel-Lucent 1850 TSS-5 shelf using an optical fiber jumper cable. Attenuate according to Table 5-2, “LBOs for OC-n/STM-n lines”...
Page 119 ............................................If applicable, fully insert the VLNC35 circuit pack into function slot “C” only. Note: The VLNC35 must occupy function slot “C” of the Alcatel-Lucent 1850 TSS- 5 shelf. Note: Unlatch the circuit pack and using a gentle steady pressure on both ends of the circuit pack, slide the circuit pack into the slot until it is fully seated.
Page 120: Lbos For Oc-N/Stm-N Lines
............................................If FAULT LEDs remain lit on the VLNC50 or VLNC52 circuit pack log into shelf and retrieve alarms using the RTRV-ALM command and refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Maintenance and Trouble-Clearing Guide, 365-372- 402R5.1, for procedures to clear the alarm.
Page 121: Software Installation
Installation of the (Alcatel-Lucent 1850 TSS-5) software and WaveStar CIT Graphical User Interface (GUI) software is covered in detail in the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Software Release Description, which is provided with the software CD. On this CD, is software for the VLNC2, VLNC50, VLNC52, VLNC35, and the following CLI (Command Line Interface) packs VLNC40, VLNC42, VLNC60, VLNC61 and the VLNC64.
Page 122: Use Of Wavestar ® Cit Software
Description ® Complete the following steps to login to the Alcatel-Lucent 1850 TSS-5 via WaveStar CIT. It is assumed that the CIT software has been installed on the PC and the NE software has been downloaded to the Alcatel-Lucent 1850 TSS-5 shelf per the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Software Release Description.
Page 123 ® Stand-alone node set-up Use of WaveStar CIT software .................................................... The following windows appears: ® Figure 5-1 WaveStar CIT banner ® Figure 5-2 WaveStar CIT login prompt ............................................Enter the following in the Login window if CIT login was enabled during installation: User ID: LUC01 Password:...
Page 124 ® Stand-alone node set-up Use of WaveStar CIT software ..............................................................................................Click OK to connect. The following window will appear: ® Figure 5-3 WaveStar CIT legal notice ............................................After reading the Legal Notice, click OK............................................The following is displayed: ®...
Page 125: Shelf Login
............................................Enter valid User ID and Password. Enter ALU01 (case sensitive) for user ID and 1850TSS-5 (case sensitive) for the password............................................A graphical representation of the Alcatel-Lucent 1850 TSS-5 shelf will open..................................................... 5 - 1 3 365-372-403R5.1 Issue 1 November 2008...
Page 126 ® Stand-alone node set-up Use of WaveStar CIT software ..............................................................................................Check off the appropriate box in Table II-1, “Part II installation checklist” (p. II-1) T E P S ..................................................................................5 - 1 4 365-372-403R5.1 Issue 1 November 2008...
Page 127: Stand-Alone Installation Testing
10/100M ports by performing stand-alone verification tests. This applies to any equipped pack that the Alcatel-Lucent 1850 Transport Service Switch 5 (Alcatel-Lucent 1850 TSS-5) shelf supports in Release 5.1. For end-to-end turn-up and testing procedures, refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) User Provisioning Guide, 365-372-401R5.1. Contents...
Page 128: Lbo Software Settings
“Setting VLNC60/61 LBO settings (optional)” (p. 6-3)............................................Log into the Alcatel-Lucent 1850 TSS-5 shelf using the CIT software as described in Chapter 5, “Use of WaveStar® CIT software”............................................Refer to the following table of cable lengths and LBO values. Determine the LBO value corresponding to the DS1 cables installed.
Page 129 Stand-alone installation testing LBO software settings ..............................................................................................To provision LBO values, right-click on the graphical representation of the DS1 ports on the VLNC50/52 circuit pack. Notice that there are either eight or twenty-eight squares representing the DS1 ports for the VLNC50 and VLNC52 respectively. One group of four ports represent ports a-1-1 to a-1-4 on the far right.
Page 130: Vlnc60/61 Default Rs-232 Settings
Stand-alone installation testing LBO software settings .................................................... Note: The VLNC60 defaults the eight DS1/E1 ports to a 0 to110 ft. setting. The VLNC61 defaults the 16 DS1/E1 ports to a 0 to 110 ft. setting. If this value needs to be changed, this procedure will be necessary.
Page 131 Click OK. Result: A hyper terminal window will open............................................Enter a <CR> return. Result: A “User:” prompt will be echoed back............................................Login into the Alcatel-Lucent 1850 TSS-5 shelf using the following values; Prompt Value User: Admin Password: blank Result: The default system prompt (ALU 1850TSS-5) will be echoed back.
Page 132: Ds3/E3 Lbo Values
Setting DS3/E3 LBO values Follow this procedure to set the LBOs for DS3/E3 interfaces............................................Log into the Alcatel-Lucent 1850 TSS-5 shelf using the CIT software as described in Chapter 5, “Use of WaveStar® CIT software”............................................Refer to the following table for cable types and LBO values. Determine the LBO value corresponding to the DS3/E3 cables installed.
Page 133 Stand-alone installation testing LBO software settings ..............................................................................................Right-click on port b-1............................................Right-click and select Configure port............................................Select the appropriate value (IN/OUT) for the cable lengths ............................................At the bottom of the screen, choose all ports this pack............................................
Page 134: Clearing Alarms
If there are any FAULT LEDs on or flashing, press the UPD/INIT push-button on the SYSCTL circuit pack............................................If FAULT LEDs remain lit on any of the inserted circuit packs retrieve alarms using the RTRV-ALM command and refer to the Alcatel-Lucent 1850 Transport Service Switch .................................................... 6 - 8 365-372-403R5.1...
Page 135 Stand-alone installation testing Clearing alarms .................................................... (TSS-5) Alarm Messages and Trouble-Clearing Guide, 365-372-402R5.1 for procedures for addressing the problem............................................Leave the office alarm cable disconnected until all procedures and testing have been completed............................................Check off the appropriate box in Table II-1, “Part II installation checklist”...
Page 136: Local Equipment And Cross-Connect Tests
