Epsilon Eb and EN Drives Reference Manual
In this example, the parameters of two user defined motors are named "User1" and "User2".
Abbreviated parameter identifiers are used in the .ddf file. The table below shows the
abbreviated identifier for each parameter followed by a description of each.
Motor Parameter
Motor Poles
Motor Encoder Lines Per Revolution
Motor Encoder Marker Angle
Motor Encoder U Angle
Motor Encoder Reference Motion
Motor Inertia
Motor Resistance
Motor Inductance
Motor Peak Current
Motor Continuous Current
Motor Maximum Operating Speed
Motor Encoder Exponent
Motor Parameter Descriptions
Note
These parameters are valid and active only when a user defined motor is selected. When
an Control Techniques motor is selected, the data in these registers remain at the last value
set and do not update to reflect the data of the Control Techniques motor selected.
Motor Poles
Specifies the number of magnetic pole pairs (N-S) on the motor. The supported values are 2,
4, 6, 8, 10, 12, 14 and 16 poles.
Motor Encoder Lines Per Revolution
Specifies a coefficient for determining the number of encoder lines per mechanical
revolution. The supported values are 1 to 16383. The equation for determining the total
number of encoder lines per revolution is:
nLines = n*10
where
nLines = Total number of Encoder Lines
n = Motor Encoder Lines per Rev Coefficient
x = Motor Encoder Exponent
176
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Motor KE
x
DDF Identifier
motorPoles
encoderLines
encoderMarker
encoderU
encoderRef
rotorInertia
motorKE
phaseResistance
phaseInductance
peakCurrent
continuousCurrent
maxOperatingSpeed
encoderExponent
