EN Drive Dimensions

6.90
[175.24]
11.70
[297.08]
0.41
[10.37]
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Minimum Connector
Clearance if used
1.75
[44.57]
0.41
[10.49]
Model
EN-204
EN-208
EN-214
Specifications
"A"
0.39
[9.78]
1.85
[47.12]
0.33
[8.32]
11.20
[284.54]
0.20 (5.08)
Typ. 4 Places
Dim "A"
2.93 [74.4]
3.43 [87.1]
3.93 [99.8]
209