The tests in this section verify the proper operation of the circuit packs in the Alcatel- Lucent 1850 TSS-5 shelf. It verifies proper cabling from the Alcatel-Lucent 1850 TSS-5 to the access panel or connecting equipment. The shelf must successfully pass this test before testing any other feature of the Alcatel-Lucent 1850 TSS-5.
Page 137 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Set the DS1 test set to transmit and receive a Quasi-Random Sequence Signal (QRSS) with B8ZS line coding............................................Connect a cable from the DS1 test set to the associated DS1 port of the A Group on the access panel.
Page 138 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Highlight an available tributary on the right hand side (m-1-1-1-1) and click on Select............................................Click Next............................................Select the DS1 to drop to, (B). Choose an available trib from the “A” function group VT Group 1 (a-1-1-1), ............................................
Page 139 Stand-alone installation testing Local equipment and cross-connect tests .................................................... E1 testing procedure Perform the following steps to verify backplane cabling to A function slot of the VLIU access panel. This test case is only necessary if SDH mode testing is to be done. Cabling to E1 connectors located on the VLIU access panel are via backplane connections.
Page 140 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Select Create a new cross-connection, and enter Next at the bottom of the screen............................................Select Rate of the cross-connection (VC12); enter Next............................................Select UPSR Ring Add/Drop and select Next............................................
Page 141 Facility loopback testing allows the installer to verify the electrical cabling to the Alcatel- Lucent 1850 TSS-5 shelf. When the shelf is cabled to other DS1/E1 terminating equipment, it will be necessary to contact the Customer Network Control Center and have a signal established at the port under test, in order to complete the loopback testing.
Page 142 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Once the DS/E1 is selected, choose Facility and Operate from the loopback buttons and select Apply at the bottom of the screen. Verify the loopback under the Alarm List at the system level view.
Page 143 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Repeat entire procedure on each of the remaining DS1/E1 (VLNC50/52) tributaries of function group “A.” ............................................At the NE system level view, select Configuration -> Update system and choose update all.
Page 144 Stand-alone installation testing Local equipment and cross-connect tests .................................................... pack. If there is not an established cross-connection for the port under test, enter one with the following command............................................At the NE system view screen, under Configuration, select Cross-Connection. Result: The cross-connect wizard will open and guide you through setting up a cross- connect.
Page 145 Facility Loopback testing allows the installer to verify the electrical cabling to the Alcatel- Lucent 1850 TSS-5 shelf. When the shelf is cabled to other DS3/E3 terminating equipment, it will be necessary to contact the Customer Network Control Center and have a signal established at the port under test, in order to complete the loopback testing.
Page 146 Stand-alone installation testing Local equipment and cross-connect tests .................................................... If an error-free signal is not received: Check the LBO settings. • Verify that the pack is provisioned for the framing format being sent from the test set, • CBIT, or M13. Check the DS3/E3 cabling for proper connections.
Page 147 This procedure will verify the four electrical RJ-45 ports are working on the VLIU I/O panel when the Alcatel-Lucent 1850 TSS-5 shelf is equipped with a VLNC35 circuit pack. If the VLNC35 is equipped the optical PTMs these ports will be tested as well.
Page 148 VLNC42 circuit pack.This test case will use a PC set up temporarily with a specific static IP address to verify each 100-Mb port can ping the Alcatel-Lucent 1850 TSS-5 shelf’s switch IP address. This switch IP address will be removed upon completion of these tests.
Page 149: Vlnc40/42 Default Rs-232 Settings
Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Connect the other end of the RS-232 cable to the PC. see Chapter “RS-232 cable assembly” (p. 3-32)............................................Launch a Hyper Terminal session from the PC. Start -> Programs -> Accessories -> Communications ->...
Page 150 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Login into the Alcatel-Lucent 1850 TSS-5 shelf using the following values; Prompt Value User: Admin Password: blank Result: The default system prompt (ALU 1850TSS-5) > will be echoed back............................................
Page 151 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Configure a static IP address on the PC to match the subnet mask in Step 15 above............................................Click Start -> Settings -> Network and Dial-up Settings on the PC. Result: A Network and Dial-up Connections window will open.
Page 152 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................From the PC enter the following command. Start -> Run -> cmd. Result: A cmd.exe window will open............................................Enter ipconfig in this window. Result: The LAN card will display the IP address and subnet mask configured in Step Step ............................................
Page 153 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Login into the Alcatel-Lucent 1850 TSS-5 shelf using the RS-232 cable and the following values; Prompt Value User: Admin Password: blank Result: The default system prompt (ALU 1850TSS-5) > will be echoed back.
Page 154 This assumes the VLIU is installed and software has been successfully downloaded to the VLNC60/61 circuit pack as described in the “Install NE Software on a new Alcatel-Lucent 1850 TSS-5 network Element” chapter of the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Software Release Description.
Page 155: Vlnc60/61 Default Rs-232 Settings
Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Connect the other end of the RS-232 cable to the PC. see Chapter “RS-232 cable assembly” (p. 3-32)............................................Launch a Hyper Terminal session from the PC. Start -> Programs -> Accessories -> Communications ->...
Page 156 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Login into the Alcatel-Lucent 1850 TSS-5 shelf using the following values; Prompt Value User: Admin Password: blank Result: The default system prompt (ALU 1850TSS-5) > will be echoed back............................................
Page 157 This assumes the VLIU is installed and software has been successfully downloaded to the VLNC64 circuit pack as described in the “Install NE Software on a new Alcatel-Lucent 1850 TSS-5 network Element” chapter of the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Software Release Description.
Page 158: Vlnc64 Default Rs-232 Settings
Click OK. Result: A Hyper Terminal Window will open............................................Enter a <CR> return. Result: A “User:” prompt will be echoed back............................................Login into the Alcatel-Lucent 1850 TSS-5 shelf using the following values; Prompt Value User: Admin Password: blank Result: The default system prompt (ALU 1850TSS-5) >...
Page 159 Stand-alone installation testing Local equipment and cross-connect tests ..............................................................................................Enter user privilege mode by entering an “e” at the (ALU 1850TSS-5) prompt............................................Enter a <CR> at the password prompt. Result: The default system prompt (ALU 1850TSS-5)# will be echoed back............................................
Page 160: Led Test
LED test Description This test verifies proper operation of all LEDs on the VLNC2, VLNC35, VLNC50, and VLNC52 Alcatel-Lucent 1850 TSS-5 circuit packs. Operation of all the LEDs is necessary to assist in trouble isolation. Note: This test case requires the VLNC2 and either an VLNC50 or VLNC52 and VLNC35 be present.
Page 161: Office Alarm Test
“Office alarm connections” (p. II-35) lists the office alarms connections. It is a requirement that alarms on the Alcatel-Lucent 1850 TSS-5 do not affect and are • not affected by other equipment via office alarm connections. During this test, the alarm state of other equipment connected to the same office alarms as the Alcatel- Lucent 1850 TSS-5 should be examined after creating or clearing every alarm.
Page 162 Select all ports this pack from the bottom of the screen, and apply............................................Connect the office alarm cables to ALARM termination block on the VLIU access panel of the Alcatel-Lucent 1850 TSS-5 shelf............................................Introduce a valid DS1/E1 signal, then remove the signal.
Page 163 Stand-alone installation testing Office alarm test .................................................... Important! Select MJ instead of MN in Step ............................................Remove the valid DS1/E1 signal. Result: Activated office alarms: CR/MJ visual, CR/MJ audible............................................Press the ACO push-button on the SYSCTL. Result: Activated office alarm: CR/MJ visual. The CR/MJ audible alarm clears.
Page 164: Miscellaneous (Environmental) Discrete Telemetry Test
MDI test procedure Proceed as follows: ............................................Determine which environmental inputs to be monitored via the Alcatel-Lucent 1850 TSS- 5 shelf............................................Verify that the miscellaneous discrete cables are connected to the MDI connector block on the VLIU Access Panel.
Page 165 This procedure only tests MDOs 1-4 which are connected to the VLNC2. To verify MDO6 a service-affecting alarm must be created on the VLNC40 or VLNC42 circuit pack if equipped............................................Determine which environmental outputs are to be activated via the Alcatel-Lucent 1850 TSS-5 shelf..................................................... 6 - 3 9 365-372-403R5.1...
Page 166 Stand-alone installation testing Miscellaneous (environmental) discrete telemetry test ..............................................................................................Verify that the miscellaneous discrete cables are connected to the MDO connector block on the Access Panel. See Figure 3-12, “VLIU MDI/MDO/alarm terminal block” (p. 3-20) Figure 3-13, “VLIU MDI/MDO/alarm terminal block shelf view” (p. 3-21) Chapter 3, “Cable and fiber installation”.
Page 167: Final Operations
Note: Sending an upd-sys command will update the system database to reflect the current configuration and incoming signals. If any alarm is present, refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Maintenance and Trouble-Clearing Guide, 365-372-402R5.1 ............................................If desired, reconnect the office alarm cable at this time.
Page 168 Stand-alone installation testing Final operations ......................................................................................................6 - 4 2 365-372-403R5.1 Issue 1 November 2008...
Page 169: Part Iii: Network Turn-Up And Testing
Overview This section starts the process of integrating the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) into the customer’s network. The section provides the procedures to connect inter-office fibers and verify DCC communications and path switching. Contents This part of the document contains the following chapters:...
Page 170 Network turn-up and testing ......................................................................................................II I- 2 365-372-403R5.1 Issue 1 November 2008...
Page 171 This procedure is used to make fiber connections between nodes in a UPSR/SNCP ring. It is not intended to replace acceptance test procedures. If problems are encountered, refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Maintenance and Trouble-Clearing Guide, 365-372-402R5.1, for detailed troubleshooting procedures.
Page 172 Alcatel-Lucent 1850 TSS-5 shelf is disconnected............................................At each Alcatel-Lucent 1850 TSS-5 shelf, enter the shelf TID per the customer order or use LT-DMXPLORE-1 and LT-DMXPLORE-2 as defaults. This can be done at the NE system level view by entering Administration -> Set TID and entering the TID.
Page 173: Connecting Adjacent Network Elements Fiber Installation
LC connectors. Note: The Alcatel-Lucent 1850 TSS-5 VLNC50/52 require single-mode lightguide cable. Single-mode optical fibers connecting this shelf with the far-end shelf should not be connected to the VLNC50/52 until at least 45 seconds after an optical loopback is removed.
Page 174 Select the appropriate LBO value required based on the received optical power measurement. Attenuate to the middle of the allowable optical receive power range. Refer to the following tables for the Alcatel-Lucent 1850 TSS-5 main circuit pack receive levels. Wave...
Page 175 Reconnect the fiber and repeat the process for the other direction of transmission............................................In order to enable communications with the adjacent Alcatel-Lucent 1850 TSS-5 nodes, right click on the ports of the VLNC50/52 pack and enable DCC. Select the following options for Main 1-1 based on work instructions: dcc-m1-1, COM=ENABLED, SIDE=US ....................................................
Page 176 Verify proper shelf timing at each node using View -> Timing Sync. To change timing modes use the Configuration -> Timing/Sync command............................................In order to verify proper communications with the adjacent Alcatel-Lucent 1850 TSS-5 nodes, execute the following command: Administration -> OSI Neighbor Map...
Page 177: Oc-3/Stm-1/Oc-12/Stm-4 Optical Transmission Test
OC-3/STM-1/OC-12/STM-4 optical transmission test .................................................... OC-3/STM-1/OC-12/STM-4 optical transmission test Procedure This procedure should be conducted when the Alcatel-Lucent 1850 TSS-5 shelf is set to UPSR/SNCP or any other application and connected end to end and not looped back on itself............................................
Page 178: Automatic Protection Switching Test
Connecting adjacent network elements Automatic protection switching test .................................................... Automatic protection switching test Description This section provides the procedures for verifying the Alcatel-Lucent 1850 TSS-5 shelf automatic and manual protection switching. Note the following: These tests do NOT simulate circuit pack failures. •...
Page 179 Connecting adjacent network elements Automatic protection switching test .................................................... Result: The ring that was active in the previous step is now in signal failure and the other ring is now in the active state............................................Reconnect the optical fiber to the port of the VLNC50 or VLNC52. After a short time, the MN/ABN alarm LED on the SYSCTL and the FAULT Result: LED on the OLIU will extinguish.
Page 180: Manual Switching Tests
Connecting adjacent network elements Manual switching tests .................................................... Manual switching tests Description This test will initiate switching commands from the CIT and verify proper switching and LED indications for a UPSR/SNCP ring. This test may be performed on the VLNC50 optical ports.
Page 181 Connecting adjacent network elements Manual switching tests ..............................................................................................At the NE system level view, establish a protection switch with Fault -> Protection, click the + sign to open up to the path level switch type = manual then choose the Apply button at the bottom of the screen.
Page 182: Final Operations
Final operations .................................................... Final operations Description The following procedure ensures that all test signals and cross-connects have been removed and the Alcatel-Lucent 1850 TSS-5 shelf is alarm free and ready for network connection procedures. Procedure Proceed as follows: ............................................Update the system by entering Configuration -> Update System -> Update All.
Page 183 Connecting adjacent network elements Final operations ..............................................................................................Check off the appropriate box in Table III-1, “Part III installation checklist” (p. III-1). T E P S ..................................................................................7 - 1 3 365-372-403R5.1 Issue 1 November 2008...
Page 184: Cover Installation For Alcatel-Lucent 1850 Tss-5
Description Proceed as follows: ............................................For the rack-mount Alcatel-Lucent 1850 TSS-5 shelf, align the slots of the front cover with the slots located on the bottom corners of the shelf............................................Rotate the cover up and align the screws on the top corners with the screw holes.
Page 185: Part Iv: Miscellaneous Detailed Installation Procedure And Reference Material
Overview This section provides supplementary information that is useful when installing the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) system and using this Installation and System Turn-up Services Guide. Contents This part of the document contains the following:...
Page 186 Miscellaneous detailed installation procedure and Overview reference material ......................................................................................................IV- 2 365-372-403R5.1 Issue 1 November 2008...
Page 187 Technical support Overview Purpose This chapter provides important technical assistance information for the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5). Contents This appendix contains the following sections Technical assistance Accessing and navigating the On-Line Customer Support (OLCS) web site...
Page 188: Technical Support
Repair and Replacement (R&R) - technical support services for device repair/return or • parts replacement. Alcatel-Lucent On-Line Customer Support (OLCS) - online access to information and • services that can help resolve technical support requests. Note: Technical Support Services are available 24 hours a day, 7 days a week.
Page 189 Alcatel-Lucent product technical issue. When additional assistance is required, the Alcatel-Lucent Welcome Center is the first point of contact. An Alcatel-Lucent Welcome Center operator can direct the request to engineers that are highly trained and skilled in resolving issues, involving Alcatel-Lucent products.
Page 190 OLCS web site and view ARs 24 hours a day, 7 days a week. Data Drop Box The data drop box feature allows Alcatel-Lucent support technicians to provide customers with a quick method to share files. The Data Drop Box allows a technician to provide or receive a file from a customer quickly.
Page 191 Technical support Technical assistance .................................................... – Modification Implementation Procedure (MIP) – User Guide – Alarm Messaging and Trouble-Clearing Guide (AMTCG) – Framework User Guide – Graphical User Interface (GUI) Guide – Maintenance Guide, Provisioning Guide – User Operations Guide (UOG) Technical Notes •...
Page 192 Note: This may not apply to all products. The RMA area provides a list of contact information on all Alcatel-Lucent products. There is a “request an RMA number” on-line for most Alcatel-Lucent products. An RMA number is required for all returned parts and this feature provides you with an easy method to obtain the RMA number.
Page 193: Accessing And Navigating The On-Line Customer Support (Olcs) Web Site
(if necessary), and navigate to each feature listed in this document. Accessing the OLCS web site To access the Alcatel-Lucent OLCS web site, enter: www.alcatel-lucent.com/support. Once you are at this web page, select Lucent Global Support. This will bring you to the web site where you can log in to gain access to the entitled products.
Page 194 Technical support Accessing and navigating the On-Line Customer Support (OLCS) web site .................................................... Need Help while registering? From the U.S. 1 (866) 582 3688, prompt 7 From outside the U.S. +1 (630) 218 7688 In Asia/Pacific Please contact the in-country technical support hotline.
Page 195 “My Bookmarks” section (if Data Drop Box has been added there). Click the “Upload a file” button in the Data Drop Box window to send a file to the Alcatel-Lucent support technician. An email address can also be entered so that the ....................................................
Page 196 Alcatel-Lucent technician will be notified when the file has been sent. Click the “Download a file” button from the Data Drop Box if the Alcatel-Lucent technician has sent a file to be downloaded. These files will remain on the site for 7 days.
Page 197 “My Bookmarks” section (if Alcatel-Lucent alerts is added there). Once you are on the Alcatel-Lucent alerts web page, a list of products are displayed. Click on a product to see a list of Alerts for that product. Alternatively, use the “Enter the number of the Alert”...
Page 198: Other Technical Support Services
Generally, customers should have a basic understanding of digital fundamentals and lightwave transmission systems. In addition, customers should have taken a previous Alcatel-Lucent Operating & Maintenance course or have equivalent experience with operations and maintenance issues related to the product...
Page 199 Technical support Other technical support services .................................................... Workshop Location: This workshop will be delivered in the Customer Advocate System Test Labs in Westford, MA. The format is 75% hands-on lab exercises, reinforced with 25% classroom instruction. How to sign up: To enroll in the training course: Within the United States, •...
Page 200 Technical support Other technical support services ......................................................................................................A- 1 4 365-372-403R5.1 Issue 1 November 2008...
Page 201: B Fiber Cleaning
Overview Purpose This appendix describes the Alcatel-Lucent recommended method for the cleaning and inspection of optical connectors using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. It is critical that connector faces are clean and free from particular contamination to assure proper performance and reliability of lightwave systems.
Page 202: Equipment Requirements And Recommendations
Fiber cleaning Equipment requirements and recommendations .................................................... Equipment requirements and recommendations Description For proper cleaning, the following equipment and materials are recommended: Table B-1 Required and recommended equipment and materials Installation Product Model/Description Comcode ITE # Order # Optical Fiber Scope Noyes OFS 300-200X 408197028 ITE-7129...
Page 203: Safety Instructions
Fiber cleaning Safety instructions .................................................... Safety instructions Safety instructions WARNING Laser hazard Never view an energized optical cable with the naked eye or with an optical magnifying instrument. Disconnected or separated optical connectors may emit invisible laser radiation and direct exposure can severely injure the eye. If inspecting the endface of a connector with a fiberscope, be absolutely certain that the system is deactivated.
Page 204: Cleaning/Inspecting Optical Connectors
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Cleaning/inspecting optical connectors Introduction The procedure that follows utilizes the “Wet/Dry” method for connector cleaning. This method first applies a “wet” solvent such as high purity alcohol to the connector endface to dissolve/remove any organic particulate or oily films, followed by a “dry” double clean wipe using the CLETOP cleaning cassette.
Page 205: Cleaning The Ferrule Endface
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Figure B-1 Cleaning the ferrule endface ............................................If a CLETOP cassette cleaner is not available, proceed with Step 7. Otherwise, hold the CLETOP cassette cleaner in the palm of your hand with the cassette shutter door facing Figure B-2, “CLETOP cleaner”...
Page 206: Cletop Cleaner
Fiber cleaning Cleaning/inspecting optical connectors .................................................... Figure B-2 CLETOP cleaner ............................................Insert and press the connector ferrule endface perpendicular against the cleaning cloth in the first of two slots of the cleaner. Figure B-3, “Acceptability criteria for fiber cleaning” (p. B-8).
Page 207 Fiber cleaning Cleaning/inspecting optical connectors .................................................... Follow this by folding an unused portion of the cloth over the end of the ferrule endface and then with light pressure from the thumb, slightly drag the cloth from the center of the ferrule to the edge while rotating the connector 360 degrees.
Page 208: Acceptability Criteria For Fiber Cleaning
Fiber cleaning Cleaning/inspecting optical connectors .................................................... No chips, cracks or scratches are allowed near the core of the glass Requirement: fiber endface. Requirement: No large floating (loose) contaminates are allowed on the glass fiber and ceramic ferrule endface. Figure B-3 Acceptability criteria for fiber cleaning ............................................
Page 209 Fiber cleaning Cleaning/inspecting optical connectors .................................................... Fiber adapters or circuit pack connectors During testing and/or trouble shooting activities it may be necessary to clean the optical buildout adapter or the circuit pack connector. The following procedure is recommended. CAUTION Do not attempt to clean ports equipped with yellow Light guide BuildOut (LBO) attenuators.
Page 210 Fiber cleaning Cleaning/inspecting optical connectors ......................................................................................................B- 1 0 365-372-403R5.1 Issue 1 November 2008...
Page 211: Cptm Installation
PTM installation Overview Purpose This chapter describes how to insert a small form pluggable (SFP) optics module into a Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) circuit pack. Contents This chapter contains the following. PTM modules Install pluggable optics ....................................................
Page 212: Ptm Installation
PTM installation PTM modules .................................................... PTM modules Alcatel-Lucent approved Class 1 SFP transceivers The following table lists all the current approved SFP modules to be used with Alcatel- Lucent 1850 TSS-5 approved SFPs Name Optical Module Code/Comcode Description VLNC40 PTMs...
Page 213 PTM installation PTM modules .................................................... Name Optical Module Code/Comcode Description OC-3/STM- Ch47 1471 nm OCN CWDM Optics 1/OC12/STM- Ch49 1491 nm OCN CWDM Optics 4/OTU-1 CWDM Types: Ch51 1511 nm OCN CWDM Optics Ch53 1531 nm OCN CWDM Optics Ch55 1551 nm OCN CWDM Optics Ch57 1571 nm OCN CWDM Optics...
Page 214 PTM installation PTM modules .................................................... Name Optical Module Code/Comcode Description VLNC 64 CWDM Ch 47 1471nm 109669622 Optics Ch49 1491nm 109669630 Ch51 1511nm 109669648 Ch53 1531nm 109669655 Ch55 1551nm 109669663 Ch57 1571nm 109669671 Ch59 1591nm 109669689 Ch61 1611nm 109669697 .................................................... C - 4 365-372-403R5.1 Issue 1 November 2008...
Page 215: Install Pluggable Optics
PTM installation Install pluggable optics .................................................... Install pluggable optics Task Complete the following steps to install pluggable optical modules in a circuit pack that has already been installed in a shelf............................................Determine the circuit pack and socket being equipped with the pluggable optical module............................................
Page 216: Module Types
PTM installation Install pluggable optics .................................................... Figure C-2 Module types ............................................Important! Pluggable optical modules are shipped with a dust plug installed into the optical ports to maintain cleanliness during storage and/or transportation. It is recommended that the dust plug be kept in place to maintain cleanliness until the optical fiber is connected.
Page 217: Latch Type 3 (Opened And Closed
PTM installation Install pluggable optics .................................................... Figure C-3 Latch type 3 (opened and closed) ............................................Proceed to Step ............................................Before inserting the module, the latch must be in the closed position. With the dust plug in place, the latch is in the closed position. Figure C-4 Latch type 4 (opened and closed) ............................................
Page 218: Insert Optical Module Into Socket
PTM installation Install pluggable optics ..............................................................................................Insert the pluggable optical module in the required socket of the circuit pack faceplate. Confirm that the optical module is locked in the socket. Verify that all unused sockets on the circuit pack are equipped with dust covers. Figure C-5 Insert optical module into socket ®...
Page 219 PTM installation Install pluggable optics .................................................... the duplicated information will be declared failed. Refer to the Alcatel-Lucent 1850 Transport Service Switch (TSS-5) Alarm Messages and Trouble Clearing Guide, 365- 372-302............................................Push on the dust plug to insert the module. The latch automatically catches when the module is inserted.
Page 220 PTM installation Install pluggable optics ......................................................................................................C - 1 0 365-372-403R5.1 Issue 1 November 2008...
Page 221: D Installing Fiber Connectors And Lbos
Overview Purpose This appendix provides procedures for installing and removing Line Build Out (LBOs) units and fiber connectors onto input and output ports found on the Alcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) optical circuit packs. Contents This chapter provides information on the following topics:...
Page 222: Installing Fiber Connectors And Lbos
LBOs are fixed-value optical attenuators that mate into mounting blocks and provide a specific connector interface (LC, ST, FC or SC-type) for external fiber connections. The Alcatel-Lucent 1850 TSS-5 optical circuit packs are equipped with LC-type connector ports designed for use with LC-type LBOs and fiber connectors. Dust caps should be applied on all LBOs when not installed in connector ports.
Page 223: Lc-Type Lbo
Installing fiber connectors and LBOs LBOs .................................................... new LC™ optic attenuators are designed to provide flat spectral loss across the full spectrum, allowing the attenuators to be used in the 1300-nm, 1400-nm, and 1500-nm bands. Figure D-2 LC-type LBO SNAP-ACTION TAB ALIGNMENT KEY Assembly of LC-type LBO into LC block The LC-type LBOs are installed into the LC-type connector by aligning the alignment key...
Page 224: Removing Lc-Type Lbo From Lc-Type Connector Port
Installing fiber connectors and LBOs LBOs .................................................... Figure D-4 Removing LC-type LBO from LC-type connector port DEPRESS TAB TO RELEASE LBO .................................................... D- 4 365-372-403R5.1 Issue 1 November 2008...
Page 225: Fiber Connections
.................................................... Fiber connections General Alcatel-Lucent 1850 TSS-5 uses AllWave ADVANTAGE™ Lightguide Jumpers, part of Alcatel-Lucent’s AllWave ADVANTAGE™ Optical Connectivity Solution (OCS). These jumpers contain a boot angled at 40 degrees, allowing the jumpers to dress appropriately into the fiber tray. The angled boot eliminates projection outside the front of the shelf assembly.
Page 226: Lc-Type Fiber Connection
Installing fiber connectors and LBOs Fiber connections .................................................... Figure D-6 LC-Type fiber connection ALIGNMENT SLOT DEPRESS LEVER TO RELEASE THE SNAP-ACTION TAB .................................................... D- 6 365-372-403R5.1 Issue 1 November 2008...
Page 227: Backplane Pin Replacement
Overview Purpose This appendix provides information and the procedures used when a connector and/or pin on the Alcatel-Lucent 1850 Transport Service Switch 5 (Alcatel-Lucent 1850 TSS-5) backplane has been bent or broken. Contents This appendix provides information on the following topics:...
Page 228: Pin And Connector Background
Pins are identified by a column and row position on the backplane. D-Subminiature connectors are identified by their designation and J-number. All the METRAL™ pins used on the Alcatel-Lucent 1850 TSS-5 shelves have the same tail length of 4.30mm (0.169 in.).
Page 229: Backplane Locations Of Metral™ Pins
Backplane pin replacement Pin and connector background .................................................... Table E-1 Backplane locations of METRAL™ pins Mating Length Tail Length Slot Column Type (mm) (mm) MAIN 001, 103 to 108 a,b,c,d,e Signal Pin 8.00 4.30 SYSCTL 001, 037 to 042 a,b,c,d,e Signal Pin 8.00 4.30...
Page 230: Repair Kits And Tools
All the METRAL™ pins used on the Alcatel- Lucent 1850 TSS-5 shelves have the same tail length of 4.30 mm (0.169 in.). Additional replacement signal pins may be ordered in packages of 100 by the part number shown in Table E-2, “Metral™...
Page 231: Simple Repair Methods
Backplane pin replacement Simple repair methods .................................................... Simple repair methods Precautions CAUTION Service disruption hazard These procedures should be done with the shelf out of service and powered down to insure no further damage to the equipment or to the person doing the repair. If service cannot be removed or rerouted, contact your next level of support before proceeding.
Page 232 D-subminiature pins The D-Subminiature connectors on the Alcatel-Lucent 1850 TSS-5 backplane are all of the receptacle type. These connectors are designated as jacks and not as plugs. The individual connector terminals are protected somewhat by the molded plastic insert inside the connector shell.
Page 233: Replacement Methods
Important! Any press-fit connector pin may be removed and replaced one time in the Alcatel-Lucent 1850 TSS-5 backplane. A second removal and replacement in the same plated-through hole may not meet the long-term reliability objectives. If a replacement is needed for a previously replaced connector pin, contact your next level of support before proceeding.
Page 234 Backplane pin replacement Replacement methods ..............................................................................................Verify that the new pin is securely in the backplane............................................If the replacement is not successful, contact your next level of support. T E P S ................................ Guide and keying pin procedure If it becomes necessary to replace guide or keying pins, contact your next level of support for tooling, replacement parts and detailed replacement procedures.
Page 235: F Fiber Labeling
Fiber labeling Overview Purpose This chapter describes the labeling of the fiber. Contents This appendix provides information on the following topics: Fiber description Fiber labels .................................................... F - 1 365-372-403R5.1 Issue 1 November 2008...
Page 236: Fiber Description
Fiber description Fibers There are three different types of single-mode fiber used with theAlcatel-Lucent 1850 Transport Service Switch 5 (1850 TSS-5) system, simplex blue fiber, simplex yellow fiber, and the customer's fiber Blue fiber Blue fiber is made up of a single blue colored fiber equipped with LC connectors at both ends.
Page 237 Fiber labeling Fiber description .................................................... A 1310nm or 1550-nm test source and an ITE# 7116 (or equivalent) optical power • meter shall be used to perform all tests. The light source shall first be measured for a reference point/baseline. • No fiber jumper may have a measured loss of more than 2 dB.
Page 238: Fiber Labels
Fiber labeling Fiber labels .................................................... Fiber labels Introduction If pre-printed labels are not available, use a label-maker to create labels for each end of each fiber. The label should include: Rack location • Circuit pack • Port • Direction (IN, OUT) •...
Page 239 Glossary Acronyms and Abbreviations ....................................................................................Abnormal (status condition) Alarm Cutoff ACO/SW Alarm Cutoff and Test Add/Drop Multiplexer AGNE Alarm Gateway Network Element Alarm Indication Signal Alternate Mark Inversion ANSI American National Standards Institute Automatic Protection Switch Access Resource Manager AS&C Alarm, Status, and Control ASCII...
Page 240 Glossary Acronyms and Abbreviations .................................................... ASNE Alarm Server Network Element Asynchronous Transfer Mode Auto Automatic AUXCTL Auxiliary Control .................................................... B3ZS Bipolar 3-Zero Substitution B8ZS Bipolar 8-Zero Substitution BDFB Battery Distribution and Fuse Bay Bit Error Ratio Bit Interleaved Parity BITS Building Integrated Timing Supply Basic Rate Interface ....................................................
Page 241 Glossary Acronyms and Abbreviations .................................................... Craft Interface Terminal Carrier Line Failure Status Clock CMISE Common Management Information Service Element CMOS Complementary Metal Oxide Semiconductor CMTS Cable Modem Termination System Central Office Circuit Pack Customer Premises Equipment Critical (alarm status) Carrier Serving Area Channel Service Unit CS&O Customer Support and Operations...
Page 242 Glossary Acronyms and Abbreviations .................................................... DEMUX Demultiplexer Digital Loop Carrier DPLL Digital Phase-Locked Loop Dual Ring Interworking Digital Signal Level 1 DS3/E3 Digital Signal Level 3 DSLAM Digital Subscriber Line Access Multiplexer DSNE Directory Services Network Element Digital Cross-Connect Panel Distant Terminal Data Terminating Equipment ....................................................
Page 243 Glossary Acronyms and Abbreviations .................................................... EOOF Excessive Out of Frame EPROM Erasable Programmable Read-Only Memory Equipped (memory administrative state) Errored Seconds Electrostatic Discharge Extended Super Frame Environmental Stress Testing .................................................... Federal Communications Commission FDDI Fiber Distribution Data Interface Far End FE ACTY Far End Activity FEBE...
Page 244 Glossary Acronyms and Abbreviations ......................................................................................................Gigabit Ethernet Gateway Network Element Telcordia Technologies General Requirement General Telemetry Processor GTSIP Global Technical Support Information Platform Graphical User Interface .................................................... HECI Humans Equipment Catalog Item .................................................... Internal Clock Identifier International Electrotechnology Commission Infant Mortality Factor Incoming Status Input/Output...
Page 245 Glossary Acronyms and Abbreviations .................................................... In Service ISCI Intershelf control Interface Intershelf Interface ISDN Integrated Services Digital Network International Standards Organization Internet Service Provider IVHS Intelligent Vehicle Highway System .................................................... Local Area Network LAPD Link Access Procedure "D" Line Build Out Local Communications Network Local Exchange Carrier Light-Emitting Diode...
Page 246 Glossary Acronyms and Abbreviations .................................................... Low Speed .................................................... Mediation Device Major Alarm Multimode huMan-Machine Language Minor Alarm MPEG Moving Picture Experts Group MSDT Multi-Services Distant Terminal MTBF Mean Time Between Failures MTBMA Mean Time Between Maintenance Activities Mult Multipling Multiplex MXBIU Multiplexer and Backplane Interface Unit ....................................................
Page 247 Glossary Acronyms and Abbreviations .................................................... NEBS Network Equipment-Building System Nanometer (10 meters) Network Monitoring and Analysis NMON Not Monitored (provisioning state) Nonreturn to Zero NARTAC Lucent North American Regional Technical Assistance Center call 1-866-LUCENT8 (866-582-3688): Prompt 1 Network-Network Interface Not Service Affecting NSAP Network Services Access Point No Trouble Found...
Page 248 Glossary Acronyms and Abbreviations .................................................... Out of Lock OPS/INE Operations System/Intelligent Network Element Operations System OSGNE Operations System Gateway Network Element Open Systems Interconnection OSMINE Operations Systems Modifications for the Integration of Network Elements Outside Plant .................................................... P-bit Performance Bit Personal Computer Power Conversion Unit Program Identification...
Page 249 Glossary Acronyms and Abbreviations .................................................... Points of Presence POTS Plain Old Telephone Service Performance Report Message PROTN Protection Primary Reference Source Power Supply Unit Permanent Virtual Circuit Power .................................................... Random Access Memory Reliability Prediction Procedure (described in Telcordia Technologies TR-NWT-00032) Remote Terminal Return to Zero ....................................................
Page 250 Glossary Acronyms and Abbreviations .................................................... SEFS Severely Errored Frame Seconds Single-Ended Operations Severely Errored Seconds Super Frame (format for DS1 signal) System Identification Service Level Agreements SLIM Subscriber Loop Interface Module Single Mode SONET Synchronous Optical NETwork Synchronous Payload Envelope Sync Quality Unknown Software Release Description STS, STS-n...
Page 251 Glossary Acronyms and Abbreviations ......................................................................................................T1X1 and T1M1 The ANSI committees responsible for telecommunications standards Telcordia Technologies Technical Advisory TABS Telemetry Asynchronous Byte Serial (Protocol) TARP Target ID Address Resolution Protocol Threshold-Crossing Alert TCP/IP Transmission Control Protocol/Internet Protocol TCVCXO Termperature-Compensated Voltage-Controlled Crystal Oscillator Time Division Multiplexing Target Identifier...
Page 252 Glossary Acronyms and Abbreviations ......................................................................................................Unavailable Seconds User Network Interface Universal Optical Connector UPD/INIT Update/Intialize UPSR Unidirectional Path Switched Rings .................................................... Voice Frequency VLAN Virtual Local Area Network VLSI Very Large Scale Integration Violation Monitor Violation Monitor and Removal VoIP Voice over Internet Protocol VONU...
Page 253 Glossary Terms and Definitions ......................................................................................................Wide Area Network Terms and Definitions ....................................................................................Numerics Set up using unswitched cross connections on UPSR Ring Interfaces. The 1+1 protection switching architecture protects against failures of the optical transmit/receive equipment and their connecting fiber facility. One bidirectional interface (two fibers plus associated OLIUs on each end) is designated "service,"...
Page 254 Glossary Terms and Definitions .................................................... ASCII - American Standard Code for Information Interchange A standard 8-bit code used for exchanging information among data processing systems and associated equipment. Auto One possible state of a service interface port. In this state, the port will automatically be put "in service"...
Page 255 Glossary Terms and Definitions .................................................... CCITT - International Telephone and Telegraph Consultative Committee An international advisory committee under United Nations’ sponsorship that has composed and recommended for adoption worldwide standards for international communications. Recently changed to the International Telecommunications Union Telecommunications Standards Sector (ITU-TSS).
Page 256 (accepts transmitted data), or both. Dual Homing A network topology in which two Alcatel-Lucent 1850 shelves serve as hosts supporting up to 8 OC-3 rings or 4 OC-12 rings. Each OC-3 and OC-12 ring is interconnected between the two separate hosts.
Page 257 FT-2000 Lucent’s SONET OC-48 Lightwave System. Function Unit Refers to any circuit pack that is designated for Function-Group-C of the Alcatel-Lucent 1850 TSS- 5 shelf..................................................... GNE - Gateway Network Element A network element that has an active X.25 link.
Page 258 .................................................... LBO - Line Build Out An equalizer network between the Alcatel-Lucent 1850 TSS-5 and the DSX panel. It guarantees the proper signal level and shape at the DSX panel. LED - Light Emitting Diode Used on a circuit pack faceplate to show failure (red) or service state.
Page 259 See Intermediate Reach..................................................... Main The two slots (M-1 and M-2) on the Alcatel-Lucent 1850 TSS-5 shelf in which the OC-3 or OC-12 main OLIU circuit packs are installed. Midspan Meet The capability to interface between two lightwave terminals of different vendors. This applies to high-speed optical interfaces.
Page 260 Glossary Terms and Definitions .................................................... NE - Network Element The basic building block of a telecommunications equipment within a telecommunication network that meets SONET standards. Typical internal attributes of a network element include: onr or more high- and low-speed transmission ports, built-in intelligence, synchronization and timing capability, and access interfaces for use by technicians and/or operation systems.
Page 261 SONET APS channel (K1 and K2 bytes in the SONET line overhead). On a Alcatel-Lucent 1850 TSS-5, a protection line is a pair of fibers that terminate an OLIU circuit pack in the Main-2 or C-2 slots. See Service Line.
Page 262 DCC. Service Line On a Alcatel-Lucent 1850 TSS-5 system, a service (or "working") line is a pair of fibers (one transmit and one receive) that terminate on an OLIU circuit pack in the Main-1 or C-1 slots. As defined by the SONET standard, the SONET APS channel is not defined on a service line.
Page 263 Terms and Definitions .................................................... Single Homing A network topoly in which a single Alcatel-Lucent 1850 TSS-5 serves as a DDM-2000 FiberReach, OC-3 Multiplexer, or OC-12 Multiplexer host. Standby Standby identifies a 1+1 protected OC-N line which is not currently selected by the receiver at either end as the payload carrying signal, or 1x1 or 1xN protected circuit pack that is not currently carrying service.
Page 264 Glossary Terms and Definitions .................................................... Unidirectional A protection switching mode in which the system at each end of an optical span monitors both service and protection lines and independently chooses the best signal (unless overridden by an equipment failure or by an external request, such as a forced switch or lockout). In a system that uses unidirectional line switching, both the service and protection lines may be active simultaneously, with one line carrying traffic in one direction and other line carrying traffic in the other direction.
Page 265 Index ................fuse board (BDFB) 2-13 Interface Cable 2-14 1000Base-T serial port 3-33 optical fiber cables 3-29 battery distribution fuse board software 5-10 3-30 (BDFB) 2-15 CLETOP cleaning cassette bay frame ground ................abnormal alarm (ABN) 6-36 commands 7-10 ................See "minor/abnormal alarm conventions used cable(s)
Page 266 Index .................................................... environmental discrete 3-22 laser radiaition 3-29 ohmmeter 6-38 laser radiation 3-29 optical attenuators optical fiber scope damage LC Block out-of-service mode electronic components LC-type ................jack 2-12 connector port Personal Computer (PC) wrist strap fiber connectors CIT requirements 2-12 6-35 pinouts...
Page 267 Index .................................................... Pacific Bell Equipment Framework Standard PBS- 000-102PT ................telemetry 3-22 6-38 connections 6-38 panel 3-23 test equipment CIT Interface Cable DS1 error rate test set multimeter 2-12 ohmmeter optical fiber scope screwdrivers 2-12 video fiber scope tools CLETOP cleaning cassette Luminex Stick port cleaners screwdriver(s) torque wrench...
Page 268 Index ......................................................................................................I N - 4 365-372-403R5.1 Issue 1 November 2008...

Alcatel-Lucent 1850 Installation And System Turn-Up Manual

About this Document

1 Safety

Part I: Physical and Power Installation

2 Physical Installation Planning

3 Cable and Fiber Installation

4 Circuit Pack Installation

Part II: Stand-Alone Installation Tests

5 Stand-Alone Node Set-Up

6 Stand-Alone Installation Testing

Part III: Network Turn-Up and Testing

7 Connecting Adjacent Network Elements Fiber Installation

Part IV: Miscellaneous Detailed Installation Procedure and Reference Material

Technical Support

B Fiber Cleaning

PTM Installation

Installing Fiber Connectors and Lbos

Backplane Pin Replacement

F Fiber Labeling

Quick Links

Need help?

Questions and answers

Related Manuals for Alcatel-Lucent 1850

Summary of Contents for Alcatel-Lucent 1850

Table of Contents
